2D IMAGER

READER SETTINGS TABLE

The tables below list reader settings as well as symbology settings for the 2D scan
engine.
2D
Decode Time-out
Decode Illumination
Aiming Pattern
Redundancy Level
Level 1
Level 2
Level 3
Description
Set the maximum time for decoding to continue during a
scan attempt.
1~9 (second) for ReaderConfig.exe – default to 3
5~99 (0.1 second) for programming – default to 30
Decide whether to flash illumination on every barcode
capture to aid decoding.
Turn On (Internal LED )
Turn Off
Decide whether to project the aiming pattern during
barcode capture.
Turn On
Turn Off
The following barcodes must be successfully read twice before being
decoded:
Barcode Types
Codabar
MSI
Industrial 25 (Discrete 25)
Interleaved 25
All barcodes must be successfully read twice before being decoded.
All barcodes except for the following barcodes must be successfully read
twice before being decoded.
The following barcodes must be read three times:
Barcode Types "Excluded"
Codabar
MSI
Industrial 25 (Discrete 25)
Interleaved 25
Appendix III
Code Length
8 characters or less
4 characters or less
8 characters or less
8 characters or less
Code Length
8 characters or less
4 characters or less
8 characters or less
8 characters or less
Default
3 sec.
On
On
Level 1
133
