Menu Tree - Omron Programmable Terminals NT31 NT31C Setup Manual

Operation Modes and the System Menu

6-3-2 Menu Tree

SYSTEM INSTALLER MODE
Exit System Installer
Download System Program (page 151)
Change System Settings (page 153)
Erase Screen Data (page 154)
SYSTEM MENU
Quit
Transmit Mode (page 155)
Maintenance Mode
Expansion Mode
EXPANSION
MODE MENU
Quit
Programming Console Function (page 221)
Version Display (page 230)
Device Monitor Function (page 227)
The System Menu allows the various functions of the NT31/NT31C to be
executed by using touch switches displayed on the touch panel. The menu tree,
starting from the System Menu, is shown below.
For details on System Menu operations, refer to 6-3-3 Operations with the Sys-
tem Menu (page 138).
The menu tree may differ according to the system program installed in the
NT31/NT31C. The menu tree for the system program that is installed in the
NT31/NT31C on shipment is shown below.
MEMORY INIT. MENU
MAINTENANCE
MODE MENU
Quit
Memory Init.
Memory Switch
I/O Settings
Calendar Check (page 195)
PT Settings (page 197)
Display History
Alarm History
Screen Data Disp. (page 202)
I/O Check
I/O CHECK MENU
Quit
I/F Check
Device Check
I/F CHECK MENU
Quit
Tool Comm. (page 215)
Comm. Port A (page 217)
Comm. Port B (page 217)
Printer (page 220)
DEVICE CHECK MENU
Quit
Buzzer Check (page 205)
LED Check (page 206)
LCD Check (page 208)
Backlight Check (page 209)
Screen Memory (page 209)
Touch Switch (page 212)
Battery (page 214)
Quit
Screen Data (page 140)
Display History (page 142)
Alarm History (page 144)
Recipe Table (page 145)
Memory Table (page 147)
Memory Switch (page 149)
DISPLAY HISTORY MENU
Section
MEMORY
SWITCH MENU
Start-up Wait Time (page 169)
Key Press Sound (page 170)
Buzzer Sound (page 171)
Printer Controller (page 172)
Print Method (page 174)
Screen Saver Movement (page 175)
Screen Saver Start up Time (page 177)
Hist. Disp. Method (page 179)
Resume Function (page 181)
Comm. Auto-return (page 183)
Time-out Interval (page 185)
Retry Counts (page 186)
Comm. A Method (page 157)
Comm. B Select (page 167)
Comm. B Method (page 157)
I/O SETTINGS MENU
Quit
Contrast Adjust (page 191)
Brightness Adjust (page 193)
Quit
Sort by Occurrence (page 198)
Sort by Frequency (page 198)
ALARM HISTORY MENU
Quit
Sort by Occurrence (page 200)
Sort by Frequency (page 200)
