Bit Rate
Radio Mode
Auth Type
Encryption & WEP keys/PSKs
Type of encryption (and decryption) used to protect transmitted data
Value:
None
No encryption
Manual WEP
WEP with up to four static keys, 40-bit or 128-bit in ASCII or hex
Auto WEP
WEP with key generated during EAP authentication
WPA PSK
TKIP with PSK, ASCII passphrase or hex PSK
WPA TKIP
TKIP with key generated during EAP authentication
WPA2 PSK
AES with PSK, ASCII passphrase or hex PSK
WPA2 AES
AES with key generated during EAP authentication
CCKM TKIP
TKIP with key generated during EAP authentication and with Cisco key
management protocol for fast re-authentication
CKIP manual
WEP with up to four static keys, 40-bit or 128-bit in ASCII or hex, plus
Cisco TKIP and/or Cisco MIC if configured on AP
CKIP Auto
WEP with key generated during EAP authentication, plus Cisco TKIP
and/or Cisco MIC if configured on AP
Default: None
EAP Type & Credentials
Extensible Authentication Protocol type used for 802.1X authentication to AP
Value:
None
LEAP
EAP-FAST
Bit rate used by the radio when interacting with AP; however, if a
specified bit rate is selected, the radio will not connect to an AP unless
the specified SSID is configured for only the selected bit rate.
Value: Auto (rate negotiated automatically with AP) or the specified
value in megabits per second (1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36,
48, 54
Default: Auto
Use of 802.11b and/or 802.11g when interacting with AP
Value: B rates only, BG rates full, G rates only, BG subset, Ad Hoc
Default: BG rates full
802.11 authentication type used when associating to AP
Value: Open, Shared (shared-key), LEAP (Network-EAP)
Default: Open
Credentials values for LEAP
User: Username or Domain\Username (up to 64 characters)
Password (up to 32 characters)
Credentials values for EAP-FAST
User: Username or Domain\Username (up to 64 characters)
Password (up to 32 characters)
Chapter 4
Using 802.11 Radio
69
