Omron Programmable Terminals NT31 NT31C Setup Manual page 283

Model List
Model
CPM2C-10jjjjjj-j
CPM2C-20jjjjjj-j
CQM1-CPU41-EV1
CQM1-CPU42-EV1
CQM1-CPU43-EV1
CQM1-CPU44-EV1
CQM1-CPU45-EV1
CQM1H-CPU21
CQM1H-CPU51
CQM1H-CPU61
C200HS-CPU21-E
C200HS-CPU23-E
C200HS-CPU31-E
C200HS-CPU33-E
(*)
C200HE-CPU32-(Z)E
C200HE-CPU42-(Z)E
(*)
C200HG-CPU33-(Z)E
C200HG-CPU43-(Z)E
(*)
C200HG-CPU53-(Z)E
C200HG-CPU63-(Z)E
(*)
C200HX-CPU34-(Z)E
C200HX-CPU44-(Z)E
(*)
C200HX-CPU54-(Z)E
C200HX-CPU64-(Z)E
C200HX-CPU65-ZE
C200HX-CPU85-ZE
CV500-CPU01-EV1
CV1000-CPU01-EV1
CV2000-CPU01-EV1
CVM1-CPU01-EV2
CVM1-CPU11-EV2
CVM1-CPU21-EV2
* Either of the communication boards C200HW-COM02/COM04/COM05/COM06-EV1 is required.
CPU Units for Connection via a 1:N NT Link
Model
(*1)
CQM1H-CPU51
(*1)
CQM1H-CPU61
(*)
C200HE-CPU32-(Z)E
C200HE-CPU42-(Z)E
(*)
C200HG-CPU34-(Z)E
C200HG-CPU43-(Z)E
(*)
C200HG-CPU53-(Z)E
C200HG-CPU63-(Z)E
(*)
C200HX-CPU34-(Z)E
C200HX-CPU44-(Z)E
(*)
C200HX-CPU54-(Z)E
C200HX-CPU64-(Z)E
C200HX-CPU65-ZE
C200HX-CPU85-ZE
Specification
Connect to the RS-232C port of a CPM2C-CN111
Connecting Cable.
Features a 9-pin connector for RS-232C connections
Features a 9-pin connector for RS-232C connections
Features a connector for RS-232C connections
(selectable/9-pin)
Features a connector for RS-232C connections
(selectable/9-pin)
Features a connector for RS-232C connections
(selectable/9-pin)
Features a connector for RS-232C connections
(selectable/9-pin)
Features a connector for RS-232C connections
(selectable/9-pin)
Specification
Features a 9-pin connector for RS-232C connections
Features a connector for RS-232C connections (selectable/9-pin)
Features a connector for RS-232C connections (selectable/9-pin)
Features a connector for RS-232C connections (selectable/9-pin)
Appendix J
PC Type
C-series
CPM2C
C-series
CQM1
C-series
CQM1H
C-series
C200HS
C-series
C200HE(-Z)E
C-series
C200HG(-Z)E
C-series
C200HX(-Z)E
CVM1/CV-series
CV500
CV1000
CV2000
CVM1
PC Type
C-series
CQM1H
C-series
C200HE(-Z)E
C-series
C200HG(-Z)E
C-series
C200HX(-Z)E
279
