Page 1 RTR-61 for Windows (EU) RTR-5W Wireless and Network Station RTR-50 Wireless Communication Port Thank you for purchasing our product. Carefully read this instruction manual before using this unit. © Copyright T&D Corporation. All rights reserved. 2011.10 16504390009 (5th Edition)
Page 2: Notices About This User's Manual
Notices about this User's Manual In order to properly use this product, please carefully read this manual before using. T&D Corporation accepts no responsibility for any malfunction of and/ or trouble with this product or with your computer that is caused by the improper handling of this product and will deem such trouble or malfunction as falling outside the conditions for free repair outlined in the attached warranty.
Page 3: Software User Agreement
T&D Corporation. 2. RTR-61 for Windows (EU) is for use free of charge. Redistribution is permitted as long as it is to others for non-profit. In this case, all terms and conditions as written in the above disclaimers automatically transfer and hold true and valid for the party to which the program was redistributed.
Page 4: Safety Precautions And Instructions
Safety Precautions and Instructions To ensure the safe use of RTR-5W and RTR-50 The following items should be strictly obeyed for the safe usage of this unit, and for protecting yourself and other people from bodily harm and/or damage to property. To ensure the proper use of our product, please read the following carefully and fully understand the contents.
Page 5 DANGER Be sure to follow the warnings and notices about use from your PC maker when installing and using this unit. Do not take apart, repair or modify the main unit. Doing so may cause fire or electrocution. If water or a foreign body enters in this unit, turn the power off and remove the batteries.
Page 6 CAUTION We are not responsible for any damage, malfunction or trouble, whether direct or indirect, caused by the use of our product.Please be fully aware of this before using our product. This product has been designed for private or industrial use only. It is not for use in situations where strict safety precautions are necessary such as in connection with medical equipment, whether directly or indirectly.
Page 7: Rtr-5W
RTR-50 Battery life depends on the measurement environment, communication frequency, recording interval and battery quality. Do not use any other batteries than those that are specified in this User's Manual. It may cause a fire or other trouble including malfunction. Battery terminals may provide insufficient contact due to age or vibration.
Page 8 Compliance Information CE Statement This device complies with technical specifications required under EN 301 489 (with battery and AC Adaptor), EN 300-220, and EN 60950-1. Important Notice Wireless products cannot be used in countries other than where those products have been approved for use, according to that country’s wireless regulations.
Page 9 Introduction...
Page 10: Table Of Contents
Deleting / Initializing Remote Unit ------ 65 Installing batteries for Repeater(s) --------------- 27 Confirming Remote Unit Info -------------------- 65 Installing Software "RTR-61 for Windows (EU) " -- 28 Deleting Remote Unit / Group ------------------- 65 For Windows XP ---------------------------------- 28...
Page 11 About [File] Menu ------------------------ 73 Messages shown during communication of a Measurement Command ------------------109 4. How to use "RTR-61 for Windows" Communication Results -------------------------110 Checking Data -----------------------------------111 About the Display ------------------------ 76 Data Files Recorded by Remote Measurement Main Window ------------------------------------- 76...
Page 12: What Is Web Wing Wl Rtr-5W
NOTE: About the Explanation of RTR-5W - This manual only provides information about RTR-5W which is necessary in order to carry out operations with "RTR-61 for Windows (EU)" . - For more detailed info about RTR-5W functions, see the product introduction page on our Website.
Page 13: General Procedure For Using An Rtr-5W
Getting Ready 1. Getting an Remote Unit (RTR-61) Ready to Use - Install the batteries and sensor (See the RTR-61 User's Manual) 2. Getting the Base Unit (RTR-5W) Ready to Use - Check your operational settings and network environment for the RTR-5W.
Page 14: What Is Communication Port Rtr-50
Data Logger as a Remote Unit of that RTR-50 via optical communication using the supplied optical communication adaptor (RTR-06A1). - If the distance between an RTR-50 Base Unit and an RTR-61 Remote Unit exceeds the possible range of wireless communication, it is...
Page 15: General Procedure For Using An Rtr-50
Base Unit (via a Wireless) Getting Ready 1. Getting an Remote Unit (RTR-61) Ready to Use - Install the batteries and sensor (See the RTR-61 User's Manual) 2. Getting the Base Unit (RTR-50) Ready to Use 3. Getting the Repeater (RTR-50) Ready to Use - When the use of a Repeater is necessary, after considering the wireless communication distance, determine the needed number of Repeaters.
Page 16: What Is "Rtr-61 For Windows (Eu)
What is "RTR-61 for Windows (EU)"? "RTR-61 for Window (EU)" is software designed to be used with our wireless core temperature data logger, RTR-61. This user friendly software enables the user to download data, view data lists and save data to files, as well as make important logger settings.
Page 17: Getting Ready
1. Getting Ready This section provides instructions on getting ready to install the supplied software.
Page 18: Getting Rtr-5W Ready To Use : Rtr-61Sk-W
Package Contents The following items are included in the package. Network Station CD-ROM LAN Cable RTR-5W RTR-61 for Windows (EU) LN-20W •••••• •••••••• • • • • • • •• • ••• • •• • •• AC adaptor Optical Communication...
Page 19: Rtr-5W Part Names And Functions
RTR-5W Part Names and Functions [FRONT] Optical Communication Area POWER LED POWER LED While the power is ON, the lamp will be on. When you wish to communicate directly, not by wireless, with Optical a data logger (Remote Unit), it is necessary to place the logger Communication Area (Remote Unit) face down on this area for communication to occur.
Page 20: Checking Your Operating Environment
Checking your Operating Environment To properly use the logger, the following operational environment is necessary. PC Operating Environment Microsoft Windows 7 32/64bit English Microsoft Windows Vista 32bit English Microsoft Windows XP 32bit(SP2 or above) English * For installation, it is necessary to have Administrator (Computer Administrator) rights.
Page 21: Connecting Supplied Lan Cable
Connecting Supplied LAN Cable NOTE: - To ensure a proper connection make sure that the connector is completely inserted. Connecting Supplied AC Adaptor NOTE: - To ensure a proper connection make sure that the plug is completely inserted. - Do not use an AC adaptor other than the one that is supplied with the product. Doing so may cause fi re or other trouble.
Page 22: Connecting To A Network
Connecting to a Network The following are some ways to connect an RTR-5W to a network. Please select the connection method that suits your network environment. NOTE: - To ensure a proper connection make sure that the plug is completely inserted. Connection Example Connecting to a HUB for in-company Communication Connecting Directly to PC for Communication...
Page 23: Connecting To A Wireless Lan
Connecting to a Wireless LAN By inserting a Wireless LAN card into the RTR-5W, it is possible to carry out communication in places where LAN wiring is difficult or troublesome. NOTE: - To ensure a proper connection make sure that the wireless LAN card is completely inserted.
Page 24: Connecting To The Internet
Connecting to the Internet In order to connect the RTR-5W to the Internet, you must fi rst set up an Internet connection environment by making arrangements with a provider for a line and get a global IP address and domain. Also, if necessary, make all domain name server and / or router settings.
Page 25 Using a Domain Name (ex: rtr-5w.net) In order to access the RTR-5W from your browser, enter the Domain Name (Ex: rtr-5w.net) that has been assigned to the RTR-5W in your browser's URL bar following [http://]. The Domain Name that was entered in the URL bar is converted by the DNS server into an IP address and the RTR-5W is called.
Page 26: Getting The Rtr-50 Ready To Use : Rtr-61Sk
The following items are included in the package. Communication Port RTR-50 CD-ROM USB Cable (Ver.2-1-x or higher) RTR-61 for Windows (EU) (US-15C) •••••• •••••••• • • • • • • •• • ••• • •• • •• Optical Communication Adaptor...
Page 27: Installing Batteries For Repeater(S)
[RIGHT SIDE] RS-232C (Serial) USB (MiniB) AC Adaptor Connection Jack NOTE: - "RTR-61 for Windows (EU)" can only be used when the PC communication connection is with a USB Cable. [Back] Optical Communication Area Battery Cover Installing batteries for Repeater(s)
Page 28: Installing Software "Rtr-61 For Windows (Eu)
For information about operating the software, please carefully read the important notices and instructions found in the User’s Manual. For Windows XP, Vista and 7, in order to install "RTR-61 for Windows (EU)", it is necessary to have Administrator rights (Computer Administrator) for the computer in which you wish to install it.
Page 29: For Windows Vista / 7
Continue the installation by following the directions as they appear. After installation has been completed, RTR-61 for Windows (EU) will be registered in Window's [Start] Menu. For Windows Vista / 7 Open Windows. Insert the attached CD-ROM in the CD-ROM drive.
Page 30 Select [Install RTR-61 for Windows], then click the [Run] button and the [User Account Controls] window should appear. Click [Next] to start the installation. Continue the installation by following the directions as they appear. After the software has been installed, the following message will appear: Click the [Install] button.
Page 31: Using Applications
Using Applications How to Open From the list of programs in the Window's Start Menu, click on RTR-61 for Windows(EU). Launcher "RTR-61 for Windows (EU)" is made up of four applications. By clicking on "RTR-61 for Windows (EU)", the Launcher Window will appear.
Page 32: Using Help
Using Help For details about how to use the software, please see the explanations in the Software Help Menu. By clicking on [Help] in the Menu Bar and then click on one of the tabs [Contents] or [Index] to search for the topic or term you are unsure about or have questions about.
Page 33: Before Using The Rtr-50
Before using the RTR-50 Have you installed the software that comes with the RTR-50? Make sure to install the provided software before connecting the RTR-50 to your PC. If you do connect the unit before installing, make sure to click the "Cancel" button in the Wizard window when it appears.
Page 34: Installing The Usb Device Driver
Installing the USB Device Driver Before using the RTR-50, it is necessary to install the USB device driver. After installing the USB device driver, your computer will be able to detect and recognize any RTR-50 that has been connected with a USB cable. Connect the supplied USB cable to a USB port on your computer.
Page 35: Installation Procedure By Operating System
For Windows Vista and 7, in order to install "RTR-61 for Windows (EU)", it is necessary to have Administrator rights (Computer Administrator) for the computer in which you wish to install it.
Page 36: For Windows Xp
® For Windows For Windows XP, in order to install "RTR-61 for Windows (EU)", it is necessary to have Administrator rights (Computer Administrator) for the computer in which you wish to install it. Turn on your computer and open Windows.
Page 37 If the Driver is not automatically detected (Windows XP) Disconnect the USB cable from RTR-50 and then re-connect it. The [Add New Hardware Wizard] will automatically open. * Windows such as this will not appear for [No Service Pack] and [Service Pack 1] versions.
Page 38 Select the driver for the device being used from the folder where "RTR-61 for Windows (EU)" was installed. EX C:\Program Files\RTR-61 for Windows (EU)\Driver RTR-50 Insert the CD-ROM into the proper drive and from the CD-ROM select the driver for the device being used.
Page 39 ® Confirming Connection for Windows Connect an RTR-50 to the Computer. (See page 34 for details) Open the [Control Panel] and double click on [System]; the [System Properties] will be displayed. Click the [Hardware] tab, and click the [Device Manager] button in the [Device Manager] Area.
Page 40: If Usb Device Driver Installation Fails
If USB Device Driver Installation Fails If, during USB device driver installation, some trouble occurs that results in a failure to install properly, the following display will appear in the Device Manager. EX: This mark means installation failure. For Windows Vista / 7 Even after having properly installed the provided software, there may be a few cases where USB communication cannot be carried out.
Page 41 2. Network Settings Utility This application is a set of tools to help make settings for connecting an RTR-5W to a network.
Page 42: Network Settings Utility
Network Settings Utility From the list of programs in the Window's Start Menu, click on [RTR-61 for Windows(EU)]-[Network Settings Utility]. Menu Bar Functions Tab Main Items in the Network Settings Utility [Network Initialization] Tab After purchasing a RTR-5W unit, the first step is to make all Network Initialization Settings including assigning an IP Address and a Subnet Mask.
Page 43: Menu
Menu [MENU] [Login History] If you wish to disable the History Function, select [Login History] -> [OFF]. [Clear Login History] Use this to erase the entire login history. By clicking [Clear Login History], a confirmation message will appear. Select "Yes" to erase the entire login history. [Communication Time Settings] In the [Detailed Network Settings], communication speed settings can be made.
Page 44: Network Initialization Settings
Network Initialization Settings To connect an RTR-5W to a network, it is necessary to enter an IP Address and Subnet Mask that are appropriate for your network. Please note, that upon purchase, all RTR-5W units are set with the same IP address. To make IP address changes, connect one unit at a time and carry out the changes.
Page 45 From the displayed list, select the RTR-5W to which you wish to make settings by clicking on the IP address and click on the [Change Settings] button. * Also, by double clicking on the IP address, the [Network Settings] window appear . [Change Settings] Button Select IP Address...
Page 46: Detailed Network Settings
Detailed Network Settings After making the network initialization settings for the RTR-5W, the reception of RTR-5W settings and more detailed network settings can be made. * Before making any of these settings, please make sure that the RTR-5W is set with the proper IP address.
Page 47: Making Settings (Changes)
Making Settings (Changes) . In the [Detailed Network Settings] window, click the [Change Settings] button and make any necessary changes. [Change Settings] Button Enter info for the RTR-5W you [Send Settings] Button wish to make settings in. . After making the settings, enter the info for the recipient of the settings and click the [Send Settings] button.
Page 48: [Re-Activate Communication] Button
[Re-activate Communication] button If the browser does not open, wireless communication continually results in failure, or if any errors occur during communication, click the [Re-activate Communication] button. [Re-activate Communication] Button NOTE: - Note that by clicking the [Send Settings] button or the [Re-activate Communication] button over and over, communication may become impossible.
Page 49: Returning Network Settings To Factory Default Settings
Returning Network Settings to Factory Default Settings If you have forgotten the IP address or the password you can easily return the logger to the default factory settings. Pull out the AC adaptor plug from the RTR-5W logger. Press in the <RESET> button on the RTR-5W logger with a pointed object and reconnect the AC adaptor.
Page 50 Network Settings Utility for RTR-5W...
Page 51: 3. Rtr-61 Registration
3. RTR-61 Registration This application is designed to carry out Base Unit (RTR-5W / RTR-50), Repeater (RTR-50) and Remote Unit (RTR-61) Registration.
Page 52: Image Of Registration
Repeater. - Also, when carrying out Repeater Registration it is possible to assign a "Relay Route Name" that can be used to make sure that data is transmitted through a multiple number of Repeaters in the specified route. RTR-61 Registration...
Page 53 Remote Unit. If it is necessary to download a unit with full data, then it is also necessary to have no more than 20 Repeaters. For all communications other than downloading, no conflict with the time limitation will occur, even if there are 250 Repeaters present. RTR-61 Registration...
Page 54: Basic Procedure For Registration
Wireless Communication Test -> p.71 Checking Network Connection -> p.72 Others Confirming Remote Unit Info, Deleting /Initializing Remote Unit -> p.65 Confirming Repeater Info, Deleting /Initializing Repeater -> p.67 RTR-61 Registration...
Page 55: Making A New Base Unit Registration
Making a New Base Unit Registration From the list of programs in the Window's Start Menu, click on [RTR-61 for Windows(EU)] - [RTR-61 Registration] to open the registration window. Basic Procedure for Registration: from the [Registration] Menu Connect the unit to be registered to your computer. Then carry out the following procedure to register one Base Unit at a time.
Page 56: Modifying And Deleting Registration Contents
Select the Base Unit from the Base Unit Registration List and then click [Delete] in the [Registration] Menu. Then a confirmation massage will appear. By clicking the [OK] button, the selected Base Unit will be deleted from the Registration List. RTR-61 Registration...
Page 57: Remote Unit Registration
Place the supplied Optical Communication Adaptor (RTR-06A1) on top of a registered Base Unit. The "RTR-61 Registration" application open. Place the Remote Unit on top of the adaptor as shown in the figure, making sure that the optical communication area is aligned properly.
Page 58: New Registration
At the left side of the window, the selected Base Unit icon is displayed . Connect the Base Unit which displays its icon to your computer. Then place the Remote Unit (RTR-61 Data Logger) on top of the Base Unit using an optical communication adaptor (See page 57).
Page 59 - A distinction will be made between upper and lower case alphabet. Ex. abc123 and ABC123 will be treated as different. - In order to register a Remote Unit, it is also necessary to register a Group Name. RTR-61 Registration...
Page 60 When successful communication has occurred, the Group Name and Remote Unit Name will appear. If you wish to register the currently displayed Remote Registration Contents without any changes, click the [New Registration] button to add the received registration info. RTR-61 Registration...
Page 61: Repeater Registration
- Up to 8 characters can be entered. - You may leave this field blank if not necessary and should note that changes cannot be made after registering a Repeater. If you wish to make changes, it is necessary to create the Relay Route again. RTR-61 Registration...
Page 62: Registration List
- Test / KOKI1 The Repeater in Relay Route "Route2" is not connected to any Remote Units. The following Remote Units communicate directly with the Base Unit. - Group1 / R1a - Group1 / Remote34 - Group2 / Remote1 RTR-61 Registration...
Page 63: Connecting A Remote Unit Via Repeater(S)
. The Remote Unit will be added under the location in the Relay Route (background color: blue) in the Registration List. RTR-61 Registration...
Page 64: Removing A Remote Unit From A Relay Route
By selecting a Remote Unit or a Repeater in the Registration List and right clicking on it, the Menu will be displayed. The Tab window at the right will automatically be changed according to the selected Menu item. RTR-61 Registration...
Page 65: Confirming Remote Unit Info Deleting / Initializing Remote Unit
- By deleting a Remote Unit, communication will be impossible with that unit. However, the registration contents will still remain in the unit. Make sure to initialize it when not in use. - The Relay Route and Repeater in the current display will not be deleted. RTR-61 Registration...
Page 66: Initializing Remote Unit
. Click the [Initialize] button on [Remote Unit Info / Delete / Initialize] Tab. [Remote Unit Info / Delete / Initialize] Tab [Initialize] Button - When initializing a currently registered Remote Unit, the Registration Info will also be erased from the Registration List. RTR-61 Registration...
Page 67: Confirming Repeater Info Deleting / Initializing Repeater
[Delete Route] Button Deletes the Relay Route in the current display from the Remote Unit Group List and Registration List. When deleting a Relay Route, all Repeaters which belong to that Relay Route will also be automatically deleted. RTR-61 Registration...
Page 68: Replacing Repeater
Base Unit for communication. If you wish to communicate with the Remote Units via the newly added Repeater, it is necessary to manually move them in the Registration List so they connected for communication via the new unit. RTR-61 Registration...
Page 69: Initializing Repeater (Returning To Base Unit)
- Initializing the Unit will return it to the condition it was in when it left the factory. The default setting for an RTR-50 Unit is as a Base Unit. When using as a Base Unit from the start, initialization is not necessary. RTR-61 Registration...
Page 70: Getting Base Unit / Repeater Info (Direct Communication)
RTR-50 Battery life and Battery Replacement The Battery Level will be shown in 5 stages (1 to 5). We suggest that you change the batteries if the remaining battery level becomes 3 or lower. (1: Low < 5: High) RTR-61 Registration...
Page 71: Wireless Communication Test
Radio Wave Strength Test from the Relay Route Name List. If you have checked [All Routes] in the [Select Route for Test] box, the Radio Wave Strength Test for all Repeaters and Remote Units that belong to each of the Routes will be carried out. RTR-61 Registration...
Page 72: Wireless Communication Test Results
Open Internet Explorer. Then enter the IP address (or Domain Name) that has been assigned to the RTR-5W in your browser's URL bar. If proper settings have been made with a correct IP address, the following message will be displayed. RTR-61 Registration...
Page 73: About [File] Menu
This file can be used, however, for copying registration information from one computer to another, or for changing registration on the current computer. [Quit] Quits and closes the application. RTR-61 Registration...
Page 74 RTR-61 Registration...
Page 75: How To Use "Rtr-61 For Windows
4. How to use "RTR-61 for Windows" After completing the Remote Unit Registration, open the settings application "RTR-61 for Windows" to make various operational settings for the Remote Unit(s).
Page 76: About The Display
Then go to the [Communication] Menu to carry out the necessary commands. Communication Log A log listing communications with Remote Units while the application is running will be displayed. (See the next page.) How to use "RTR-61 for Windows"...
Page 77: Communication Log
Main Window, a file containing "Full Communication History" will be automatically stored in the same folder where "RTR-61 for Windows (EU)" was installed. (See page 130 for details) com.log How to use "RTR-61 for Windows"...
Page 78: Item Table: [File] Menu
Select a Remote Unit from the Remote Unit List Right clicking Also by right clicking on the Remote Unit List Display, the Menu will appear. [Item Table] Window Item Name, Item Group Upper / Lower Limit List How to use "RTR-61 for Windows"...
Page 79 - Note that if more than one Remote Unit has been selected, some commands in the [Communication] Menu cannot be carried out. Hold down the <Shift> key to select Hold down the <Ctrl> key to select Remote several sets of Remote Units. Units separated from one another. How to use "RTR-61 for Windows"...
Page 80: Creating Item Tables
Item Name, Upper Limit and Lower Limit in the Item List. . Right click on the Item List and select [Insert Item] from the Menu to add an Item to the Item List. Right click on [Insert Item] How to use "RTR-61 for Windows"...
Page 81 Unit Info (Page 105 ) in "Communication" Menu – "Get Remote Unit Info" . - If a name that has already been assigned to another Item is entered and/or the number of entered characters exceeds the limit, an error message will appear. How to use "RTR-61 for Windows"...
Page 82: Sending Item Tables
After making Item Table entries, select [Send Item Table] from the [Communication] Menu to send the entered info to the Remote Unit (RTR-61 data logger). When the communication has been completed, the Item Table will be registered into the Remote Unit.
Page 83: Getting Item Tables
. Select the Item line to be corrected and right click on it to show the Menu. [Insert Item] It is possible to add a new Item above the selected line. [Delete Item] It is possible to erase the selected line. How to use "RTR-61 for Windows"...
Page 84 Unit Info (Page 105) in "Communication" Menu – "Get Remote Unit Info" . - If a name that has already been assigned to another Item is entered and/or the number of entered characters exceeds the limit, an error message will appear. How to use "RTR-61 for Windows"...
Page 85: Deleting The Contents Of An Item Table
By selecting [Create New] in the [File] Menu, all Items that are displayed in the Item Table will be deleted. - The deletion made here will not be reflected in the RTR-61 Remote Unit until the [Send Item Table] command in the [Communication] Menu is executed.
Page 86: Other Menus
- For details about Remote Measurement Commands see page 108. - Remote Measurement Command cannot be carried out when a multiple number of Remote Units has been selected. Close: [File] Menu Closes the Item Table Window. How to use "RTR-61 for Windows"...
Page 87: User Table: [File] Menu
Unit List and open the [File] Menu. Select a Remote Unit from the Remote Unit List Also by right clicking on the Remote Unit List Display, the Menu will appear. [UserTable] Window User List User Group List How to use "RTR-61 for Windows"...
Page 88: Creating User Tables
- Up to 8 characters can be entered for User Group and User Name. . Right click on the User Group List in the User Table and select [Insert Group] from the Menu. Then enter the User Group Name. Enter the Group Name Check How to use "RTR-61 for Windows"...
Page 89 Right click on [Insert User] NOTE: - If a name that has already been assigned to another User is entered and/or the number of entered characters exceeds the limit, an error message will appear. How to use "RTR-61 for Windows"...
Page 90: Sending User Tables
After making User Table entries, select [Send User Table] from the [Communication] Menu to send the entered info to the Remote Unit (RTR-61 data logger). When the communication has been completed, the User Table will be registered into the Remote Unit.
Page 91: Getting User Tables
. Select the User line to be corrected and right click on it to show the Menu. [Insert User] It is possible to add a new User above the selected line. [Delete User] It is possible to erase the selected line. How to use "RTR-61 for Windows"...
Page 92: Deleting Contents Of User Tables
By selecting [Create New] in the [File] Menu, all Users that are displayed in the User Table will be deleted. - The deletion made here will not be reflected in the RTR-61 Remote Unit until the [Send User Table] command in the [Communication] Menu is executed.
Page 93: Saving User Tables In Text File
User Table - It is also possible to create a User data list in the same Text File Format as when the data was exported. Other Menus Close: [File] Menu Closes the User Table Window. How to use "RTR-61 for Windows"...
Page 94: [Communication] Menu
Remote Unit List and then open the [Communication] Menu. Select a Remote Unit from the Remote Unit List Right clicking Also by right clicking on the selected Remote Unit(s), the Menu will be displayed. How to use "RTR-61 for Windows"...
Page 95: Selecting The [Communication] Menu
LAN cable Select the icon of the Base Unit and then click [Communication] or right click on the icon to display the Menu available for optical communication. Select icon of Base Unit How to use "RTR-61 for Windows"...
Page 96: Operational Settings
Remote Unit are different. - For details about the settings and operations that can be carried out by the RTR-61 Unit, see the User's Manual that accompanies your Push Wireless RTR-61 data logger.
Page 97: Recording Mode
. Click the [Send] button to start communication with the Remote Unit and the settings will be transmitted. - The settings made here will not be reflected in the RTR-61 Remote Unit until the [Send] button is clicked and communication can occur with the Remote Unit.
Page 98 (Delta Temperature: C /sec) between 0.1 C and 25 C (0.2 F and 45.0 F) . When the <REC> button on the RTR-61 Unit has been pushed and a change in temperature occurs within a second which is greater than that which was set as...
Page 99 - If more than one Remote Unit has been selected, the Item / User Name Table settings cannot be made. - In this case, the Item / User Name which are at the beginning of the list in the Remote Unit display will automatically be selected. How to use "RTR-61 for Windows"...
Page 100: Making Recorded Data File Settings
- If a multiple number of Remote Units is selected, the Prefix setting cannot be made. [Location] By clicking the [ ... ] button, it is possible to select the desired folder. The data downloaded via wireless communication will be saved into the specified folder. How to use "RTR-61 for Windows"...
Page 101: Rtr-61 Clock Settings
Unit. Select Remote Unit(S) [Send] Button NOTE: After making clock settings, please erase the recorded data in the Remote Unit. When downloading recorded data by specifying date and time, it may not work properly. How to use "RTR-61 for Windows"...
Page 102: Downloading Recorded Data
Download only that data recorded after a specified time. NOTE: - After making clock settings (see page 101), make sure to erase the recorded data in the Remote Unit. Otherwise it may not work properly when downloading data by specified time. How to use "RTR-61 for Windows"...
Page 103: About File Names And Locations For Downloaded Data
When downloading recorded data, data file ".puw" and text file ".txt" will be simultaneously created and saved into the same destination folder. - For details about the destination folder, see page 128 for details. How to use "RTR-61 for Windows"...
Page 104: Checking Downloaded Data
Checking Downloaded Data By clicking the [View Data List] button after downloading data, the "RTR-61 Data Viewer" will be opened. Here it is possible to view the downloaded data as a list. - For details about "RTR-61 Data Viewer" , see page from 117.
Page 105: Getting Remote Unit Info
- About the display before getting the current info: Because some settings can be made in the Remote Unit from the RTR-61 Unit itself, it may happen that the settings info in the computer and the settings written into the Remote Unit are different.
Page 106: Erasing Recorded Data
- Send Item Table - Send User Table - Send Operational Settings (When making changes to the recording mode) - Erase Recorded Data We suggest periodic downloading and saving of recorded data to the computer. How to use "RTR-61 for Windows"...
Page 107: Sending Messages
Drag and drop text file into the Window 1st line 2nd line 3rd line 4th line Check the notification method Select Remote Unit(s) [Send] Button Sends the message to the Remote Unit How to use "RTR-61 for Windows"...
Page 108: Remote Measurement Commands
During the period of time which has been set as the Measurement Command timeout, this interval is the amount of time between communications with the Remote Unit to check on its status, i.e. whether the measurement /recording request has been completed or not. How to use "RTR-61 for Windows"...
Page 109: Messages Shown During Communication Of A Measurement Command
Measurement Command By clicking [Send Command], a message will appear that a communication is currently in progress. [Communicating with XX.] When an RTR-61 unit receives a Measurement Command, the message displayed during communication will change. [Waiting for Remote Measurement Results.] The results of the remote measurement will be waited for during the time period set in [Measurement Command Timeout].
Page 110: Communication Results
[Result] column of the [Communication Log] Window. [Result] column [Success] Remote measuring and recording was successful during the time period [Failure] Remote measuring and recording failed or was not carried out within the time period How to use "RTR-61 for Windows"...
Page 111: Checking Data
It is possible to check the data recorded by a Remote Measurement Command. [Note] column [View Data List] Button This will open the "RTR-61 Data Viewer" . It is possible to view all data recorded by a Remote Measurement Command. [View Data List] Button RTR-61 DataViewer How to use "RTR-61 for Windows"...
Page 112: Data Files Recorded By Remote Measurement Command
The data measured and recorded by a Measurement Command will be automatically saved into a file entitled "RemoteRec.puw" in the same folder where "RTR-61 for Windows" was installed. - For details about opening an automatically saved data file, see page 130.
Page 113: Adjustment Function
. Place a check next to the desired unit of temperature. . Click the [Send] button to transmit the settings to the Remote Unit.A confirmation message will appear; if correct click the [OK] button. How to use "RTR-61 for Windows"...
Page 114: About Adjustment Methods
For example, the RTR-61 reads 0 C when the standard thermometer reads 0.1 C, and RTR-61 reads 10 C when the standard says the true measurement is 10.2 C. In this case the slope (a) is 10.2-0.4/10-0=0.98. The offset is 0.4, so the conversion equation...
Page 115 This clears any previous adjustment equation(s) and initializes the device. [Close] Button This closes the Settings Window. If the window is closed before the [Send] button has been clicked, the settings will not be completed. [Help] Button This displays the Help Menu. How to use "RTR-61 for Windows"...
Page 116 How to use "RTR-61 for Windows"...
Page 117: How To Use "Rtr-61 Data Viewer
5. How to Use "RTR-61 Data Viewer" After downloading recorded data to your computer, the downloaded data can be viewed by using "RTR-61 Data Viewer"...
Page 118: About The Display
About File Names Data File Names for Data Downloaded via Optical Communication [D/M/Y/ Hr/Min/Sec/.ext] Data File Names for Data Downloaded via Wireless Communication [Group Name_Remote Name_D/M/Y/Hr/Min/Sec/.ext] Data File Names for Data Downloaded by Remote Measurement Command [Remote Rec.puw] RTR-61 Data Viewer...
Page 119: Opening Saved Data
Opening Saved Data See the following procedures for opening a data file. The data file extension for data recorded by RTR-61 data loggers is ".puw" . Open files from the [File] Menu . In the [File] Menu, click [Open]. [File] Menu .
Page 120: Uploading Additional Data Files
Upon opening a data file, Remote Unit Info will appear for the Remote at the time when data was downloaded. When uploading an additional data file, the Remote Unit Info will become blank for contents which are not the same for all Remote Units currently in view. RTR-61 Data Viewer...
Page 121: [File] Menu
Text Data - The file format is text type (comma delimited) only. - The extension for the created file will be ".txt". - Data saved as text file cannot be read by "RTR-61 Data Viewer". RTR-61 Data Viwer...
Page 122: Print
[Print] Button The [Print] dialog box will appear and printing will begin. [Prev] / [Next] Buttons Preview the previous or next page. [Zoom Out] / [Zoom In] Buttons Zoom-in or out on data in the currently displayed page. RTR-61 Data Viewer...
Page 123 " U " or " L " will be displayed next to the value of the temperature measurement. Also, item(s) which were not selected in [View] - [Item View] will not be printed. (See page 125 for details) RTR-61 Data Viwer...
Page 124: [Edit] Menu
Hold down the <Shift> key to delete non-consecutive Remote Units to delete several consecutive sets of data. them. Either go to the [Edit] Menu or right click on one set of data. Then select [Delete Line of Choice] to delete the desired data. RTR-61 Data Viewer...
Page 125: [View] Menu
[View] Menu . Remove the check mark from item(s) you wish not to view. If you wish to select all items, right click on any item. . Click the [OK] button to refresh the Data Viewer display. RTR-61 Data Viwer...
Page 126: Changing Temperature Unit
There are three types of Date / Time display formats. [Month / Date / Year / Hour : Minutes' Seconds] [Date / Month / Year / Hour : Minutes' Seconds] [Year / Month / Date / Hour : Minutes' Seconds] RTR-61 Data Viewer...
Page 127: Changing The Display Widths
For easy viewing, it is possible to change the display area widths of the Data List and Remote Unit Info area. In the [View] Menu, select [Split] and drag the line which appears to the left or right. RTR-61 Data Viwer...
Page 128 RTR-61 Data Viewer...
Page 129: Others
6. Others...
Page 130: Recorded Data And Log Data
. The [Program Files] folder contains currently installed programs which have been saved to here. . Select the [RTR-61 for Windows (EU)] folder and open it. In the [RTR-61 for Windows (EU)] folder, the recorded data and communication log data will have already been saved.
Page 131: Troubleshooting
Troubleshooting Network Settings Utility The following message appears "Windows Security Alert", what should I do? If you are using Windows XP SP2 or higher / Vista / 7, the following message may be displayed. There is no problem, so please click [Unblock].
Page 132 Q.6 Because of some other [Communication Error] communication cannot occur. Why? One of the following may be the reason: - The IP Block setting is ON and communication can occur with only specific PC's. - If after several attempts a communication error continues to occur, turn OFF the RTR-5W and restart.
Page 133: Q&A
Q&A Q&A about RTR-5W Q.1 RTR-5W units use an AC adaptor, what happens when there is power shortage? During a power shortage the Web Server will not function and communication via LAN cannot occur. Q.2 Can I connect directly to my computer with the LAN cable that comes with the logger ? To connect a RTR-5W logger directly to your computer, you must use a cross LAN cable.
Page 134: Q&A About Networks
Q&A about Networks Q.1 What is a network ? A network is a system in which a group of computers are connected by cable (copper wire, optical fiber, etc), infrared ray, radio waves or other means in order to share and exchange information. There are basically two types of computer networks.
Page 135 An IP address is made up of the network address to which the computer belongs (network address) and the computer's own address within the network (host address). The Subnet mask determines the division between these. Network Address Host Address IP Address 255.
Page 136 Q.6 What is a port number ? When using TCP/IP communication with a LAN cable or via a phone line, port numbers are assigned to distinguish one application from another. Port numbers can be assigned from 0 to 65535. The numbers 0 to 1023 are already reserved to communication services and are referred to as "Well Known Port Numbers".
Page 137: Q&A About The Internet
Q&A about the Internet Q.1 What is a fixed IP address? Usually, when you connect to the Internet, the provider with which you have contracted service automatically assigns an IP address which may be different each time you connect, or may change after a certain length of time. With this type of changing IP address, it is more difficult for outsiders to illegally enter your computer.
Page 138 Q.4 I want to use a URL without a fixed IP address, how can I do that? If you wish to access an RTR-5W by URL but without a fixed IP address, it is possible to use a dynamic DNS. The DNS or Domain Name Server helps to switch difficult to understand IP address of just numbers, such as "61.197.203.107"...
Page 139: Q&A About Rtr-61 For Windows
- Also, it is possible to view the remaining battery level in the [Get Remote Unit Info] ( "Communication" Menu) in "RTR-61 for Windows" . (See page 99 for details) If the remaining battery level falls below 20%, please change the batteries.
Page 140 Q.2 The Remote Unit does not appear in the Remote Unit List. What should I do? The cause is probably because Registration Settings for the Remote Unit have not been properly made under "RTR-61 Registration". Please register the Remote Unit using "RTR-61 Registration". Q.3 The Remote Measurement Command cannot be sent. Why? A multiple number of Remote Units may have been selected and/or the gathering of an Item Table may have not been carried out by the Remote Unit.
Page 141: Specifications
Specifications Software "RTR-61 for Windows" Compatible Devices (Base Unit): RTR-50 (Wireless Communication Port) : Unit Version 2-1-x or above RTR-5W (Network and Wireless Station) : Internal Script Version 1.45 or above RF Version 1.4.x or above PC Operating Environment Microsoft Windows 7 32/64bit English...
Page 142: Rtr-61Sk
Optical Communication Adaptor (RTR-06A1) ,User's Manual * For the Push Wireless Communication Set "RTR-61SK" , it is impossible to use RTR-5 series data loggers in conjunction with the RTR-61. Please be fully aware of this before purchasing these products. Others...
Page 143: Rtr-61Sk
Optical Communication Adaptor (RTR-06A1) , User's Manual * For the Push Wireless Communication Set "RTR-61SK-W" , it is impossible to use RTR-5 series data loggers in conjunction with the RTR-61. Please be fully aware of this before purchasing these products. Others...
Page 144: Options
Options For RTR-50 (When used as a Repeater) AC-Adaptor(AD-0604) Cable Length:1.85m Input: AC AC 230V Output: DC 6V 50mA Frequency: 50Hz Plug Figure: C For RTR-5W AC-Adaptor(AD-05C1) Cable Length:1.6m Input: AC 100-240V Output:DC5V 2A Frequency:50/60Hz Plug Figure: C Wall Attachment : TR-5WK1 Double-sided Adhesive Tape x 1 Materials : Polycarbonate [Unit:mm]...
Page 145 For product information or questions contact us at Shimadachi 817-1, Matsumoto, Nagano 390-0852 JAPAN Tel: +81-263-40-0131 Fax: +81-263-40-3152 E-mail: support@tandd.com Website: http://www.tandd.com/ RTR-61 for Windows (EU) User's Manual RTR-5W Wireless and Network Station RTR-50 Wireless Communication Port © Copyright T&D Corporation. All rights reserved.
Page 146: Base Unit Warranty
Base Unit (RTR-50 / RTR-5W) Warranty Provisions for Free Repair RTR-50 RTR-5W The warranty is contained in the User’s Manual (English) included in the package. 1 year from date of purchase Guarantee Period When seeking repair, please make sure to fill in all required fields and present it. Date of Purchase If the Unit does not work properly despite the fact that the customer used it properly and in line with the manual, the Unit shall be repaired free of charge through the distributor which sold the...

T&D RTR-61 Instruction Manual

1 Getting Ready

3 RTR-61 Registration

4 How to Use "RTR-61 for Windows

5 How to Use "RTR-61 Data Viewer

6 Others

Quick Links

Need help?

Questions and answers

Related Manuals for T&D RTR-61

Summary of Contents for T&D RTR-61

Table of Contents
