Relationship between System Program and
Here, relationship between system program and hardware is described.
NT31/NT31C have following models.
NT31-ST121j-E Conventional product
NT31C-ST141j-E
NT31-ST121j-EV1 Version upgrade model of the products above
(12/98) (12/98)
NT31C-ST141j-EV1
NT31-ST121j-EV2 Version upgrade model of the products above
(12/99) (12/99)
NT31C-ST141j-EV2
System programs indicated below are installed for the models shown above in the default state. Also, system pro-
grams are supplied with the Support Tool as follows.
• System programs for NT31-ST121j-E/NT31C-ST141j-E: System Program Ver. 1.0j
(System programs supplied with NT-ZJ3AT1-EV2/ZJCAT1-EV2)
• System programs for NT31-ST121j-EV1/NT31C-ST141j-EV1: System Program Ver. 2.0j or 2.1j
(System programs supplied with NT-ZJ3AT1-EV3/ZJCAT1-EV3)
• System programs for NT31-ST121j-EV2/NT31C-ST141j-EV2: System Program Ver. 3.0j
(System programs supplied with NT-ZJCAT1-EV4)
(A system program for the earlier NT30/620 PTs is also included with the NT-ZJCAT1-EV4.)
These system programs have mutual compatibility, therefore, they can be installed and used for NT31-ST121
j-E
NT31C-ST141 /NT31-ST121j-EV1/NT31C-ST141j-EV1/NT31-ST121j-EV2/NT31C-ST141j-EV2
each.
However, there will be a limitation on function depending on the combination. Refer to the following table.
Limitations of System Program/PT Combinations
The following table shows only the relationship between the hardware and system program.
For details of the relationship with the screen data created using the Support Tool, refer to NT-series Support Tool
for Windows (Ver. 4.1) Operation Manual (V061-E1-j).
Combining a -V1 Version and Version without a -Vj Suffix
System program Ver. 1.0j
System program Ver. 2.0j or Ver. 2.1j
The system program's version can be checked from the System Menu.
*
Appendix I
Hardware
p
pg p
pg p
NT31-ST121j-E
NT31C-ST141j-E
The following functions cannot be used
S Analogue meter
S High-definition font display
S Installation of system programs using memory unit
S Connection to Mitsubishi PLCs
S Memory link
S Window control from the host
S Multiple display of window screens
S Moving a window
S Refer to the following table for details on new
functions supported by the -V2 versions.
The following functions cannot be used
S Installation of system programs using memory unit
S High-definition font display
S Refer to the following table for details on new
functions supported by the -V2 versions.
Hardware
NT31-ST121j-EV1
NT31C-ST141j-EV1
The following functions cannot be used
S Analogue meter
S High-definition font display
S Connection to Mitsubishi PLCs
S Memory link
S Window control from the host
S Multiple display of window screens
S Moving a window
S Refer to the following table for details on new
functions supported by the -V2 versions.
* Installation of system programs using memory unit
is possible
The new functions supported by the -V2 versions
cannot be used. Refer to the following table for details.
j-E
/
