Before Operating

1-6

Before Operating

Host
Set the host settings.
• For the host link, refer to
pages 54 and 101, and
the manuals for the host
link unit and peripheral
tools.
• For the NT link (1:1), refer
to pages 67 and 111.
• For the NT link (1:N), re-
fer to pages 72 and 113.
• For the high-speed NT
link (1:N), refer to pages
75 and 115.
• For the Memory link, refer
to pages 72 and 116
Connect to the
NT31/NT31C.
Create the host program.
Reference:
Device or Software
NT31/NT31C,
NT631/NT631C
System Installer
Support Tool
22
Follow the procedure given below to start the system of the NT31/NT31C.
NT31/NT31C
Install the PT in the
operation panel.
(page 32)
Connect the power supply.
(page 33)
Install the system program.
(refer to page 151 and the
Support Tool manual)
Make the settings in the
system installer mode.
(page 151)
Transmit the screen data.
Set the memory switches.
(page 157)
Connect to the host.
When RS-232C used at the PT: refer to section 4
When RS-422A/485 used at the PT: refer to section 5
Confirm the settings and
check communication.
Start operation.
*1: System program installation is only done in special circumstances, for example
when changing the system program, or to recover the original status of the
installed program. This operation is not normally necessary. When using other PC
models (sequencers), however, it is necessary to install specific system programs.
*2: Display of the system menu, and all change operations, can be inhibited. This
enables you to prevent the accidental deletion or alteration of screens and
settings.
S For the system program, use the NT31/NT31C system program supplied as
an accessory with the NT-series Support Tool (NT-ZJCAT1-EV4).
S For the Support Tool, use NT-series Support Tool for Windows (Ver. 4.1).
Refer to the following manuals for the devices and software.
Reference Manual
NT-series Support Tool for Windows (Ver. 4.1) Operation Manual
NT-series Support Tool for Windows (Ver. 4.1) Operation Manual
Support Tool
Install the Support
Tool at the computer.
(refer to the manual for
the Support Tool)
*1
Create the screens.
*2
(Refer to the NT31/NT31C/NT631/NT631C
Programmable Terminal Reference Manual
and the Support Tool Operation Manual.)
(page 155)
Manual Title
Section 1-6
Manual
Number
V064-E1-1
V061-E1-j
V061-E1-j
