Removing And Installing Body Panels; Front Cover - CanyCom CMX 227 Operator's Manual

5
Item
Electrical System
Battery
Fuse, 30A (Green, Main)
Fuse 10A (Red, Lights)
Light Bulb (Head Lamp)
Light Bulb (Tail Lamp)*1

Removing and Installing Body Panels

• Cut or pinch hazard exists when removing or installing body panels; beware of
sharp edges and pinch points.
• Make certain to reinstall panels after removing for repairs or inspection.

Front Cover

Latch
5332M-0401-040E
5332M-0401-110E
Maintenance
Part No.
37053901000
09801003002
09801001002
53320203100
09808121502
1.
Front Cover
2.
NOTE
• Tool box is provided under the front cover.
Schedule
Replace if defective.
Replace if defective.
Replace if defective.
Replace if defective.
Replace if defective.
Pull top side of front cover to unlock latch.
Pull up front cover.
Use this tool box to store tools or substitute
cutting blades.
-50-
Qty.
1
1
1
1
1
