Page 1 Cat. No. V062-E1-04 NT31 and NT31C Programmable Terminals Setup Manual...
Page 2 NT31 and NT31C Programmable Terminals Setup Manual Revised September 2007...
Page 4 OMRON. No patent liability is assumed with respect to the use of the information contained herein. Moreover, because OMRON is con- stantly striving to improve its high-quality products, the information contained in this manual is subject to change without notice.
Page 6: Table Of Contents
Role and Operation of the NT31/NT31C ........
Page 7 Transporting and Storing the NT31/NT31C ........
Page 8: About This Manual
About this Manual: This manual describes connecting the NT-series NT31 and NT31C Programmable Terminals to a PLC (Programmable Controller) or other host and peripheral devices and the settings required for communi- cations and applications. It includes the sections described below.
Page 9 This manual describes connecting the Programmable Terminals to a host and peripheral devices and settings required for communications and applications. The functions and actual operating methods for the NT31 and NT31C PTs are provided in the Refer- ence Manual (V064-E1-@).
Page 10 WHETHER SUCH CLAIM IS BASED ON CONTRACT, WARRANTY, NEGLIGENCE, OR STRICT LIABILITY. In no event shall the responsibility of OMRON for any act exceed the individual price of the product on which liability is asserted. IN NO EVENT SHALL OMRON BE RESPONSIBLE FOR WARRANTY, REPAIR, OR OTHER CLAIMS...
Page 11 Application Considerations SUITABILITY FOR USE OMRON shall not be responsible for conformity with any standards, codes, or regulations that apply to the combination of products in the customer's application or use of the products. At the customer's request, OMRON will provide applicable third party certification documents identifying ratings and limitations of use that apply to the products.
Page 12 Performance data given in this manual is provided as a guide for the user in determining suitability and does not constitute a warranty. It may represent the result of OMRON's test conditions, and the users must correlate it to actual application requirements. Actual performance is subject to the OMRON Warranty and Limitations of Liability.
Page 14: Precautions
PRECAUTIONS This section provides general precautions for using the Programmable Terminal. The information contained in this section is important for the safe and reliable application of the Programmable Terminal. You must read this section and understand the information contained before attempting to set up or operate a Programmable Terminal.
Page 15: Intended Audience
Safety Conventions and Their Meanings This operation manual uses the following conventions and symbols to indicate cautions, warnings, and dangers in order to ensure safe use of the NT31/31C. The cautions, warnings, and dangers shown here contain important informa- tion related to safety. The instructions in these cautions, warnings, and dan- gers must be observed.
Page 16 Doing either of these may result in electrical shock. WARNING Switch OFF the NT31/NT31C power before replacing the backlight. Otherwise you could sustain an electric shock. CAUTION Do not touch the backlight immediately after switching OFF the power supply.
Page 17 Safety Precautions xviii...
Page 18: General
Operations of the NT31/NT31C ......Functions of the NT31/NT31C........
Page 19: Role And Operation Of The Nt31/Nt31C
2. Position of dog M2 3. Mounting of photosensor P5 Panel Switch Functions Setting touch switches on the NT31/NT31C allows workers to use the NT31/ NT31C as an operating panel; the results of the operations are transmitted to the host.
Page 20: Operations Of The Nt31/Nt31C
Receives Data from a Host The NT31/NT31C can be connected to the host by a host link or NT link and receive necessary data from the host. Host link, NT link...
Page 21: Functions Of The Nt31/Nt31C
*When mounted in a panel of the recommended thickness (page 30). Construction Best Suited • The panel is an STN monochrome LCD type with backlight for the NT31 to the FA Environment and an STN color LCD type with backlight for the NT31C.
Page 22 Functions of the NT31/NT31C Rapid System Program & Screen Data Changes Possible Using a Memory Unit • Installing a Memory Unit (model NT-MF261) on the rear of the NT31/ NT31C makes it easy to write screen data into the NT31/NT31C on site.
Page 23: Comparison Between Nt31 And Nt31C
1-2-2 Comparison between NT31 and NT31C Two NT31 models — the NT31, which is capable of versatile graphic displays, and the NT31C, which is also capable of color display — are available. The differences between the NT31 and NT31C are tabled below:...
Page 24: Section
This is the capacity of the flash memory that stores screen data. The values are the same as the NT30/NT30C when the PT is in NT30/620 compatible mode. For differences in programming, refer to Appendix B in the NT31/NT31C/NT631/NT631C Programmable Termi- nal Reference Manual.
Page 25: Principal Functions Of Nt31/Nt31C
Functions of the NT31/NT31C 1-2-4 Principal Functions of NT31/NT31C The following are the principal functions of the NT31/NT31C. Functions relating to data display Character display Characters of various sizes can be displayed. Characters can be flashed and displayed in reverse video.
Page 26: Recipe Function
Communications with the host The NT31/NT31C can communicate with the host by four methods: host link, 1:1 NT Link, 1:N NT link (standard or high-speed), and Memory link. Data can be read from the host, and data input by means of touch switches and numeral/character string settings can be sent to the host.
Page 27: Displays
The NT31/NT31C can display various kinds of elements such as characters, numeric values, graphs, lamps, and touch switches, on a screen. The screen data displayed by the NT31/NT31C are created by using the Support Tool at a personal computer. Characters...
Page 28 Functions of the NT31/NT31C Section 1-2 Mark Image data Library data Lamps These are graphics whose display status changes in accordance with the states of bits at the host. Squares, circles, sectors and polygons can be used for lamps (normal (standard) lamps). In accordance with the status of the host bit, they can be lit (displayed in reverse video) or flashed (repeated alternation between normal and reverse video display states).
Page 29 Functions of the NT31/NT31C Section 1-2 The following 8 types of display graphic can be used for touch switches: Stan- dard, shadow, 3-dimension, no display frame, rectangle, circle, polygon, sec- When rectangle, circle, polygon, or sector is selected as the shape, the area within which pressing of the touch switch is sensed (the touch switch area) can be set independently of the position where the display graphic is set.
Page 30 Section 1-2 Functions of the NT31/NT31C Thumbwheel Switches Numeric values can be input by incrementing or decrementing each digit with the corresponding touch switch (+, –). The input numeric values can also be stored in a numeral memory table and notification sent to the host.
Page 31 ON are recorded and displayed together with the message (character string) set for the bit memory table. The NT31/NT31C allows selection of the display order as the newest record first or the oldest record first by memory switch setting.
Page 32: System Configuration
Section 1-3 System Configuration System Configuration This section shows the configuration of a system that uses an NT31/NT31C. For details on product models, refer to Appendix J Model List. 1-3-1 Peripheral Devices That Can Be Connected The following peripheral devices can be connected to an NT31/NT31C.
Page 33: Communications With The Host
(1:1) communications method, RS-485 cannot be used. The connection must be made with RS-232C or RS-422A. Communications with the Host The NT31/NT31C is connected to the host by one of the following communi- cations methods. The following communications can be used to connect an OMRON PLC: •...
Page 34: Host Link
PLC memory. • Since the NT31/NT31C can directly refer to PLC bit and word data without using the program at the PLC, it can be connected to the PLC without changing the PLC program which controls the currently running produc- tion line.
Page 35 NT31/NT31C switches to the monitor mode when the PLC is in the RUN mode.) • In the case of PTs that support the standard 1:N NT Link (NT20S, NT31, NT31C, NT600S, NT620S, NT620C, NT625C, NT631, NT631C) up to 8 PTs can be connected to one port of the PLC and used at the same time.
Page 36: Communications Using Memory Links
In memory link, there is an area called PT Memory, as shown below, inside the NT31/NT31C, and this area is treated as a virtual area on the PLC. This allows PT memory and the display elements of the NT31/NT31C to make a quasi-direct connection.
Page 37: Comparison Between Direct Connection And Memory Link
RS-232C/422A communications In the memory link method, the only difference is that the NT31/NT31C finds its communications target inside instead of outside. In the memory link method, therefore, change of the target is all that is needed to be capable of using the exact screen data that is acquired by the direct connection.
Page 38: Before Operating
For more details on the memory link online transfer function, refer to informa- tion on the memory link online transfer function in the NT31/NT31C/NT631/ NT631C Programmable Terminal Reference Manual. Before Operating Follow the procedure given below to start the system of the NT31/NT31C. Host Support Tool NT31/NT31C Set the host settings.
Page 39 Before Operating Section 1-6 Refer to the following manuals for the devices and software. Device or Software Manual Title Manual Number NT31/NT31C, NT631/ Reference Manual V064-E1-1 NT631C System Installer NT-series Support Tool for Windows (Ver. 4.@) Operation Manual V061-E1-05 Support Tool NT-series Support Tool for Windows (Ver.
Page 40: Preparing For Connection
SECTION 2 Preparing for Connection This section describes the connection methods that are possible with the PTs, and the functions of the parts of PTs, as the required knowledge before connecting to the host and to the peripheral devices. Method for Connection to the Host ....... . Names and Functions of Parts .
Page 41: Method For Connection To The Host
This section describes the methods for connection to the host used with the NT31/NT31C, and the relationship between the connection method and the communications method. NT31/NT31C Communications Ports and Communications Methods The NT31/NT31C has two communications ports. Their uses are indicated in the table below. Communications Usable communications methods...
Page 42 Combinations of Communications Method and Connection Method The connection methods that can be used depending on the communications method used and the communications type for communications between the NT31/NT31C and the host are indicated in the table below. Commu- Communi-...
Page 43 6 of the RS-232C connector. Check the signals of the RS-232C connector at the host. • +5 V is not output from serial port B of the NT31/NT31C. When connect- ing an NT-AL001 at serial port B, a separate power supply is required for the NT-AL001.
Page 44: Names And Functions Of Parts
Names and Functions of Parts Section 2-2 Names and Functions of Parts Before starting operation, the names and functions of the parts of the NT31/ NT31C are described here as a confirmation. A method of hardware settings is also described.
Page 45 Serial port B connector Connect the cable for connection to the host here. Depending on the setting made at the NT31/NT31C system menu, either RS-232C or RS-422A/485 may be used. This is a 25-pin connector. It is not possible to use RS-232C and RS-422A/485 at the same time.
Page 46: Hardware Settings And Connections
SECTION 3 Hardware Settings and Connections This section describes the settings of the PTs and methods for connection to peripheral devices. For details on connecting to the host, refer SECTION 4 Connecting to the Host from the RS-232C Port or SECTION 5 Connecting to the Host from the RS-422A/485 Port.
Page 47: Installation
Also confirm that there is no abnormal noise on shaking the PT lightly. Installation Install the NT31/NT31C in the operation panel and connect the power to the NT31/NT31C as described below. 3-1-1 Installation Environment Observe the following points when installing the PT in an operation panel.
Page 48: Power Supply Connection
0.5 to 0.6 N ⋅ m in order to ensure water- and dust-resistance. Front sheet of NT31/NT31C may be warped if the tightening is too strong or not uniformity. The panel must not be soiled or warped, and must be able to support an installation that will remain secure and strong.
Page 49: Grounding
( of the NT31/NT31C. 2. If the NT31/NT31C is installed in the same panel as equipment that gen- erates noise, such as a motor or inverter, do not ground the functional ground terminal ( ) of the NT31/NT31C.
Page 50: Connecting To The Support Tool
The NT31/NT31C connects the RS-232C cable from a personal computer at serial port A. When the host is connected at serial port B, the connection with the host can be maintained as it is while the NT31/NT31C is connected to the RS-232C cable from a personal computer.
Page 51: Connecting A Printer
The length of the cable should not exceed 1.5 m. Reference: If the connector cable is connected or disconnected while the power to the printer is on, the NT31/NT31C may malfunction. Always turn off the power to the printer before connecting or disconnecting the cable. PRINTER...
Page 52: Connection Method
Section 3-4 Connecting a Bar Code Reader 3-4-1 Connection Method Connect the bar code reader to serial port A of the NT31/NT31C, as shown in the figure below. NT31/NT31C Bar code reader PRINTER PORT B PORT A Serial port A...
Page 53: Using A Memory Unit
During bar code reading, the NT31/NT31C performs RS/CS control. When the Input Method setting of the NT31/NT31C is set to Auto, the RS signal is turned OFF, prohibiting the next input, until the read data has been sent to the host as notification.
Page 54: Installation Method
Memory Unit. After mounting a Memory Unit, be sure to tighten its two screws. 2. During data transmission, do not turn off the power supply to the NT31/ NT31C or reset it. 3. Do not touch the PCB (printed circuit board) with bare hands.
Page 55: Method Of Use
Factory setting is turned all to off. Note 1. Always confirm that the power to the NT31/NT31C is off before setting the DIP switches. 2. Do not touch the PCB (printed circuit board) directly with bare hands. DIP Switch Functions The functions of the DIP switches on the Memory Unit are indicated in the table below.
Page 56 Use the following procedure to write the screen data in the NT31/NT31C to the Memory Unit by automatic transmission. 1,2,3... 1. Check that the power supply to the NT31/NT31C is OFF, then set the DIP switches of the Memory Unit as follows after installing Memory Unit to NT31/NT31C.
Page 57 NT31/NT31C, this mode becomes convenient. Reference: When data is written to the NT31/NT31C, the data that has been stored up until that point is lost. When the system program is changed, the operation of NT31/ NT31C also changes.
Page 58 NT31/NT31C. Transmission can be executed while checking the settings. Reference: When data is written to the NT31/NT31C or Memory Unit, the data that has been stored up until that point is lost. Method of Execution Use the following procedure to write screen data using manual transmission.
Page 59 (The second line may not be displayed in the kind of system program.) Current PT Screen Data, Screen The comment for the screen data in the NT31/NT31C is displayed here. Current Memory Unit Screen Data • In the case of system program:...
Page 60 Section 3-5 Using a Memory Unit • When writing the system program into the NT31/NT31C, the type of sys- tem program inside Memory Unit and the type of PT must correspond. 4. Press Execute. The data is transmitted. The messages Preparing, Transmitting, Verifying, and Finished are dis- played in accordance with the progress of data transmission.
Page 61 Error Probable Cause Remedial Action Flash memory error An error occurred during Turn the NT31/NT31C power OFF, initialization of the NT31/ then back ON. If the error recurs, NT31C or Memory Unit the flash memory at the write desti- flash memory, or during nation may be faulty.
Page 62: Connecting To The Host From The Rs-232C Port
SECTION 4 Connecting to the Host from the RS-232C Port This section describes the method for connecting to the host using the RS-232C port of the PT. Connecting to the RS-232C Port at the Host ......4-1-1 Host Types and Settings .
Page 63: Connecting To The Rs-232C Port At The Host
Direct Connection Between The RS-232C Ports Using an RS-232C Cable (page 73) This is the easiest connection method. Depending on the host to which the connection is to be made, it may be possible to use OMRON cables with con- nectors. NT31/NT31C Host RS-232C cable (max.
Page 64 Connecting to the RS-232C Port at the Host Section 4-1 The Units that can be connected to the NT31/NT31C by the host link method using the RS-232C ports of both Units are indicated in the table below. Units with Built-in Host Link...
Page 65 Unit # Set the host link communications speed at 9600 bps or 19200 bps with the memory switch at the NT31/NT31C. For details, refer to 6-7-2 Setting the Host Link Method (page 161). The 1-to-N setting enables BCC (Block Check Character). It is not actually possible to connect more than one NT31/NT31C in a single host link.
Page 66 Section 4-1 Connecting to the RS-232C Port at the Host LK201 ERROR • Unit # (SW1, SW2) Set these switches to 0. • Instruction level, parity, and transfer code (SW4) Set this switch to 2. • Communications speed (SW3) Set this switch to 5 to select 9600 bps. Set this switch to 6 to select 19200 bps.
Page 67 Section 4-1 Connecting to the RS-232C Port at the Host Setting the Rear Switches • I/O port selection (selector switch) Set this to RS-232C. I/O port • Unit # (DIP SW1) RS-422A Set SW1-1 to SW1-5 to OFF (0). RS-232C Synchronization Internal External...
Page 68 Section 4-1 Connecting to the RS-232C Port at the Host C1000H/C2000H Rack-mounting Unit: C500-LK203 Setting the Rear Switches • I/O port selection (selector switch) Set this to RS-232C. 5 V supply • Unit #, parity, and transfer code (DIP SW1-1 to SW1-7) I/O port Set SW1-1 to SW1-7 to OFF (0).
Page 69 A CVM1/CV series Host Link Unit (CV500-LK201) has two connectors (com- munications ports 1 and 2). Either of these ports can be used for connection to an NT31/NT31C by the RS-232C method. However, since the connectors at these ports are of different types, a cable that matches the connector must be prepared.
Page 70 Stop bit 2 stop bits Parity Even Data length ASCII 7 bits Unit # Set the host link communications speed at 9600 bps or 19200 bps with the memory switch at the NT31/NT31C. For details, refer to 6-7-2 Setting the Host...
Page 71 Section 4-1 Connecting to the RS-232C Port at the Host Link Method (page 161). Either set PLC Setup directly from a Programming Device (e.g. SYSMAC sup- port software), or transmit the PLC Setup made at a Programming Device to the CPU Unit. For details on the PLC Setup, refer to the SYSMAC CVM1/CV500/1000/2000 Operation Manual: Ladder Diagrams (W202-E1-@).
Page 72 Unit # Set the host link communications speed at 9600 bps or 19200 bps with the memory switch at the NT31/NT31C. For details, refer to 6-7-2 Setting the Host Link Method (page 161). Set the PLC Setup area settings directly from a Programming Device (e.g. the CX-Programmer support software).
Page 73 Section 4-1 Connecting to the RS-232C Port at the Host Word # Writing Value Settings DM6646 0303 Data length 7 bits, 2 stop bits, even parity, communica- tions speed: 9600 bps 0304 Data length 7 bits, 2 stop bits, even parity, communica- tions speed: 19200 bps DM6648 0000...
Page 74 Section 4-1 Connecting to the RS-232C Port at the Host Peripheral port CPM2C-CN111 CPM2C CS1W-CN118 CPM2C CPM2C CS1W-CN114 RS-232C port Peripheral port RS-232C port (D-Sub 9-pin, female) (D-Sub 9-pin, female) Setting the DIP Switches of a C200HX/HG/HE(-Z)E, CQM1, or CQM1H When using a C200HX/HG/HE(-Z)E, CQM1, or CQM1H, the DIP switches on the front panel must be set as shown below in order to make the settings in the PLC Setup area (data memory) effective.
Page 75 Unit No. for the host link Set the host link communications speed at 9600 bps or 19200 bps with the memory switch at the NT31/NT31C. For details, refer to 6-7-2 Setting the Host Link Method (page 161). When the communications speed is set to...
Page 76 Communications speed: 19200 bps. 0000 Unit #00 Setting the Front Switches Set the CPU Unit’s DIP switches to 4 or 5 in accordance with the port NT31/ NT31C is connected to. An example of a CS-series CPU Unit is shown below. ERR/ALM PRPHL/COMM...
Page 77 Section 4-1 Connecting to the RS-232C Port at the Host Allocation DM Area Settings for CPU Unit Settings are written from the Programming Device (a Programming Console or CX-Programmer) directly into the allocation DM area (system setting area) of the CPU Unit. After the settings are written, they become effective by turn- ing the power ON, restarting the Unit, restarting the communications port, or execution of the STUP command.
Page 78 Check the model and series of the PLC against the type of CPU Unit before making the connections. The Units that can be connected to the NT31/NT31C by the NT link (1:1) method using the RS-232C ports of both Units are indicated in the table below.
Page 79 Section 4-1 Connecting to the RS-232C Port at the Host One of the following Communications Boards is required: C200HW- COM02/COM04/COM05/COM06-EV1. A CPM1-CIF01 adapter is required. Use a CPM2C-CN111 or CS1W-CN114/118 Connecting Cable, CPM1- CIF01 RS-232C Adapter, or CPM1-CIF11 RS-422A Adapter to connect. A CQM1H-SCB41 Serial Communications Board is required.
Page 80 Section 4-1 Connecting to the RS-232C Port at the Host Peripheral port CPM2C-CN111 CPM2C CS1W-CN118 CPM2C CPM2C CS1W-CN114 RS-232C port Peripheral port (D-Sub 9-pin, female) RS-232C port (D-Sub 9-pin, female) Setting the DIP Switches on the Front of a C200HX/HG/HE(-Z)E, CQM1, CQM1H When using a C200HX/HG/HE(-Z)E, CQM1, or CQM1H, the DIP switches on the front panel must be set as shown below in order to make the settings in...
Page 81 Compatible Host Units Method The only OMRON PLCs that can be connected using the NT link (1:N) method are the CS/CJ-series CPU Units and the C-series C200HX/HG/HE(- Z)E, CQM1H, and SRM1. With the CS/CJ-series PLCs, it is also possible to connect a 1:N NT Link using a Serial Communications Board (CS Series only) or Serial Communications Unit.
Page 82 Check the model and series of the PLC as well as the model of Serial Com- munications Board or Unit being used before making the connections. The Units that can be connected to the NT31/NT31C by the NT link (1:N) method using the RS-232C ports of both Units are indicated in the table below.
Page 83 Section 4-1 Connecting to the RS-232C Port at the Host One of the following Communications Boards is required: C200HW-COM02/COM04/COM05/COM06-E(V1) A CQM1H-SCB41 Serial Communications Board is required. Reference: With version 1 (-V1) and high-speed versions (H) of the CS-series CPU Units and any versions of the CJ-series CPU Units, the high-speed 1:N NT Link method can be used as well as the standard 1:N NT Link method.
Page 84 (W339) or the SYSMAC CJ Series Operation Manual (W393). Setting the Front Switches Set the CPU Unit’s DIP switch to 4 or 5 in accordance with the port NT31/ NT31C is connected to. An example of a CS-series CPU Unit is shown below.
Page 85 This is used mainly for accordance with PLC Setup) when connecting connection to the MCPWR BUSY the NT31/NT31C to the peripheral port. Programming Device. OPEN • Set SW5 to OFF (establishing communications (This also supports the RS- in accordance with PLC Setup) when 232C unit connection.)
Page 86 Section 4-1 Connecting to the RS-232C Port at the Host Setting the Front Switches Set the unit number of the Serial Communications Unit by using the rotary switch located on the front panel. Set each switch with a flat blade screwdriver so that the values or symbols in the setting value window agree with the fol- lowing.
Page 87 Section 4-1 Connecting to the RS-232C Port at the Host The following table shows which CS-series PLCs can be connected to an NT31/NT31C with the high-speed 1:N NT Link. PLC Series CPU Units with Built-in CPU Units Connectable with Connect-...
Page 88 115,200 bps. Setting the Front Switches Set the CPU Unit’s DIP switch to 4 or 5 in accordance with the port NT31/ NT31C is connected to. An example of a CS-series CPU Unit is shown below.
Page 89 Connecting to the RS-232C Port at the Host Section 4-1 Allocated DM Area words Setting Setting Contents Port 1 Port 2 DM32001 DM32011 000A Communications baud rate (high-speed) DM32006 DM32016 000@ @ = The largest model number of the con- nected PT (0 –...
Page 90 Parity None, even, odd Flow control None, RS/CS, XON/XOFF 4-1-2 Connecting Directly between RS-232C Ports The method for connection between the RS-232C ports of the NT31/NT31C and the host is described here. Host link unit/CPU NT31/NT31C SYSMAC CS/CJ-series PLC C-series PLC,...
Page 91 XW2Z-500S 9-pin ⇔ 9-pin XW2Z-200T XW2Z-500T When a connection is made to a personal computer at serial port A in the memory link method, OMRON cable with connectors shown below are avail- able. Model Cable Length Connector Specification 9-pin ⇔ 25 pin CV500-CN228 9-pin ⇔...
Page 92 25-pin connector (communications port 1), and a 9-pin connector (com- munications port 2). When using communications port 2, refer to Wiring for Other Connections (Other Than the Memory Link Method) (page 76). Serial Port A NT31/NT31C PLC (host link unit) Abbreviation Shielding wire...
Page 93 Section 4-1 Connecting to the RS-232C Port at the Host * For Units that have a CTS setting selector switch, RS and CS do not have to be shorted if this switch is set to 0 V. Wiring for Other Applicable Units: Connections CV500-LK201 (communications port 2)
Page 94 Connecting to the RS-232C Port at the Host Section 4-1 Serial Port A NT31/NT31C PLC (Host link unit) Abbreviation Abbreviation Shielding wire number number Connector hood RS-232C interface RS-232C interface (9-pin type) (9-pin type) Serial Port B NT31/NT31C PLC (Host link unit)
Page 95 Section 4-1 Connecting to the RS-232C Port at the Host NT31/NT31C PLC (Host link unit) Abbreviation Abbreviation Shielding wire number Connector Connector hood hood RS-232C interface RS-232C/ 422A/485 interface RDB (+) SDB (+) SDA (-) RDA (-) RSB (+) RSA (-)
Page 96: Connecting To The Host From The Rs-422A/485 Port
SECTION 5 Connecting to the Host from the RS-422A/485 Port This section describes the method for connecting to the host using the RS-422A/485 port of the PT. Connecting to the Host’s RS-232C Port......5-1-1 The Type of Host and Settings .
Page 97: Connecting To The Host's Rs-232C Port
OMRON PLCs, refer to the PLC Connection Manual (V042-E1-@) or NT31/ 631 Multi Vendor Connection Manual (V060-E1-@). • Method in which the RS-422A port of the NT31/NT31C and the RS-232C port of the host are connected in a 1:1 connection via an RS-232C/RS- 422A Adapter (page 82).
Page 98: The Type Of Host And Settings
One end of the wire must always be connected to the host (PLC), and there must be no branching. Branching will cause problems such as transmission delays and communications failures. (At termination) Relay terminal block Relay terminal block Max. 2 m NT31C NT31 NT31 NT31 NT31C NT31 NT31 NT31C NT31...
Page 99: 1:1 Connection Between Rs-422A/485 At The Pt And Rs-232C At The Host
25-pin connector (NT-AL001) RS-422A/485 cable RS-232C cable (max. length: 500 m) with connectors 9-pin connector RS-422A terminal block Reference: When using RS-485 as a port for the NT31/NT31C, only NT link (1:N) method (standard or high-speed) can be used.
Page 100 For details on handling shield wires, refer to 5-2-8 Handling the Shield on RS- 422A/485 Cables on page 128. Reference: When using RS-485 as a port for the NT31/NT31C, only NT link (1:N) method (standard or high-speed) can be used.
Page 101 Section 5-1 Connecting to the Host’s RS-232C Port Connecting an NT-AL001 and Host NT31/NT31C Host NT-AL001 RS-232C Wiring When Connecting a Host Link Unit (25-pin) Applicable Units: C200H-LK201-V1 3G2A5-LK201-EV1 C500-LK203 3G2A6-LK201-EV1 CV500-LK201 (communications port 1) CVM1/CV-series Host Link Unit (CV500-LK201) has two types of connector: a 25-pin connector (communications port 1), and a 9-pin connector (communi- cations port 2).
Page 102 Section 5-1 Connecting to the Host’s RS-232C Port CJ1G-CPU44/45 CJ1G-CPU42H/43H/44H/45H CJ1H-CPU65H/66H/67H CJ1M-CPU11/12/13/21/22/23 C200HS-CPU21/23/31/33 C200HE-CPU32/42-(Z)E C200HG-CPU33/43/53/63-(Z)E C200HX-CPU34/44/54/64-(Z)E C200HX-CPU65-ZE C200HX-CPU85-ZE CV500-CPU01-EV1 CV1000-CPU01-EV1 CV2000-CPU01-EV1 CVM1-CPU01-EV2 CVM1-CPU11-EV2 CVM1-CPU21-EV2 SRM1-C02-V2 Usable Cables with Attached Connectors: • For host link and 1:1 NT Link only (+5 V power wire attached) SJ45007-102(9-pin to 9-pin, 0.7 m) SSJ45007-202(9-pin to 9-pin, 2 m) •...
Page 103: 1:N Connection Between Rs-422A/485 At The Pt And Rs-232C At The Host
1:N Connection between RS-422A/485 at the PT and RS-232C at the Host The connection method in which the RS-422A/485 ports of multiple NT31/ NT31Cs are connected to the RS-232C port of one host in a 1:N connection is described here.
Page 104 Section 5-1 Connecting to the Host’s RS-232C Port Connecting an NT31/ The relay terminal board is not included in the figure below. Insert a relay ter- NT31C and NT-AL001 (RS- minal board so as to achieve the wiring configuration indicated below.
Page 105 Section 5-1 Connecting to the Host’s RS-232C Port Connecting an NT31/ The relay terminal board is not included in the figure below. Insert a relay ter- NT31C and NT-AL001 (RS- minal board so as to achieve the wiring configuration indicated below.
Page 106 RSA (-) (25-pin type) (25-pin type) Make the connection between pin numbers 9 and 10 at the terminal NT31/ NT31C (marked * in the figure above) only. For details on handling shield wires, refer to 5-2-8 Handling the Shield on RS-...
Page 107 RSA (-) (25-pin type) (25-pin type) Make the connection pin numbers 9 and 10 at the terminal NT31/NT31C (marked * in the figure above). For details on handling shield wires, refer to 5-2-8 Handling the Shield on RS- 422A/485 Cables on page 128.
Page 108 Section 5-1 Connecting to the Host’s RS-232C Port Connecting an NT-AL001 and Host NT31/NT31C Host NT-AL001 RS-232C Wiring when connecting a CS-series Serial Communications Board, CS/CS- series Serial Communications Unit, CQM1H Serial Communications Board, or C-series C200HX/HG/HE(-Z)E Communications Board. Applicable PLCs:...
Page 109: Recommended Connectors, Cables, And Crimp Terminals
CO-MA-VV-SB Multi-core shielded cable 5P×28AWG Made by Hitachi, Ltd. Cables with Connectors Made by OMRON When connecting an NT-AL001 and a PLC, use the OMRON cables with con- nectors indicated in the table below. Model Cable Length Connector Specification 9-pin ⇔ 9-pin XW2Z-070T-1 0.7 m...
Page 110: Setting The Terminal Resistance For Rs-422A/485 Communications
(pins No. 9 and 10 of serial port B). The terminal resistance is 120 Ω . When carrying out RS-422A/485 communications using serial port B, short between terminals No. 9 and 10 at the NT31/NT31C at the end of the RS-422A/485 cable. Leave terminals No. 9 and 10 open at NT31/NT31C PTs other than the one at the end of the cable.
Page 111: Connecting To The Host's Rs-422A/485 Port
Host RS-422A cable (max. 500 m) • Method in which the RS-485 ports of the NT31/NT31C and host are con- nected by an RS-485 cable (page 119). When this method is used, the cable length can be extended up to...
Page 112: Host Types And Settings
RS-422A cable (max. total length 500 m) • Method in which the RS-485 ports of multiple NT31/NT31Cs and the RS- 485 port of the host are connected in a 1:N connection (page 124). This connection method is used with the RS-485 type NT link (1:N) method (standard or high-speed).
Page 113 Check the model and series of the PLC and the type of the installed Board or Unit before making a connection. The Host Units featuring the RS-422A/485 host link function that can be con- nected to the RS-422A/485 port of the NT31/NT31C are listed in the table below. CPU Unit with built-in Host...
Page 114 CIF01 RS-232C Adapter, or CPM1-CIF11 RS-422A Adapter to connect. CPU Units of CVM1/CV-series PLCs without the suffix -EV@ cannot be connected. The host link method cannot be used when an NT31/NT31C is connected using RS-485. To use the host link method, connect by RS-422A.
Page 115 Unit # Set the host link communications speed at 9600 bps or 19200 bps with the Comm. Speed memory switch at the NT31/NT31C. For details, refer to 6-7- 2 Setting the Host Link Method (page 161). The 1-to-N setting enables BCC (Block Check Character). It is not actually possible to connect more than one NT31/NT31C in a single host link.
Page 116 Section 5-2 Connecting to the Host’s RS-422A/485 Port C1000H/C2000H Rack-mounting Unit: 3G2A5-LK201-EV1 Setting the Front Switches Mode selector Host Local • Mode selector (key switch) Set this to Host link. Setting the Rear Switches • I/O port selection (selector switch) Set this to RS-422A.
Page 117 Section 5-2 Connecting to the Host’s RS-422A/485 Port C1000H/C2000H Rack-mounting Unit: C500-LK203 Setting the Rear Switches • I/O port selection (selector switch) Set this to RS-422A. 5 V supply • Unit #, parity, and transfer code I/O port (DIP SW1-1 to SW1-7) RS-422A Set SW1-1 to SW1-7 to OFF (0).
Page 118 Level 1, 2, 3 Set the host link communications speed at 9600 bps or 19200 bps with the Comm. Speed memory switch at the NT31/NT31C. For details, refer to 6-7- 2 Setting the Host Link Method (page 161). The 1-to-N setting enables BCC (Block Check Character). It is not actually possible to connect more than one NT31/NT31C in a single host link.
Page 119 Unit # Set the host link communications speed at 9600 bps or 19200 bps with the Comm. Speed memory switch at the NT31/NT31C. For details, refer to 6-7- 2 Setting the Host Link Method (page 161). Either set PLC Setup directly from a Programming Device (e.g. SYSMAC sup- port software), or transmit the PLC Setup made at a Programming Device to the CPU Unit.
Page 120 Section 5-2 Connecting to the Host’s RS-422A/485 Port Setting the Front Switches • Host link communication method selection (selector switch) Set this to RS-422A. • Communications type setting (DIP SW3) Set SW3 to OFF. (for host link communications) • Host link default value settings (DIP SW4) To effect the existing DIP switch I/O port selector switch...
Page 121 Unit # Set the host link communications speed at 9600 bps or 19200 bps with the Comm. Speed at the NT31/NT31C. For details, refer to refer to 6-7-2 Set- ting the Host Link Method (page 161). Set the PLC Setup area settings directly from a Programming Device (e.g.
Page 122 Section 5-2 Connecting to the Host’s RS-422A/485 Port Connecting to a CPM2C The CPM2C PLCs do not have the same kind of port connectors found on CS/ CJ-series PLCs. The CPM2C’s communications port handles both RS-232C and peripheral port connections which are divided internally. Therefore, when using the CPM2C, it is necessary to select RS-232C or peripheral port con- nections, according to the kind of cable and port (on the cable) used, as shown in the following table.
Page 123 Section 5-2 Connecting to the Host’s RS-422A/485 Port Serial Communications Board Switch Settings Set the switches on the Serial Communications Board as shown below. 2-wire or 4-wire selector (WIRE): (4-wire = RS-422A) Terminating resistance switch (TERM): ON (terminator ON = terminating resistance enabled).
Page 124 Check the model and series of the PLC against the model of CPU Unit before making the connections. The Units that can be connected to the RS-422A port of the NT31/NT31C by the RS-422A type NT link (1:1) method are indicated in the table below.
Page 125 Section 5-2 Connecting to the Host’s RS-422A/485 Port The NT link (1:1) method cannot be used using RS-485. To use the NT link (1:1) method, connect by RS-422A. NT link connection using RS-422A/485 is not possible with CPM1. Settings at the Host The setting methods for each type of Unit are described in the following.
Page 126 Check the model and series of the PLC against the model of CPU Unit or Communications Board before making the connections. The Units that can be connected to the RS-232C port of the NT31/NT31C by the RS-422A type NT link (1:N) function via a convertor are indicated in the table below.
Page 127 Section 5-2 Connecting to the Host’s RS-422A/485 Port CPU Units with Built- CPU Unit that becomes Model Name Series in NT Link (1:N) connectable by installing a Function Communications Board/Unit C series --- (*4) C200HE (-Z)E C200HE-CPU32-(Z)E (*4) C200HE-CPU42-(Z)E (*4) C200HG (-Z)E C200HG-CPU33-(Z)E (*4)
Page 128 Connecting to the Host’s RS-422A/485 Port Section 5-2 • There are no Serial Communications Boards for the CQM1H in which port 1 is the RS-422A/485 port. Setting the DIP Switches on a C200HX/HG/HE(-Z)E Communications Board Set the switches on a C200HX/HG/HE(-Z)E Communications Board as fol- lows.
Page 129 Connecting to the Host’s RS-422A/485 Port Section 5-2 COMM1 COMM2 Port 1 RS-232C PORT1 Terminal resistance setting switch (TER) Set to ON (Terminal resistance is present.) (right side) ON TERM WIRE Two wire type/four wire type changeover switch (WIRE) Port 2 For RS-422A: 4 (4 wire type) (right side) RS-422A/485 PORT2...
Page 130 Using the High-speed NT Compatible Host Units Link (1:N) Method Only OMRON’s CS/CJ-series PLCs support the high-speed 1:N NT Link through RS-422A/RS-485. The high-speed 1:N NT Link must be established through a Serial Communications Board/Unit. (Even CS-series Units without the “-V1” suffix can be connected via a high-speed 1:N NT Link by mounting a Serial Communications Board/Unit.)
Page 131 Connecting to the Host’s RS-422A/485 Port Section 5-2 This CPU Unit is for a Duplex-CPU Unit System. The CS1W-SCB41(-V1) Serial Communications Board cannot be used. Use the CS1W-SCU31-V1 Serial Communications Unit. A CS1W-SCU31-V1 or CS1W-SCU41(-V1) Serial Communications Unit is required. Settings at the Host Connecting to a CS-series Serial Communications Board Serial Communications Board equipped with an RS-422A/485 port for CS-...
Page 132 Section 5-2 Connecting to the Host’s RS-422A/485 Port Allocated DM Area Setting Setting Contents words Port 2 DM32011 000A Baud rate (high-speed) DM32016 000@ @ = The highest unit number of the connected PTs (0 to 7) For example, when connecting PTs with model numbers 3, 4, 5, and 6 to port 2, set the value 8200 hex to DM32010, 000A hex to DM32011, and 0006 hex to DM32016.
Page 133: Direct Connection Between Rs-422A Ports At Both Units
None, even, odd Flow control None, XON/XOFF 5-2-2 Direct Connection between RS-422A Ports at Both Units The connection method in which the RS-422A ports of an NT31/NT31C and a host are connected is described here. Host link, CPU Unit, Communications Unit/Board...
Page 134 Connecting to the Host’s RS-422A/485 Port Section 5-2 NT31/NT31C side Abbreviation Pin number Connector hood − RS-232C/ 422A/485 connector PLC side − Pin number Abbreviation Connector hood − − − RS-422A − connector RDB (+) − SDB (+) − −...
Page 135 CS1G-CPU42/43/44/45-E(V1) CS1H-CPU63/64/65/66/67-E(V1) CS1G-CPU42H/43H/44H/45H CS1H-CPU63H/64H/65H/66H/67H CS1D-CPU65H/67H (See note.) C200HE-CPU32/42-(Z)E C200HG-CPU33/43/53/63-(Z)E C200HX-CPU34/44/54/64-(Z)E C200HX-CPU65-ZE/85-ZE CQM1H-CPU51/61 CV500-LK201 (communications port 2) Note A Serial Communications Board cannot be used. NT31/NT31C side Abbreviation Pin number Connector hood − RS-232C/ 422A/485 connector PLC side − Pin number...
Page 136: Direct Connection Between Rs-485 Ports At Both Units
For details on handling shield wires, refer to 5-2-8 Handling the Shield on RS- 422A/485 Cables on page 128. 5-2-3 Direct Connection between RS-485 Ports at Both Units The connection method in which the RS-485 ports of an NT31/NT31C and a host are connected is described here.
Page 137 RS-485 cable with connectors (max. length: 500 m) Reference: When RS-485 is used at the PT side, only the NT link (1:N) method (standard or high-speed) can be used. Connecting an NT31/NT31C and Host NT31/NT31C Host RS-485 Wiring When Connecting a CS-series Serial Communications Board, CS/...
Page 138: 1:N Connection Among Rs-422A Ports
For details on handling shield wires, refer to 5-2-8 Handling the Shield on RS- 422A/485 Cables on page 128. 5-2-4 1:N Connection among RS-422A Ports The connection method in which the RS-422A ports of multiple NT31/NT31Cs and one host are connected in a 1:N connection is described here. CPU Unit NT31/NT31C...
Page 139 (25-pin type) (25-pin type) Make the connection between pin numbers 9 and 10 at the NT31/NT31C at the end of the RS-422A cable (marked * in the figure above) only. For details on handling shield wires, refer to 5-2-8 Handling the Shield on RS- 422A/485 Cables on page 128.
Page 140 CS1W-SCU31-V1 CJ1W-SCU31-V1/CJ1W-SCU41(-V1) CS1G-CPU42/43/44/45-E(V1) CS1H-CPU63/64/65/66/67-E(V1) CS1G-CPU42H/43H/44H/45H CS1H-CPU63H/64H/65H/66H/67H CS1D-CPU65H/67H (See note.) C200HE-CPU32/42-(Z)E C200HG-CPU33/43/53/63-(Z)E C200HX-CPU34/44/54/64-(Z)E C200HX-CPU65-ZE/85-ZE CQM1H-CPU51/61 Note A Serial Communications Board cannot be used. NT31/NT31C side Abbreviation Pin number Connector hood − RS-232C/ 422A/485 connector PLC side − Pin number Abbreviation Shielding wire...
Page 141: 1:N Connection Among Rs-485 Ports
Connecting to the Host’s RS-422A/485 Port Section 5-2 5-2-5 1:N Connection among RS-485 Ports The connection method in which the RS-485 ports of multiple NT31/NT31Cs and one host are connected in a 1:N connection is described here. CPU Unit NT31/NT31C...
Page 142 (25-pin type) Next PT Make the connection between pin numbers 9 and 10 at the NT31/NT31C at the end of the RS-485 cable (marked * in the figure above) only. For details on handling shield wires, refer to 5-2-8 Handling the Shield on RS- 422A/485 Cables on page 128.
Page 143: Recommended Connectors, Cables And Crimp Terminals
Connecting to the Host’s RS-422A/485 Port CS1G-CPU42/43/44/45-E(V1) CS1H-CPU63/64/65/66/67-E(V1) CS1G-CPU42H/43H/44H/45H CS1H-CPU63H/64H/65H/66H/67H CS1D-CPU65H/67H (See note.) C200HE-CPU32/42-(Z)E C200HG-CPU33/43/53/63-(Z)E C200HX-CPU34/44/54/64-(Z)E C200HX-CPU65-ZE/85-ZE CQM1H-CPU51/61 Note A Serial Communications Board cannot be used. NT31/NT31C side Abbreviation Pin number Connector hood − RS-232C/ 422A/485 connector PLC (CPU Unit) side − Pin number...
Page 144: Setting The Terminal Resistance For Rs-422A/485 Communications
(pins No. 9 and 10 of serial port B). The terminal resistance is 120 Ω . When carrying out RS-422A/485 communications using serial port B, short between terminals No. 9 and 10 at the NT31/NT31C at the end of the RS-422A/485 cable. Leave terminals No. 9 and 10 open at NT31/NT31C PTs other than the one at the end of the cable.
Page 145: Handling The Shield On Rs-422A/485 Cables
RS-422A/485 cable. Note Before connecting or disconnecting cables between devices, make sure that the power supply to all of the connected devices (NT31/NT31C, PLC, etc.) is OFF. Reference: • The internal circuit of the NT31/NT31C is shown below.
Page 146 Section 5-2 Connecting to the Host’s RS-422A/485 Port Preparing the Shield of RS-422A/485 Connectors Always prepare RS-422A/485 cable shields properly. Otherwise, communica- tions errors may occur with the host. Ground only one end of the shield when connecting the ground terminal (GR) of the devices to the functional ground (FG: ), and grounding each signal line at only one point and to 100 Ω...
Page 147 Section 5-2 Connecting to the Host’s RS-422A/485 Port...
Page 148: System Menu Operation
Starting the NT31/NT31C ........
Page 149 6-9-8 Setting the Screen Saver Start-up Time..... . . 6-9-9 Setting the History Display Method ......6-9-10 Setting the Resume Function.
Page 150: System Menu Operation Flow
Section 6-1 System Menu Operation Flow System Menu Operation Flow Follow the procedure below when using the NT31/NT31C for the first time or changing the system program. Create the Screen Data Create the data to be displayed on the NT31/NT31C by using the Support Tool.
Page 151 Start of Communications Communications with the host starts in accordance with the communications with the Host method set in the system memory of the NT31/NT31C. During the interval until communications are established, the system initialization screen (screen No. 9000) is displayed.
Page 152: Operation Modes And The System Menu
The NT31/NT31C operates in four modes: the RUN, Transmit, Maintenance, and Expansion modes. These modes are selected from the System Menu. In addition, the NT31/NT31C also features the System Installer mode which is used specifically for installing the system program.
Page 153 PT model. For details, refer to 6-14 Version Dis- play. • Programming Console Function Allows the NT31/NT31C to be used as a Programming Con- sole for a CS/CJ-series PLC, CPM1, CPM2A, CPM2C, CQM1, CQM1H, C200HX/HG/HE(-Z), or SRM1.
Page 154: Menu Tree
Operation Modes and the System Menu 6-3-2 Menu Tree The System Menu allows the various functions of the NT31/NT31C to be exe- cuted by using touch switches displayed on the touch panel. The menu tree, starting from the System Menu, is shown below.
Page 155: Operations With The System Menu
Installer mode, the System Menu cannot be displayed (this does not apply if an error has occurred). • At the same as the System Menu is displayed, the operation of the NT31/ NT31C stops and the RUN LED goes OFF.
Page 156 Return to the RUN mode by selecting Quit in the System Menu and other System Menu to the RUN menus. Mode Reference: Unlike previous PT models, the NT31/NT31C does not return to the RUN mode automatically if no operations are performed.
Page 157: Memory Initialization
System Installer mode, memory initialization is not possible. 6-4-1 Clearing Screen Data Use this function if the screen data has been corrupted and the NT31/NT31C cannot be started up correctly. This operation clears (initializes) only the screen data and contents of the mathematical tables.
Page 158 On completion of screen data clearance, the NT31/NT31C returns to the MEMORY INIT. MENU screen. After the screen data has been cleared, if an attempt is made to set the NT31/ NT31C to the RUN mode before screen data has been transmitted from the Support Tool or Memory Unit, an error message will be displayed and the RUN mode will not be established.
Page 159: Initializing Display History Record Data
Reference: The NT31/NT31C also allows the display history record data to be initialized by controlling the PT status control area from the host. For details, refer to 2-2-1 PT Status Control Area in the Reference Manual.
Page 160 The display history record data is initialized. During initialization, the message Initializing is displayed. If No is selected, the NT31/NT31C returns to the MEMORY INIT. MENU screen without initializing the display history record data. On completion of display history record data initialization, the message Fin- ished is displayed and the NT31/NT31C returns to the MEMORY INIT.
Page 161: Initializing Alarm History Record Data
Reference: The NT31/NT31C also allows the alarm history record data to be initialized by controlling the PT status control area from the host. For details, refer to 2-2-1 PT Status Control Area in the Reference Manual.
Page 162 The alarm history record data is initialized. During initialization, the message Initializing is displayed. If No is selected, the NT31/NT31C returns to the MEMORY INIT. MENU screen without initializing the alarm history record data. On completion of alarm history record data initialization, the message Fin- ished is displayed and the NT31/NT31C returns to the MEMORY INIT.
Page 163: Initializing The Recipe Tables
6-4-4 Initializing the Recipe Tables You can initialize the recipe tables (i.e., all the recipe data) edited in the NT31/ NT31C. Here, “initializing” the recipe tables means to restore the battery backup memory (“recipe data memory”) to the values in flash memory at that time.
Page 164: Initializing The Memory Tables
Reference: • If OFF is set for the Resume Function memory switch, the memory tables can be initialized just by switching the NT31/NT31C power off and back on again, or by resetting the NT31/NT31C (page 182). • The bit memory table merely reflects the statuses of bits at the host and...
Page 165 The memory tables are initialized. During initialization, the message Initializing is displayed. If No is selected, the NT31/NT31C returns to the MEMORY INIT. MENU screen without initializing the memory tables. On completion of memory table initialization, the message Finished is dis-...
Page 166: Initializing The Memory Switches
Section 6-4 Memory Initialization 6-4-6 Initializing the Memory Switches Initialization returns all the memory switches of the NT31/NT31C to their sta- tus on shipment. Initialize the memory switches by following the menu operation from the Sys- tem Menu shown below.
Page 167: Operations In The System Installer Mode
Section 6-5 Operations in the System Installer Mode After initialization, the memory switch statuses are as follows. Memory Switch Status Start-up Wait Time Key Press Sound Buzzer Sound Printer Controller ESC/P Print Method Tone (NT31C only) Screen Saver Movement Display erased Screen Saver Start up Time Hist.
Page 168: Setting The Display Language In The System Installer Mode
6-5-2 Clearing/Installing the System Program Use this function when the system program of the NT31/NT31C has been cor- rupted, or when installing a new system program. Reference: • In order to install a system program, the system installer must also be installed at the Support Tool.
Page 169 During clearance, the message Erasing ... is displayed. • If Return to Menu is selected, the NT31/NT31C returns to the System Installer mode menu without clearing the system program. • If clearance fails, a screen asking whether you wish to try again is dis- played.
Page 170: Changing The System Settings
Operations in the System Installer Mode Reference: If the new system program is not downloaded successfully after deleting a sys- tem program, it is not possible to use the NT31/NT31C at all. After deleting the system program, be sure to download a new one. 6-5-3...
Page 171: Clearing Screen Data
6-5-4 Clearing Screen Data If the screen data has been corrupted and the NT31/NT31C cannot be started normally, use this function to clear the screen data. Note that only the screen data is cleared (initialized), and the memory switch settings and the display history/alarm history record data are retained.
Page 172: Transmitting The Screen Data
On completion of screen data clearance, the NT31/NT31C returns to the Sys- tem Installer mode menu screen. After the screen data has been cleared, if an attempt is made to set the NT31/ NT31C to the RUN mode before screen data has been transmitted from the Support Tool or Memory Unit, an error message will be displayed and the RUN mode will not be established.
Page 173 (It is not possible to transmit mathematical table data in data units.) When data is transmitted in file units, all of the screen data in the NT31/ NT31C is cleared and then the new data is transmitted.
Page 174 If any of the following, or a system error, occurs during transmission of screen Observed When data, the transmitted screen data will not be registered correctly in the NT31/ Transmitting Screen Data NT31C. If this happens, the NT31/NT31C may not enter the RUN mode when started up, or there may be unpredictable malfunctions such as failure to dis- play screens during operation.
Page 175: Setting Conditions For Communications With Host By Using Memory Switches
Setting Conditions for Communications with Host by Using Memory Switches The NT31/NT31C can be connected to the host by the following 7 types of communications methods can be used to communicate with a host. • Host link •...
Page 176: About Communications Conditions
Setting Conditions for Communications with Host by Using Memory Switches 6-7-1 About Communications Conditions Items Set for The following settings are made for the communications conditions for com- Communications munications between the NT31/NT31C and the host. Conditions Port Communications Method/Communications Type Settings Setting Item Function Setting Options Page Comm.
Page 177 Section 6-7 Setting Conditions for Communications with Host by Using Memory Switches Possible Combinations of The combinations of communications methods that can be set with the NT31/ Communications Method NT31C are indicated in the table below. Combinations other than these listed...
Page 178: Setting The Host Link Method
Section 6-7 Setting Conditions for Communications with Host by Using Memory Switches 6-7-2 Setting the Host Link Method Set the communications conditions for the host link method at serial port A or serial port B by following the operation from the System Menu shown below. Ver 4.12 Select Maintenance Mode.
Page 179 [ ] (previous screen) touch switch, then make the setting. • To confirm the settings and quit the memory switch setting screen, press the Quit touch switch. The settings made last will be set and the NT31/ NT31C will return to the MAINTENANCE MODE MENU screen.
Page 180: Setting The Nt Link (1:1) Method
[ ] (previous screen) touch switch, then make the setting. • To confirm the settings and quit the memory switch setting screen, press the Quit touch switch. The settings made last will be set and the NT31/ NT31C will return to the MAINTENANCE MODE MENU screen.
Page 181: Setting The Nt Link (1:N) Method (Standard/High-Speed)
Section 6-7 Setting Conditions for Communications with Host by Using Memory Switches 6-7-4 Setting the NT Link (1:N) Method (Standard/High-speed) Set the communications conditions for the NT link (1:N) method at serial port A or serial port B by following the operation from the System Menu shown below.
Page 182 [ ] (previous screen) touch switch, then make the setting. • To confirm the settings and quit the memory switch setting screen, press the Quit touch switch. The settings made last will be set and the NT31/ NT31C will return to the MAINTENANCE MODE MENU screen.
Page 183: Setting The Memory Link Method
Section 6-7 Setting Conditions for Communications with Host by Using Memory Switches 6-7-5 Setting the Memory Link Method Set the communications conditions for the host link method at serial port A or serial port B by following the operation from the System Menu shown below. Check the communications settings of the host to be used.
Page 184 [ ] (previous screen) touch switch, then make the setting. • To confirm the settings and quit the memory switch setting screen, press the Quit touch switch. The settings made last will be set and the NT31/ NT31C will return to the MAINTENANCE MODE MENU screen.
Page 185: Setting The Communications Type For Serial Port B
[ ] (previous screen) touch switch, then make the setting. • To confirm the settings and quit the memory switch setting screen, press the Quit touch switch. The settings made last will be set and the NT31/ NT31C will return to the MAINTENANCE MODE MENU screen.
Page 186: Starting Operation
RS-422A/485 Port. • Confirm that the operation results of touch switch and numeric value/char- acter string input at the NT31/NT31C are sent to the host correctly by dis- playing the contents of the host words and bits using a Programming Device (e.g.
Page 187: Memory Switch Setting Screens
Section 6-9 System Settings Since the memory switch settings are backed up to the flash memory by the battery in the NT31/NT31C, they are not cleared when the power is switched OFF. 6-9-1 Memory Switch Setting Screens There are four memory switch setting screens. The required screen can be displayed by using the [ ] (next screen) and [ ] (previous screen) touch switches.
Page 188: Setting The Start-Up Wait Time
[ ] (previous screen) touch switch, then make the setting. • To confirm the settings and quit the memory switch setting screen, press the Quit touch switch. The settings made last will be set and the NT31/ NT31C will return to the MAINTENANCE MODE MENU screen.
Page 189: Setting The Buzzer Sound
[ ] (previous screen) touch switch, then make the setting. • To confirm the settings and quit the memory switch setting screen, press the Quit touch switch. The settings made last will be set and the NT31/ NT31C will return to the MAINTENANCE MODE MENU screen.
Page 190: Setting The Printer Controller
[ ] (previous screen) touch switch, then make the setting. • To confirm the settings and quit the memory switch setting screen, press the Quit touch switch. The settings made last will be set and the NT31/ NT31C will return to the MAINTENANCE MODE MENU screen.
Page 191 • PCL 5: Printers that conform to the PCL 5 printer control specifications. Note that the NT31 can only be used with the monochrome Tone setting and does not support color printing. For the NT31, the Print Method is fixed as Tone.
Page 192: Setting The Print Method (Nt31C Only)
6-9-6 Setting the Print Method (NT31C Only) The NT31/NT31C has a function for printing out data at a printer connected to it in response to an instruction from the host or operation at the NT31/NT31C. When using the NT31C, the currently displayed screen image or other data can be printed out in color.
Page 193: Setting Screen Saver Movement
[ ] (previous screen) touch switch, then make the setting. • To confirm the settings and quit the memory switch setting screen, press the Quit touch switch. The settings made last will be set and the NT31/ NT31C will return to the MAINTENANCE MODE MENU screen.
Page 194 [ ] (previous screen) touch switch, then make the setting. • To confirm the settings and quit the memory switch setting screen, press the Quit touch switch. The settings made last will be set and the NT31/ NT31C will return to the MAINTENANCE MODE MENU screen.
Page 195: Setting The Screen Saver Start-Up Time
6-9-8 Setting the Screen Saver Start-up Time The NT31/NT31C has a function to maximize the service life of the backlight and prevent the formation of an afterimage by turning off the screen display and the backlight if no operation is performed for a certain period of time.
Page 196 [ ] (previous screen) touch switch, then make the setting. • To confirm the settings and quit the memory switch setting screen, press the Quit touch switch. The settings made last will be set and the NT31/ NT31C will return to the MAINTENANCE MODE MENU screen.
Page 197: Setting The History Display Method
The default (factory) setting is From New Data. Reference: • When the voltage of the NT31/NT31C’s built-in battery becomes low, the history record contents cannot be retained. • For details on the display history record function and the alarm history record function, refer to 2-15-1 Display History Record Function and 2-15- 2 Alarm History Record Function in the Reference Manual.
Page 198 [ ] (previous screen) touch switch, then make the setting. • To confirm the settings and quit the memory switch setting screen, press the Quit touch switch. The settings made last will be set and the NT31/ NT31C will return to the MAINTENANCE MODE MENU screen.
Page 199: Setting The Resume Function
6-9-10 Setting the Resume Function The NT31/NT31C has a function to keep the contents of the memory tables even when the power to the NT31/NT31C is OFF and write back them to the host when the power is turned ON.
Page 200 [ ] (previous screen) touch switch, then make the setting. • To confirm the settings and quit the memory switch setting screen, press the Quit touch switch. The settings made last will be set and the NT31/ NT31C will return to the MAINTENANCE MODE MENU screen.
Page 201: Setting The Automatic Reset Function
Initializing screen may be displayed). • OFF: When a communications error occurs, an error screen is displayed and operation stops. Pressing OK on the error screen returns the NT31/ NT31C to the RUN mode. The default (factory) setting is OFF.
Page 202 [ ] (previous screen) touch switch, then make the setting. • To confirm the settings and quit the memory switch setting screen, press the Quit touch switch. The settings made last will be set and the NT31/ NT31C will return to the MAINTENANCE MODE MENU screen.
Page 203: Setting The Time-Out Interval
System Settings 6-9-12 Setting the Time-out Interval The NT31/NT31C goes into the time-out error status if no response is received from the host within a fixed time. The Time-out Interval setting speci- fies the time lapse at which time-out is judged to have occurred.
Page 204: Setting The Retry Count
System Settings • To confirm the settings and quit the memory switch setting screen, press the Quit touch switch. The settings made last will be set and the NT31/ NT31C will return to the MAINTENANCE MODE MENU screen. • To quit the memory switch setting screen without confirming the settings, press the Abort touch switch.
Page 205 [ ] (previous screen) touch switch, then make the setting. • To confirm the settings and quit the memory switch setting screen, press the Quit touch switch. The settings made last will be set and the NT31/ NT31C will return to the MAINTENANCE MODE MENU screen.
Page 206: Setting The Bar Code Reader Input Function
Setting the Bar Code Reader Input Function 6-10 Setting the Bar Code Reader Input Function The NT31/NT31C has a bar code reader input function which allows a bar code reader to be connected and bar code data to read as character strings into character string input fields.
Page 207 The setting option changes each time the touch switch is pressed. Press Quit. Pressing Abort on the communications condition/confirmation method setting screen causes the NT31/NT31C to return to the memory switch setting screen (4/4) without executing setting (with the previous settings still effec- tive).
Page 208: System Maintenance
TRAST ADJUST screen enables you to make the adjustment while actually checking the contrast on the screen. Once the contrast has been set, it remains in effect even if the power is turned OFF or the NT31/NT31C is reset (and even if the voltage of the built-in battery becomes low).
Page 209 ]: Decrease 1 step ]: Decrease 10 steps Press Quit. The contrast is set and the NT31/NT31C returns to the I/O SETTINGS MENU screen. Setting Using Brightness and Contrast Adjustment Screen Display screen number 9030 using either a touch switch with switch screen...
Page 210 The contrast is set, and the NT31/NT31C returns to the previous screen. Backlight Brightness The NT31/NT31C allows the brightness of the backlight to be adjusted in 3 Adjustment steps. The BRIGHTNESS ADJUST screen enables you to make the adjust- ment while actually checking the brightness on the screen.
Page 211 Select I/O Settings. Select Brightness Adjust. Adjust the contrast with the High, Middle, and Low touch switches in the left half of the screen. Press Quit. The contrast is set and the NT31/NT31C returns to the I/O SETTINGS MENU screen.
Page 212: Displaying/Setting The Calendar And Clock
Manual. • No clock data is set on shipment from the factory. • The clock data is backed up by the built-in battery of the NT31/NT31C. If the battery voltage becomes low, the clock data cannot be retained when the power to the NT31/NT31C is turned OFF or the NT31/NT31C is reset and the clock function will not operate correctly.
Page 213 Press Quit. The clock data is set and the NT31/NT31C returns to the date and time display. • Pressing Abort causes the NT31/NT31C to return to the date and time display without executing setting (with the previous settings still effective).
Page 214: Checking The Pt Setting Status
Section 6-11 System Maintenance 6-11-3 Checking the PT Setting Status The direct connection settings of the NT31/NT31C screen data, and the set- tings for serial port A and serial port B, can be checked. Screen Configuration and There are the following three PT setting status screens.
Page 215: Displaying And Printing The Display History Record
The record data can be displayed, and printed out at a printer connected to the NT31/NT31C by operation from the System Menu. This section explains how to display and print out the display history record data recorded in the NT31/NT31C.
Page 216 Section 6-11 System Maintenance Reference: • With the NT31/NT31C, the record data can also be displayed by calling screen No. 9001 (sort by occurrence) or screen No. 9002 (sort by fre- quency) during the RUN mode. • For details on the display history record function, refer to 2-15-1 Display History Record Function in the Reference Manual.
Page 217: Displaying And Printing The Alarm History Record
(order of number of times the bits have come ON). Reference: • With the NT31/NT31C, the record data can also be displayed by register- ing an alarm history display element on the screen. • For details on the alarm history record function, refer to 2-15-2 Alarm His- tory Record Function in the Reference Manual.
Page 218 Section 6-11 System Maintenance Display and print the alarm history record data by following the menu opera- tion from the System Menu shown below. Ver 4.12 Select Maintenance Mode. Select Alarm History. Select Sort by Occurrence or Sort by Frequency. If necessary, select the next or previous screen by pressing [↓] (next screen) or [↑] (previous screen).
Page 219: Checking Screen Data
98/02/17 15:44 6-11-6 Checking Screen Data The NT31/NT31C allows the registered screens (Nos. 1 to 3999) to be dis- played and checked by operation from the System Menu. Reference: • Window screens cannot be displayed by operation from the System Menu.
Page 220 Section 6-11 System Maintenance Reference: Each setting of the screen data check is effective only on this menu. Exiting from this screen data check menu resets the settings to the default (all the set- tings are set to OFF). Operations On The SCREEN DATA CHECK Screen The function shown below can be set on the SCREEN DATA CHECK screen.
Page 221 Section 6-11 System Maintenance Display the SCREEN DATA Display the SCREEN DATA CHECK screen by following the menu operation CHECK Screen from the System Menu shown below. Ver 4.12 Select Maintenance Mode. Select Screen Data Disp. Specify the screen to be displayed in the input field in the middle of the screen.
Page 222: Device Check
To end the operation, press Quit on the screen number selection screen. The NT31/NT31C returns to the MAINTENANCE MODE MENU screen. 6-11-7 Device Check The NT31/NT31C provides checks on the functions of the following items. • Buzzer page 206 • LED page 207 •...
Page 223 Section 6-11 System Maintenance Checking the Buzzer Check if the buzzer sounds correctly. Reference: The buzzer will sound in this check regardless of the setting made with the Buzzer Sound memory switch. Check the buzzer by following the menu operation from the System Menu shown below.
Page 224 Section 6-11 System Maintenance Checking the RUN LED Check if the RUN LED functions normally. Check the RUN LED by following the menu operation from the System Menu shown below. Ver 4.12 Select Maintenance Mode. Select I/O Check. Select Device Check. Select LED Check.
Page 225 (red green blue magenta cyan yellow white black). On completion of the display and clearance of all dots, the NT31/ NT31C returns to the DEVICE CHECK MENU screen. • Touch the touch panel to discontinue the LCD check. Even if 3 seconds...
Page 226 • In the screen data memory check, a write test is performed on the screen data memory. Since all the screen data in the NT31/NT31C is lost in this check, confirm that this data is backed up at the Support Tool or Memory Unit before executing it.
Page 227 Section 6-11 System Maintenance • Once a screen data check has been started, it cannot be stopped. Check the screen data memory by following the menu operation from the Sys- tem Menu shown below. Ver 4.12 Select Maintenance Mode. Select I/O Check. Select Device Check.
Page 228 • If an error is discovered in the check, the message Memory Check NG is displayed. After confirming the result of the check, press Quit. The NT31/NT31C returns to the DEVICE CHECK MENU screen. Checking Touch Switches Check whether or not the touch switches function normally by following the menu operation from the System Menu shown below.
Page 229 A touch switch is normal if it is displayed in reverse video while pressed. To end the check, press the touch switch at the top right corner (NT31: dis- played in reverse video; NT31C: displayed in yellow). The NT31/NT31C will return to the DEVICE CHECK MENU.
Page 230 Section 6-11 System Maintenance Checking the Battery Check the voltage of the NT31/NT31C’s built-in battery by following the menu Voltage operation from the System Menu shown below. Ver 4.12 Select Maintenance Mode. Select I/O Check. Select Device Check. Select Battery.
Page 231: Checking Interfaces
For details on the replacement method, refer to 7-3-1 Replacing the Bat- tery (page 243). 6-11-8 Checking Interfaces The NT31/NT31C allows the following communications functions to be checked. • Communications with the Support Tool page 214 • Communications at serial ports page 215 •...
Page 232 • If communications with the Support Tool is normal, data transmitted from the Support Tool is displayed as hexadecimal data when received by the NT31/NT31C. After confirming the result of the test, press Quit. The NT31/NT31C returns to the I/F CHECK MENU screen. Checking Check communications at the serial ports (A, B).
Page 233 Section 6-11 System Maintenance For NT Link (1:1 or 1:N) Example: Serial port B while using the NT Link (1:N) Press Execute to start the check. The data for checking communications is sent to the host, and is displayed as ∗∗ symbols at Sending Data. •...
Page 234 Select I/O Check. Select I/F Check. Select Comm. Port A or Comm. Port B. The check screen is displayed (Check screen, page 215). After confirming the result of the check, press Quit. The NT31/NT31C returns to the I/F CHECK MENU screen.
Page 235 Select I/F Check. Select Printer. Confirm that a printer is connected to the NT31/NT31C, then press Execute: Printer Interface Check will be printed out at the printer. • While data is being sent to the printer, the message Checking Now... is...
Page 236: Programming Console Function
• If data does not reach the printer within 60 seconds after sending starts, the message ‘Finished Printer output failed’ is displayed. After confirming the result of the check, press Quit. The NT31/NT31C returns to the I/F CHECK MENU screen.
Page 237: Usable Systems
The peripheral port Programming Console always has priority. If a Pro- gramming Console is connected later, the Programming Console function of the NT31/NT31C is invalidated and operation from the NT31/NT31C becomes impossible. The CPM2C-CN111 Connecting Cable splits the PLC’s Communications Port into a RS-232C port and a peripheral port.
Page 238: Connection Method
Programming Console Function Section 6-12 where * is a number in the range 1 to 9 or the letter X or Y. CQM1: @@@3, @@@4, @@@5, @@*6 where * is a number in the range 1 to 9 or the letter X or Y. C200HX/HG/HE: @@@5 @@*6 where * is a number in the range 1 to 9 or the letter X or Y.
Page 239: Method Of Use
Programming Console Function Section 6-12 6-12-3 Method of Use The Programming Console screen is displayed by operating the system menu as described below. Ver 4.12 Select Expansion Mode. Select Programming Console. The Programming Console screen is displayed. Press the Programming Console sheet keys (touch switches) for the operation.
Page 240 Section 6-12 Programming Console Function Key Operations Mode Selection Keys, Mode Lock Key The display element on the Programming Console screen shown below com- prises the mode selection keys, which change the operation mode of the PLC, and the mode lock key, which prevents unintended mode changes. Mode selection keys Mode lock key The RUN, MONITOR, and PROGRAM mode selection key elements are...
Page 241 • It is not possible to adjust the volume of the key press sound. Whether or not the key press sound sounds is determined by the setting for the Key Press Sound memory switch of the NT31/NT31C. It sounds when the set- ting is ON and does not when the setting is OFF (page 171).
Page 242: Device Monitor Function
A communications error will occur if you use the Programming Console func- tion to change the communications settings (in the PLC Setup) that govern the port to which the NT31/NT31C is connected. In this case, the Programming Console function will be unusable.
Page 243: Compatible Systems
Section 6-13 Device Monitor Function 6-13-1 Compatible Systems The following table shows the combinations of communications methods and PLCs that can support the PT’s Device Monitor function. Communications PLC model method 1:1 NT Link C200HS-CPU21/23/31/33-E C200HE-CPU32/42 (-Z)E C200HG-CPU33/43/53/63 (-Z)E C200HX-CPU34/44/54/64 (-Z)E C200HX-CPU65-ZE C200HX-CPU85-ZE CPM1-10CDR-@...
Page 244 Device Monitor Function Section 6-13 CPM1, CPM2A, or SRM1 The 1:1 NT Link can be used in all CPU Units and the 1:N NT Link can also be used in -V2 and higher versions of the SRM1. The connection method is exactly the same as for the 1:1 NT Link or 1:N NT Link.
Page 245: Version Display
Device Monitor Function in the Reference Manual. 6-14 Version Display Use the Version Display function to check the version of the NT31/NT31C’s system program. The Version Display screen shows the model, creation date, and version of the system program installed in the NT31/31C.
Page 246: Method Of Use
Section 6-14 Version Display 6-14-1 Method of Use The Version Display screen is displayed by operating the system menu as described below. Ver 4.12 Select Expansion Mode. Select Version Display. The system program's version information will be displayed as described below. Press the Quit touch switch to exit the Version Display screen and return to the Expansion Mode screen.
Page 247 Section 6-14 Version Display...
Page 248: Troubleshooting And Maintenance
Communications Errors and Their Remedies ....Maintenance of the NT31/NT31C ....... . .
Page 249: Troubleshooting
Section 7-1 Troubleshooting Troubleshooting When a fault relating to the operation of the NT31/NT31C occurs, find the symptoms in the table below and respond by following the corresponding Remedy indicated in the table. Note 1. Confirm system safety before turning the power ON/OFF or resetting.
Page 250 If the resume function does not need to be used, use memory tables. the NT31/NT31C with the resume function OFF. (6-9- 10 Setting the Resume Function, page 182) The numeral memory table is speci-...
Page 251 Manual. Create the screen data again and then The total of the element coefficients transmit all of the screen data in a batch to the NT31/ for the displayed screen is greater NT31C. than 1024.
Page 252: Responding To Displayed Error Messages
3-5 Using a Memory Unit. 7-2-1 Errors Occurring at Start of Operation and Their Remedies The table below shows the errors that can occur when the power to the NT31/ NT31C is turned ON and when operation starts, and their remedies. Message...
Page 253 MODE and download Screen Data again. [Touch Panel is disconnected] The touch panel cable (film cable) Contact your OMRON service center. inside the NT31/NT31C is discon- nected. [Memory Switch Corrupted] The memory switches have been Set the memory switches again using the...
Page 254: Errors Occurring During Operation And Their Remedies
Section 7-2 Responding to Displayed Error Messages 7-2-2 Errors Occurring during Operation and Their Remedies The table below shows the errors that can occur during operation of the NT31/ NT31C and their remedies. Message Cause Remedy [Address Setting Error] The host side allocated words and...
Page 255: Errors In The System Installer Mode And Their Remedies
Over Flow Error. 7-2-4 Errors in the System Installer Mode and Their Remedies This section describes the errors that may occur in the System Installer mode of the NT31/NT31C, and the remedies for these errors. Message Cause Remedy System Program not exist or •...
Page 256: Communications Errors And Their Remedies
When an error message is displayed, remove the cause of the error and then Communications Errors press the OK touch switch displayed on the screen. The NT31/NT31C will Occur return to the screen that was displayed before the error occurred, and opera- tion will restart.
Page 257 Check if the settings at the host for parity bit, frame conditions set incorrectly. length, communications speed, stop bit length and Framing Error flow control agree with those at the NT31/NT31C. Over-run Error The connecting cables are not con- Check the communications cable connection and nected correctly.
Page 258: Maintenance Of The Nt31/Nt31C
Doing either of these may result in electrical shock. Spare PT It is advisable to have a spare NT31/NT31C available to minimize system downtime in the event of an NT31/NT31C failure or if the screen display becomes difficult to read due to deterioration of the display unit. Backlight When the backlight in the display is getting dim and the screen cannot be read easily, replace the backlight.
Page 259 Replace the backlight by following the procedure given below: Procedure 1,2,3... 1. Turn the power supply to the NT31-ST121@-EV2/NT31C-ST141@-EV2 OFF. 2. Disconnect the terminal block wiring, the communications cable, and the printer cable. If a Memory Unit or Interface Unit is mounted, remove that Unit also.
Page 260: Replacing The Battery
• Touch switch • Backlight 9. On confirming that all the tests in 8 can be executed normally, start opera- tion. 7-3-1 Replacing the Battery The NT31/NT31C uses a lithium battery to back up the memory contents.
Page 261 Maintenance of the NT31/NT31C Section 7-3 The battery life is about 5 years if the NT31/NT31C is used in a location where the ambient temperature is 25 ° C. If the temperature at the location of use is higher than this, the battery life will be shorter. Change the battery at suitable intervals in accordance with the operating environment of the NT31/NT31C.
Page 262: Inspection And Cleaning
The connector of the new battery must be connected within 5 minutes after disconnecting the old battery’s connector. However, the battery can be re- placed while the NT31/NT31C power is on, and in this case there is no time restriction.
Page 263 Inspect the following points to determine if there is any divergence from the stated criteria. If there is, either improve the surrounding environment so that the values fall within the stated range, or adjust the NT31/NT31C, for example by re-tightening screws.
Page 264: Specifications
Appendix A Specifications General Specifications Item Specification NT31-ST123@-EV3 NT31C-ST143@-EV3 Rated power supply voltage 24 VDC Allowable power supply 20.4 VDC to 26.4 VDC (24 VDC –15% to +10%) voltage range Allowable power interruption No regulation time Power consumption 15 W max.
Page 265: Performance Specifications
Lit in orange: Low battery voltage (during operation) Flash in red: Low battery voltage (when NT31/NT31C is stopped) Note Time taken for brightness to reduce to half at normal temperature and humidity Version 2 (-V2) PTs: 25,000 hours min. at medium brightness, 10,000 hours min. at high brightness...
Page 266 Programming Environment Item Specification Programming System Programming support software Programming Tool Programming support software: NT-series Support Tool for Windows (Ver. 4.@), by OMRON Special Features Item Specifications Buzzer Three kinds of buzzer sound (continuous, short intermittent, and long intermittent) On reception of a command from the host, display of a screen with a buzzer setting, or display of an error screen such as for a receive error.
Page 267 Resume function Retains the contents of the numeral/character string memory tables (i.e., they are not initialized) when the power is turned ON, when the NT31/NT31C is reset, and when the operation mode is changed. Setting: Set “ON” for “Resume Function” in the memory switch menu.
Page 268 Appendix A Specifications Communications Specifications For a Host Link, RS-232C Type Item Specification Communications standard EIA RS-232C Communications settings Start-stop synchronization Communications speed: 9600, 19200 bps Data length: 7 bits Stop bit: 2 bits Parity: Even Connector 9-pin D-SUB connector (female) (serial port A) 25-pin D-SUB connector (female) (serial port B) Number of Units connected Transmission distance...
Page 269 Appendix A Specifications For an NT Link, 1:1, RS-422A Type Item Specification Communications standard EIA RS-422A Connector 25-pin D-SUB connector (female) (serial port B) Number of Units connected Transmission distance Max. 500 m For an NT Link, 1:N, RS-232C Type Item Specification Communications standard...
Page 270 Appendix A Specifications For a High-speed NT Link, 1:N, RS-422A/485 Type Item Specification Communications standard EIA RS-422A/485 Connector 25-pin D-SUB connector (female) (serial port B) Number of Units connected 1:1 to 8 Transmission distance Max. 500 m For a Memory Link, RS-232C Type Item Specification Communications standard...
Page 271 Appendix A Specifications For a Memory Link, RS-422A Type Item Specification Communications standard EIA RS-422A Communications settings Start-stop synchronization Communications speed: 1200, 2400, 4800, 9600, 19200, 38400 bps Data length: 7, 8 bits Stop bit: 1, 2 bits Parity: None, even, odd Flow control: None, XON/XOFF Response:...
Page 272: Dimensions
Appendix B Dimensions Body 183.5 (7.22) POWER 142 (5.59) 130.5 (5.14) 5 (0.20) 54 (2.13) 195 (7.68) With memory unit installed Units: mm (inch) (NT-MF261) 74 (2.91)
Page 273 Appendix B Dimensions Mounting Dimensions Mounting panel Mounting fixture POWER 25 (0.98) 153 (6.02) 15.5 (0.61) 5 (0.2) 145 (5.71) 34 (1.34) (min.) 38 (1.5) (max.) Units: mm (inch) 206 (8.11)
Page 274 Appendix B Dimensions Cable Connection Dimensions (with NT-MF261) 96 (3.78) 10.2 (0.47) 91 (3.58) 26.7 (1.05) PRINTER PORT B PORT A 5 (0.20) 50 (1.97) 60 (2.36) Units: mm (inch)
Page 275 Appendix B Dimensions...
Page 276: Using An Rs-232C/Rs-422A Adapter
Appendix C Using an RS-232C/RS-422A Adapter This section outlines the external dimensions, procedure for mounting and removal, and specifications of an RS-232C/RS-422A Adapter (NT-AL001-E). Refer to this information when designing the control panel. For details, refer to the instruction manual supplied with the NT-AL001-E. Dimensions 53.5 (2.11)
Page 277 Appendix C Using an RS-232C/RS-422A Adapter Removal from a DIN Rail Remove the end plates at right and left of the Adapter and, as shown in the figure below, insert a flat blade screwdriver into the rail stopper at the bottom face of the Adapter and prize it free. Mounting to an Operation Panel Drill two mounting screw holes in an operation panel with a thickness of at least 2 mm (0.08 inch) and secure the Adapter with screws.
Page 278: General Specifications
Appendix C Using an RS-232C/RS-422A Adapter Specifications The general specifications and communications specifications of the Adapter are shown below. General Specifications Item Specification 30 (W) × 114 (H) × 100.2 (D) mm: Dimensions with the RS-422A terminal block cover closed 30 (W) ×...
Page 279 DIP switch settings are correct. If the power is turned on while there is a wiring fault, the internal circuits of the Adapter or the RS-232C device may be damaged. (4) When the Adapter is connected to a C200HX/HG/HE (-ZE), CQM1H, CS/CJ-series OMRON PLC as an RS-422A device, set DIP switches SW1-5 and SW1-6 as indicated below.
Page 280 Appendix C Using an RS-232C/RS-422A Adapter Pin Arrangement The Adapter has a terminal block for an RS-422A/485 interface connection and a connector for an RS-232C interface connection. The pin arrangements for the RS-422A/485 terminal block and the RS-232C connector are as follows. RS-422A/485 Terminal Block Terminal Signal name...
Page 281 Appendix C Using an RS-232C/RS-422A Adapter Block Diagram A diagram showing the internal blocks of the Adapter is shown below. Refer to this diagram when making cables yourself, or when connecting devices with special interfaces. RS-232C side D-SUB 9P CASE RS-422A/485 side 8P terminal block POWER...
Page 282: Transporting And Storing The Nt31/Nt31C
Appendix D Transporting and Storing the NT31/NT31C • When transporting the NT31/NT31C, use the packaging intended for it. • When storing the NT31/NT31C, observe the following conditions. –20 to +60 ° C Storage ambient temperature: Storage ambient humidity: 35% to 85%...
Page 283: D Transporting And Storing The Nt31/Nt31C
Appendix D Transporting and Storing the NT31/NT31C...
Page 284: Making The Cable
Appendix E Making the Cable The procedure for making up the cable is described below. Also refer to this procedure for making a connecting cable for use with RS-422A/485 type connections. Cable Preparation The preparation of the cable differs according to whether or not the shielding wire is to be connected to the FG. Cable with Shielding Wire Connected to FG 1,2,3...
Page 285 Appendix E Making the Cable 40 (1.57) (RS-232C) 25 (0.98) (RS-422A) (0.19) Units: mm (inch) Vinyl tape Soldering 1,2,3... 1. Slide heat-shrink tube over each wire. 2. Pre-solder each wire and connector terminal. 3. Solder each wire to each connector terminal. 1 mm Soldering iron Heat-shrink tube...
Page 286: Making The Cable For Connecting A Plc
Use the following recommended products when making the connecting cable. Name Model Remarks Connector XM2D-2501 25-pin, made by OMRON, for personal computer side XM2A-0901 9-pin, made by OMRON, for PT side Connector hood XM2S-2511 25-pin, made by OMRON, for personal computer side...
Page 287: F Making The Cable For Connecting A Plc
Appendix F Making the Cable for Connecting a PLC...
Page 288: Making The Cable For Connection To A Bar Code Reader
+5 V +5 V When using the +5 V output of the NT31/NT31C, limit the cable length to within 2 m. If a cable longer than 2 m is used, connect an external power supply to the bar code reader.
Page 289 Making the Cable for Connection to a Bar Code Reader Appendix G...
Page 290: Making The Cable For Connection To A Printer
Making the Cable for Connection to a Printer The following product is recommended as the cable for connecting a printer. NT-CNT121 (made by OMRON, cable length 1.5 m, 20-pin – 36-pin) Refer to the following when making a cable for connection to a printer.
Page 291 Making the Cable for Connection to a Printer Appendix H...
Page 292: Relationship Between System Program And Hardware
(supplied with the NT-ZJCMX1-V4.08) Note NT System Installer version 2.0 or higher is required to install the NT31/31C-V3 system program. (NT System Installer version 2.0 is provided with NT-series Support Tool version 4.08 or higher.) These system programs are mutually compatible, therefore, they can be installed and used for the NT31- ST121@-E, NT31C-ST141@-E, NT31-ST121@-EV1, NT31C-ST141@-EV1, NT31-ST121@-EV2, NT31- ST122@-EV2, NT31C-ST141@-EV2, and NT31C-ST142@-EV2.
Page 293 Appendix I Relationship between System Program and Hardware Combining a -EV1 Version and Version without a -EV@ Suffix Hardware NT31-ST121@-E NT31-ST121@-EV1 NT31C-ST141@-E NT31C-ST141@-EV1 System program Ver. 1.0@ The following functions cannot be used The following functions cannot be used • Analogue meter •...
Page 294 Relationship between System Program and Hardware Appendix I Combining a -EV2 Version and Version without a -EV@ Suffix Hardware NT31-ST121@-E NT31-ST121/122@-EV2 NT31C-ST141@-E NT31C-ST141/142@-EV2 System program Ver. 1.0@ The following functions cannot be used The following functions cannot be used • Analogue meter •...
Page 295: I Relationship Between System Program And Hardware
Appendix I Relationship between System Program and Hardware...
Page 296: Model List
Appendix J Model List Model Specification NT31-ST123-EV3 STN monochrome display, beige NT31-ST123B-EV3 STN monochrome display, black NT31C-ST143-EV3 STN color display, beige NT31C-ST143B-EV3 STN color display, black Host Link Units Model Specification Applicable PLC 3G2A6-LK201-EV1 CPU-mounting Unit with RS-232C connector C-series...
Page 297 Appendix J Model List CPU Units for Connection via a Host Link Model Specification PLC Type CPM1-10CDR-@ RS-232C adapter/RS-422A adapter connected C-series CPM1-20CDR-@ to the peripheral port CPM1 CPM1A-10CD@-@ CPM1A-20CD@-@ CPM1A-30CD@-@ CPM1A-40CD@-@ CPM2A-30CD@@-@ Features a 9-pin connector for RS-232C con- C-series CPM2A-40CD@@-@ nections...
Page 298 Appendix J Model List CPU Units for Connection via a 1:1 NT Link Model Specification PLC Type CPM1-10CDR-@ RS-232C adapter connected to the peripheral port C-series CPM1-20CDR-@ (RS-422A adapter cannot be used) CPM1 CPM1A-10CD@-@ CPM1A-20CD@-@ CPM1A-30CD@-@ CPM1A-40CD@-@ CPM2A-30CD@@-@ Features a 9-pin connector for RS-232C connections C-series CPM2A-40CD@@-@ CPM2A...
Page 299 Appendix J Model List CPU Units for Connection via a 1:N NT Link Model Specification PLC Type (*1) Features a 9-pin connector for RS-232C connections C-series CQM1H-CPU51 (*1) CQM1H CQM1H-CPU61 Features a connector for RS-232C connections (selectable/9- C-series C200HE-CPU32-(Z)E pin) C200HE-CPU42-(Z)E C200HE(-Z)E Features a connector for RS-232C connections (selectable/9-...
Page 300: Rs-232C/Rs-422A Adapter
Spare battery * The Support Tool indicated above includes the system installer and the standard system programs (Ver. 3.@/ Ver. 4.@) for the NT31, NT31C, NT631, and NT631C. System programs for the earlier NT30/620 PTs are also included. Cables with Connectors for PT ↔ PLC/NT-AL001-E...
Page 301 Cable for Peripheral Port of CS/CJ-series PLC Model Specification Made by OMRON (CS-series peripheral port ↔ D-Sub, 9-pin, female) CS1W-CN118 Connecting Cable for the CPM2C Communications Connector Model Specification Made by OMRON (CPM2C communications port ↔ D-Sub, 9-pin, female, C-series periph- CPM2C-CN111 eral port)
Page 302: Option List
NT31C-ST141@-EV2 Only) This is a backlight (CFL unit) for replacement purposes. Protective Sheet ... NT30-KBA04 (Used for Both NT31/NT31C) Stuck to the display to prevent irregular reflection or contamination. The entire sheet is colorless and transpar- ent. The five sheets make a set.
Page 303 Appendix K Option List Chemical-resistant Cover ... NT30-KBA01 Covers the front panel and protects it from various chemical agents. The entire sheet is milky white and made of silicone rubber. The sheet offers protection against the following chemical agents. Protects against Does not protect against Boric acid Hexane...
Page 304 Appendix K Option List Memory Unit ... NT-MF261 This is a dedicated unit for reading/writing the screen data and the system programs in an NT31/NT31C. Data is transmitted by DIP switch setting at the Memory Unit.
Page 305 Appendix K Option List...
Page 306: Index
Comm. A Method 1:N connection among RS-422A ports Comm. B Method 1:N connection among RS-485 ports Comm. B Select 1:N connection between RS-422A/485 at the NT31/NT31C Communications Board and RS-232C at the host Communications Boards Communications by Using Memory Link...
Page 307 Index Display device Inspection method Display specifications Installation environment Displaying and printing the display history record Installation in the operation panel Displaying/setting the calendar and clock Downloading the system program Life expectancy (backlight) Life expectancy (display panel) Effective display area Life expectancy (touch panel) Enclosure ratings Error messages...
Page 308 Setting the "Key Press Sound" Precautions to be observed when transmitting screen data Setting the "Print Method" Setting the "Printer Controller" Principal functions of NT31/NT31C Setting the "Start-up Wait Time" Printer cable Setting the automatic reset function Printer connector...
Page 309 Index Transmitting the screen data Transporting and storing the NT31/NT31C Usable systems (programming console function) Using a Memory Unit(NT31/NT31C with V1) Using an RS-232C/RS-422A Adapter Vibration resistance (operating) View angle Warning label Waterproofed Weight...
Page 310: Revision History
Page 242: Added information on backlight replacement for new models, and changed model numbers. Page 243: Changed “NT31/NT31C” to “PT” in text and changed model numbers in graphic. Page 246: Changed and added information in table on power supply voltage and backlight brightness.
Page 311 Revision History...
Page 312 OMRON ELECTRONICS LLC One Commerce Drive Schaumburg, IL 60173-5302 U.S.A. Tel: (1) 847-843-7900/Fax: (1) 847-843-7787 OMRON ASIA PACIFIC PTE. LTD. No. 438A Alexandra Road # 05-05/08 (Lobby 2), Alexandra Technopark, Singapore 119967 Tel: (65) 6835-3011/Fax: (65) 6835-2711 OMRON (CHINA) CO., LTD.
Page 313 Authorized Distributor: Cat. No. V062-E1-04 Note: Specifications subject to change without notice Printed in Japan This manual is printed on 100% recycled paper.
