Mobile Base Station

RTR-500MBS-A

Getting Started Guide

Thank you for purchasing our product.

This manual explains the basic usage and features of RTR-500MBS-A.

2016. 03 16504810011 ( 4th Edition)

Safety Precautions &

Product Overview

Getting Ready

Installing the Software

Making Settings &

Transmission Tests

Installing the Device

Checking Data on T&D

WebStorage Service

Using T&D Graph to Access

WebStorage Data

LED Display / FAQ's /

Specifications / Options

Table of Contents

Need help?

Do you have a question about the RTR-500MBS-A and is the answer not in the manual?

Questions and answers

Summary of Contents for T&D RTR-500MBS-A

Page 1 Safety Precautions & Product Overview RTR-500MBS-A Getting Started Guide Getting Ready Thank you for purchasing our product. This manual explains the basic usage and features of RTR-500MBS-A. Installing the Software Making Settings & Transmission Tests Installing the Device Checking Data on T&D WebStorage Service Using T&D Graph to Access...
Page 2: Table Of Contents
Installing Devices------------------------------------------------ 22 Safety Precautions and Instructions ---------------------------- 6 Turning Operation Switch to the <Run> Position ------------- 23 What can the RTR-500MBS-A do? ----------------------------- 7 Accessing T&D WebStorage Service -------------------------- 23 Package Contents ----------------------------------------------- 8 Checking Data on T&D WebStorage Service ---- 25...
Page 3: Important Notices And Disclaimers
Important Notices and Disclaimers In order to properly use this product, please carefully read all attached documents before using. T&D Corporation accepts no responsibility for any malfunction of and/or trouble with this product or with your computer that is caused by the improper handling of this product and will deem such trouble or malfunction as falling outside the conditions for free repair outlined in the attached warranty.
Page 4: Safety Precautions And Instructions
Denotes an important warning or caution. • Avoid exposure to static electricity when handling the card. • Make sure to disconnect all cables (AC adaptor, USB cable, and external power cable) from the RTR-500MBS-A before inserting or Denotes a forbidden action. removing the card.
Page 5: Safety Precautions And Instructions
Safety Precautions and Instructions DANGER To Prevent Serious Accidents Place and store the unit and accessories out of the reach of children. Do not disassemble, repair or modify the unit and accessories. Further, T&D is not responsible for any damage, malfunction or trouble, whether direct or indirect, caused by the use of our products.
Page 6: Safety Precautions And Instructions
Safety Precautions and Instructions CAUTION Notes and Precautions for Installing Wireless Communication Devices CAUTION Do not place or store in the following areas: When installing wireless communication devices take special care in selecting • Areas exposed to direct sunlight locations so as to ensure proper communication. Note that even after a •...
Page 7: What Can The Rtr-500Mbs-A Do
What can the RTR-500MBS-A do? RTR-500MBS-A is a Base Unit equipped with both wireless and 3G mobile communication capabilities. After collecting measured data (current readings and recorded data) from Remote Units via wireless communication, the Base Unit can transmit the collected data via 3G mobile networks to a server or e-mail account.
Page 8: Package Contents
Package Contents RTR-500MBS-A Antenna (x 2) USB Mini-B Cable (US-15C) External Power Cable Software AA Alkaline Battery (x 4) (BC-0302) CD-ROM Getting Started Guide (Warranty Included)
Page 9: Part Names And Functions
Part Names and Functions SMA Male Jack Antenna Connector SMA Female (with protective cover) Jack Optical Communication Area Included Antennas External Alarm USB Port Input / Output Terminal Operation External Power Switch Connector AC Adaptor Jack ( 4 EIAJ Voltage Classification 2 ) Battery Cover...
Page 10: Getting Ready
• The SIM card must also have SMS (Short Message Service) capability if the following functions are desired. - Warning Notification via SMS • Do not connect a RTR-500MBS-A to your computer until the software has been installed. - Remote control of the RTR-500MBS-A from a mobile device via SMS commands(*) * Available commands are the “start”...
Page 11: Setting Up The Device
When purchasing a SIM card, you may be asked for the IMEI number (depending on the type of SIM card). Connect the Antennas. The IMEI number for your RTR-500MBS-A can be found in the software Remove the protective covers from the antenna connectors (LOCAL/ settings window.
Page 12 Close the card holder and slide the cover to lock it. How to Remove the Battery Cover Lock If the cover is not properly locked, it may cause insufficient contact with the IC and result in a communication error. While pressing down on the triangular mark ( ), slide the cover to the bottom of the unit Insert the batteries, making sure they are in the proper direction ( ).
Page 13: Registering With T&D Webstorage Service
Registering with T&D WebStorage Service By using T&D WebStorage Service, a cloud service provided by T&D free of charge, it is possible to monitor the RTR-500MBS-A data over the Internet. If you don't use T&D WebStorage Service, please arrange a provider's server or your own FTP server.
Page 14: Installing The Software
Installing the Software Installing the Software Start Windows and login using a User Account with Administrator (Computer Administration) rights. Installing the Software Insert the software CD into the CD/DVD drive, and the [Install Connecting the Base Unit to a PC Program] window will open automatically.
Page 15: Connecting The Base Unit To A Pc
Turn the operation switch on the Base Unit to <STBY>, and connect it to the computer with the supplied USB cable. The USB driver installation will start automatically. After the USB driver installation is completed, a window will open where you can make or change various settings related to the RTR-500MBS-A.
Page 16 Troubleshooting and Detailed Info Detailed information about software settings is provided. Please select from the launcher. Getting Started Guide: This document is available as a PDF file. Operation Guide: This contains information about basic settings as well as advanced settings for many useful functions. Help for Unit Recognition Failure: Click here for information on how to check and reinstall the USB driver.
Page 17: Making Settings & Transmission Tests
Making Basic Settings for Base Unit Making Settings & Transmission Tests • In order to prevent unnecessary or unexpected data transmission, we suggest turning the Operation Switch on Making Basic Settings for Base Unit the Base Unit to <STBY> until the units have all been set up and ready for communication.
Page 18: Making Settings For T&D Webstorage Service
[Auto-Adjustment](*) is turned OFF, the clock on the RTR-500MBS-A ing information. will not be adjusted automatically. * Auto-Adjustment is a function whereby the RTR-500MBS-A uses clock information sent from the carrier to automatically adjust the date and time. (This may not apply with some carriers.) Send Current Readings * Adjustment is made when the Operation Switch is turned to the <Run>...
Page 19: Registering A Remote Unit
• Optical Communication: RTR-501 / 502 / 503 / 505 / 507 Auto-Sending of Recorded Data Place the Remote Unit face down on the Base Unit connected to the Transmission computer so that the optical communication areas meet. Select either method. Scheduling Method Transmit by day Make settings here for dates and times for the...
Page 20: Making Transmission Tests
• Remote Unit Settings can also be changed or added later. For details, see the Remote Unit Assign a unique name for the Remote Unit. Operation Guide [ Other Useful Functions] > [Changing Remote Unit Registration Name Info]. Recording Interval Select the desired interval.
Page 21: How To Confirm Tests Were Successful
How to Confirm Tests were Successful: For the External Contact Output Test See if the warning device connected to the external contact output operated For the Transmission of Current Readings, Warning Reports, properly. and Recorded Data Tests If a Transmission Test Ends in Failure: When the destination is T&D WebStorage Service: •...
Page 22: Installing The Device
Connecting to an External Power Source (when Installing the Device applicable) Connecting to an External Power Source (when appli- Use an External Power Cable cable) The supplied external power cable can be used to connect to an external power source such as a car battery. Installing the Device * For cable specifications, see the [Option] page (p.30).
Page 23: Turning Operation Switch To The Position
When a PC is not available at the actual location of the Turn the Operation Switch on the Base Unit to the <Run> position. RTR-500MBS-A, it is possible to use a mobile device (such as a smart Operation Switch phone or tablet) to check the T&D WebStorage Service for signal strength.
Page 24 It is possible to check the signal strength between Base Unit and Remote Unit by color and number of antennas. Blue Communication is stable. (3-5 antennas) Communication is unstable. (1-2 antennas) Reposition the device(s) for more stable communication. Failed to check the signal strength due to wireless communication (no antenna) error.
Page 25: Checking Data On T&D Webstorage Service
Downloading Recorded Data Checking Data on T&D WebStorage Service It is possible to download recorded data from T&D WebStorage Service, and Viewing Current Readings open the downloaded data in T&D Graph (*). In the top (Current Readings) page of the T&D WebStorage Service, * Please use the computer on which T&D Graph has been installed.
Page 26: Using T&D Graph To Access Webstorage Data
Using T&D Graph to Access WebStorage Data With T&D Graph, it is possible to directly access and open the recorded data stored on the T&D WebStorage Service. * Please use the computer on which T&D Graph has been installed. Open T&D Graph. From the [File] menu, select [T&D WebStorage Service].
Page 27: Led Display
LED Display 3G Network Reception Level <ANT. LEVEL> Operation Status Reason Notes Switch - Running on battery power Reception Level BLINKING only Operation in progress Strong - Running on AC Adaptor or <Run> external power source - During 3G mobile BLINKING Communication communication or short range...
Page 28: Faq
Please refer to the following when contacting your cell phone carrier about The RTR-500MBS-A uses radio communication that is subject to local rules and regulations for the area in which it is being used. It is the responsibility of the estimated costs.
Page 29: Specifications
PAP-04V-S. Communication The same amount of time will be necessary for each Repeater. *3: SMS is required for some functions of the RTR-500MBS-A. If SMS is necessary, make Time Does not include communication time from Base Unit to server or sure that the contract you have with your carrier includes this service.
Page 30: Options
Options Wall Attachment: TR-5GK1 AC Adaptor: AD-05A3 Included: Input AC100-240V O-Ring ( rubber ) x 1 Output DC5V, 3A Lock Screw x 2 Frequency 50/60Hz Double-Sided Adhesive Cable Length 1.2m Tape x 1 Plug Type A Dimension: W73 x H72 x D43 mm Screw Holes: 2 - 4.2mm Materials: Aluminum...
