Connecting to the RS-232C Port at the Host
66
CS1 series CPU type : CS1G/H-CPUjj-E (-V1)
Connect to the built-in RS-232C port of the CPU, or the RS-232C port of the
communication board. Note that the connection to a peripheral port must be
made via an RS-232C adapter (CS1W-CN118) specially designed for connect-
ing to a peripheral port.
PC Setup
When connecting to a CS1 series CPU, set the following communication condi-
tions for the PC Setup area. Since the settings shown below are the PC default
settings for the CPU, no change to the PC Setup is necessary as long as the
communication speed is maintained at 9600 bps.
Item
Communication speed
Stop bits
Parity
Data length
Unit No. for the host link
*1 Set the host link communications speed at 9600 bps or 19200 bps with the
memory switch at the NT31/NT31C. For details, refer to Settings the Host Link
Method (page 160). When the communication speed is set to 19200 bps, the PC
Setup of the CPU need to be changed.
Either set the PC Setup directly from a Programming Device (Programming
Console), or transmit the PC Setup made at a Programming Device (CX-Pro-
grammer) to the CPU.
For details on PC Setup, refer to the SYSMAC CS1-series Operation Manual
(W339-E1-j).
When using the built-in RS-232C port of CS1G/H
Word # Writing Value
160 8000
0000
161 161
0007
166 0000
When using the peripheral port of CS1G/H
Word # Writing Value
144 8000
0000
145 145
0007
150 0000
Setting at Host
Set the same speed as set at the NT31/NT31C(*1)
2 stop bits
Even
ASCII 7 bits
00
Host link mode, data length 7 bits,
2 stop bits, even parity
Communication speed: 9600 bps.
Communication speed: 19200 bps.
Unit #00
Host link mode, data length 7 bits,
2 stop bits, even parity
Communication speed: 9600 bps.
Communication speed: 19200 bps.
Unit #00
Section 4-1
Settings
Settings
