9300 Mobile Computer
Select Length
Code 93
Select Length
MSI
Verify Check Digit
Transmit Check Digit
Select Length
GS1 DataBar (RSS)
GS1 DataBar
Omnidirectional
(RSS-14)
GS1 DataBar Limited
(RSS Limited)
GS1 DataBar Expanded
(RSS Expanded)
Convert RSS to
UPC/EAN
EAN-8
Convert to EAN-13
Addon 2 / Addon 5
EAN-13
Bookland EAN (ISBN)
Addon 2 / Addon 5
UPC-A
136
Reference Manual
One or two fixed lengths
Range (1~55)
One or two fixed lengths
Range (1~55)
If Two Check Digits option is selected, an additional
verification is required to ensure integrity. Select one of
the algorithms below. If the check digit is incorrect, the
barcode will not be accepted.
Check Digit
One Check Digit
Two Check Digits
Decide whether to include the check digit in the data being
transmitted.
One or two fixed lengths
Range (1~55)
"Convert to UPC/EAN" only applies to RSS-14 and RSS
Limited barcodes not decoded as part of a Composite
barcode.
Convert to EAN-13
Strip the leading "010" from barcodes.
"01" is the Application ID and must be followed by a
single zero (the first digit encoded)
Convert to UPC-A
Strip the leading "0100" from barcodes.
"01" is the Application ID and must be followed by
two or more zeros (but not six zeros)
The EAN-8 barcode will be expanded into EAN-13, and the
next processing will follow the settings configured for
EAN-13.
Refer to UPC/EAN Addon setting.
The EAN-13 barcode starting with 978 will be converted to
ISBN.
Refer to UPC/EAN Addon setting.
Algorithm
Single Modulo 10
Mod 10/Mod 11
Mod 10/Mod 10
4~55
Enable
4~55
Enable
Single Modulo
10
No
4~55
---
Enable
Enable
Enable
No
Enable
No
Enable
Yes
Enable
