Pr. Explanation
V/f Curve Selection
00-11
Constant/Variable Torque
00-12
Selection
Optimal
Acceleration/Deceleration
00-13
Setting
Time Unit for
Acceleration/Deceleration
00-14
and S Curve
00-15 Reserved
00-16 Reserved
00-17 Carrier Frequency
Auto Voltage Regulation
00-18
(AVR) Function
Auto Energy-saving
00-19
Operation
Source of the Master
00-20
Frequency Command
Source of the Operation
00-21
Command
00-22 Stop Method
00-23 Motor Direction Control
Settings
0: V/f curve determined by group 01
1: 1.5 power curve
2: Square curve
0: Constant Torque (150%)
1: Variable Torque (120%)
0: Linear accel./decel. I
1: Auto accel., linear decel.
2: Linear accel., auto decel.
3: Auto accel./decel. (auto calculate the accel./decel.
time by actual load)
4: Stall prevention by auto accel./decel. (limited by 01-12
to 01-21)
0: Unit: 0.01 second
1: Unit: 0.1 second
1~15KHz
0: Enable AVR
1: Disable AVR
2: Disable AVR when deceleration stop
0: Disable
1: Enable
0: Digital keypad (KPV-CE01)
1: RS-485 serial communication
2: External analog input (Pr. 03-00)
3: External UP/DOWN terminal
4: Pulse input without direction command (Pr.10-15
without direction)
5: Pulse input with direction command (Pr.10-15)
0: Digital keypad (KPV-CE01)
1: External terminals. Keypad STOP disabled.
2: RS-485 serial communication (RJ-11). Keypad STOP
disabled.
0: Ramp to stop
1: Coast to stop
0: Enable forward/reverse
1: Disable reverse
2: Disable forward
Chapter 4 Parameters
Factory
VF VFPG SVC FOCPG TQCPG
Setting
0
○ ○
0
○ ○ ○
0
○ ○ ○
0
○ ○ ○
10
○ ○ ○
0
○ ○ ○
0
○ ○ ○
0
○ ○ ○
0
○ ○ ○
0
○ ○ ○
0
○ ○ ○
○
○
○
○ ○
○ ○
○
○
○ ○
○ ○
○ ○
4-3
