Removing and Installing Body Panels

• Cut or pinch hazard exists when removing or installing body panels; beware of
sharp edges and pinch points.
• Make certain to reinstall panels after removing for repairs or inspection.

Front Cover

Latch
5347M-0401-040E
5347M-0401-110E
Front Cover
5332M-0401-140E
Maintenance
1.
Front Cover
2.
NOTE
• Tool box is provided under the front cover.
3.
Clip
4.
NOTE
• Beware not to catch front cover by the
Rod
-49-
Pull top side of front cover to unlock latch.
Pull up front cover.
Use this tool box to store tools or substitute
cutting blades.
Raise steering wheel to the maximum angle
and fit clip on the back of front cover to rods.
Fit upper part of front cover.
plates on both sides when you installing
front cover.
5
