Interior view
2
3
1.
Ribbon rewind hub
2.
Ribbon rewind gear
3.
Gap sensor (receiver)
4.
Media holder
5.
Media holder locking switch
6.
Gap sensor (transmitter)
7.
Print head
1
4
5
7
8
9
6
8.
Ribbon supply hub
9.
Top cover support
10.
Media guide adjustment button
11.
Media guides
12.
Black mark sensor
13.
Platen roller
