Connecting to the Host's RS-232C Port
1
5

5-1-4 Recommended Connectors, Cables, and Crimp Terminals

Usable Cables with Attached Connectors:
• For host link, 1:1 NT Link, or 1:N NT Link (+5 V power supplied from PC)
XW2Z-070T-1 (9-pin to 9-pin, 0.7 m)
XW2Z-200T-1 (9-pin to 9-pin, 2 m)
SJ46006-102
SSJ46006-202 (9-pin to 9-pin, 2 m)
NT-AL001 side
6
Abbreviation Pin number
Shielding wire
Connector
FG
hood
−
1
RS-232C SD 2
connector
RD 3
RS 4
5
CS
6
+5V
−
7
− 8
9
SG
9 (9-pin type)
Since the CS1G/H, CQM1H, and C200HX/HG/HE(-Z)E have a +5 V output,
no external power supply is required for the NT-AL001.
Connectors and Cables Recommended for RS-232C
When making an RS-232C connecting cable, as far as possible use the recom-
mended parts indicated in the table below. Some units come supplied with one
connector and connector hood.
Check the required parts and prepare them in advance.
Name Model
XM2A-0901
Connector
XM2A-2501
DB-25P
CS1H-CPU67-E(V1)
CQM1H-CPU51
C200HE-CPU32-(Z)E
C200HG-CPU33-(Z)E
C200HG-CPU53-(Z)E
C200HX-CPU34-(Z)E
C200HX-CPU54-(Z)E
C200HX-CPU65-ZE
(9-pin to 9-pin, 1 m)
PC side
Pin number Abbreviation
Connector
FG
hood
−
1
2 SD RS-232C
connector
3 RD
RS
4
5 CS
6 +5V
−
7
−
8
9 SG
(9-pin type)
Remarks
9-pin type
Made by OMRON
25-pin type
Made by OMRON
25-pin type
Made by JAE
Section 5-1
CQM1H-CPU61
C200HE-CPU42-(Z)E
C200HG-CPU43-(Z)E
C200HG-CPU63-(Z)E
C200HX-CPU44-(Z)E
C200HX-CPU64-(Z)E
C200HX-CPU85-ZE
6
1
9
5
Delivered with
CS1-series CS1G/H
C-series CQM1, C200HS,
C200HX/HG/HE(-Z)E
CVM1/CV-series CPUs
CV500-LK201
C500-LK203
3G2A5-LK201-EV1
C200H-LK201-V1
3G2A5-LK201-EV1
3G2A6-LK201-EV1
