Summary of Contents for Oce 750

  • Page 1 Recycled paper is used for the inside pages of this book. Océ 750 User's Manual...
  • Page 2 MAINTENANCE AGREEMENT Océ 750 Printer will give you many years of trouble-free service. To ensure high-quality printing performance and to prevent premature wear or failure of precision parts and components, schedule periodic cleaning and routine adjustments. We recommend that you contact your service center to discuss the benefits and advantages of Océ's Customer Service Maintenance Agreement and to be shown how a maintenance plan can be tailored to your individual printing needs.

  • Page 3: Section 1: Introduction

    Section 1: Introduction To the User ..Features Overview ..Introduction 1-1...
  • Page 4 Introduction To the User Welcome to the Océ 750 Printer, which includes the main body engine, the print controller, and the optional network interface card. Separate user documentation is provided with the print controller and the network interface card. This User's Manual describes the layout of the main body machine configured with both standard and optional equipment and explains control panel functions and procedures for all operations.
  • Page 5 Network Interface Card, enabling the system to function as a network printer or print server on the network. The Océ 750 electronically digitizes images then outputs in various ways controlled by software. The digitized image is represented as pixels on a screen or as dots per inch (dpi) on hard print.
  • Page 6 (10 ~ 150mm) permits in manual or auto mode. • Reserve Scans subsequent print jobs while the Océ 750 is busy printing or printing. • Resolution (400dpi, 600dpi) 400dpi and 600dpi resolution modes provide optimal image quality for photos, complicated graphics and text requiring high to very high compression.
  • Page 7 Introduction Introduction 1-5...

  • Page 9: Table Of Contents

    Section 2: Safety Information User Instruction ..Machine Safety Labels ..Label Locations ..2-3 Regulations ..FCC Regulations ..2-5 Canadian Department of Communications Regulations ..2-5 FDA Regulations ..2-5 Installation and Power Requirements ..Machine Handling and Care ..Routine Safety ..

  • Page 10: Machine Safety Labels

    Safety Information User Instructions The following pages include important safety information, which you must read and understand before you attempt to operate the printer. If you have any concerns about safety matters, please contact your service representative. Keep this manual permanently located with the printer, so that this safety information is readily available.

  • Page 11: Label Locations

    Safety Information Machine Safety Labels (continued) Label Locations CAUTION ATTENTION PRECAUCION CUIDADO WARNING Alta temperatura. NÃO This internal area is very Cette zone interne est Esta zona interior está TOQUE nesta área très chaude. Pour éviter hot. To avoid getting muy caliente.
  • Page 12 Safety Information Machine Safety Labels (continued) Label Locations (continued) Tray 1 Tray 2 CAUTION CAUTION ATTENTION PRECAUCION DO NOT put your hand CUIDADO between the main body and tray; otherwise you may be injured. Tray 3 (Finisher / Finisher-Binder) CAUTION Use care after opening the paper exit outlet.

  • Page 13: Regulations

    Regulations FCC Regulations Warning: The Océ 750 generates, uses, and can radiate radio frequency energy. If it is not installed and used in accordance with the instruction manual, interference with radio communications may result. This equipment has been tested and found to comply with...

  • Page 14: Installation And Power Requirements

    Safety Information Installation and Power Requirements CAUTION: FAILURE TO HEED THE FOLLOWING CAUTIONS MAY RESULT IN BODILY INJURY AND/OR MACHINE DAMAGE FIRE PREVENTION Install machine away from flammable or volatile materials. Routinely check for abnormal heat from power cord and/or plug. SHORT CIRCUIT FROM WATER DAMAGE Do not install or operate this equipment outdoors near a lake, pond, or river, etc.;...
  • Page 15 Safety Information Installation and Power Requirements (continued) CAUTION: FAILURE TO HEED THE FOLLOWING CAUTIONS MAY RESULT IN MACHINE DAMAGE, OVERHEATING, RISK OF ELECTRICAL SHOCK, AND/OR PERSONAL INJURY PLUG SOCKET A plug socket is limited in capacity. Use an exclusive power source for this machine; otherwise, overheating and/or smoking may occur.

  • Page 16: Machine Handling And Care

    Safety Information Machine Handling and Care WARNING: FAILURE TO HEED THE FOLLOWING WARNING MAY RESULT IN DEATH OR SERIOUS INJURY AND/ OR MACHINE DAMAGE MACHINE CONTACT Never touch internal high voltage area indicated with a WARNING label. Never touch the drum surface. Never put your hand into the developing unit when removing mishandled paper.

  • Page 17: Routine Safety

    Safety Information Routine Safety CAUTION: FAILURE TO HEED THE FOLLOWING CAUTIONS MAY RESULT IN MACHINE DAMAGE, OVERHEATING, AND/OR PERSONAL INJURY PERIODIC CHECK Check for loose connection or excessive heat on power plug, damage to power cord and/or plug (creased, frayed, scratched or cut, etc.). Be sure the plug is inserted fully, and ground wire is connected correctly.

  • Page 18: Finisher Capacity Requirements

    500 sheets (5.5"x8.5"R) 3,000 sheets (8.5"x11", 8.5"x11"R) 1,500 sheets (11"x17", 8.5"x14") The Secondary (sub) tray can be unloaded while the Océ 750 is running. Set production is not limited by the capacity of the Secondary (sub) tray. Primary (Main) tray: Staple-Sort mode 1,000 sheets* (11"x17"...
  • Page 19 Safety Information Finisher Capacity Requirements (continued) CAUTION: FAILURE TO HEED THE FOLLOWING CAUTIONS MAY RESULT IN BODILY INJURY AND/OR MACHINE DAMAGE FINISHER-FOLDER MODE OUTLET Inside the Booklet mode outlet is the roller drive unit. DO NOT put your hand into it when removing the folded or stapled &...
  • Page 21 Section 3: Machine Information Océ 750 Overview ..Key Operator Functions ..3-3 Service, Repairs and Supplies ..3-3 Machine Labels ..3-3 Service Settings ..3-4 External Machine ..Internal Machine ..Standard Equipment ..Optional Equipment ..Finisher/Large Capacity Tray ..3-10 Trimmer Unit ..

  • Page 22: Section 3: Machine Information

    This timesaving system allows you to work with optimal efficiency while the printer is operating at peak capacity. The advanced finishing system of the Océ 750 provides you with the option of sending print jobs to the output tray face down and in correct order.

  • Page 23: Key Operator Functions

    Machine Information Océ 750 Overview (continued) Key Operator Functions Access to the Key Operator mode may require entry of a Key Operator password previously set by your service representative. A Key Operator may make various custom settings that affect printer functions. We recommend using a password to limit access to the Key Operator mode to an authorized person.

  • Page 24: Service Settings

    Setting changes for the following functions can be made by your service representative. Finisher-Paper Capacity In the default condition, the Océ 750 will produce unlimited sets. If required, your service representative can set the printer to stop printing when the number of prints exceeds specified capacity.

  • Page 25: External Machine

    Machine Information External Machine LCD touch screen Control panel Finisher / Finisher- Multi-sheet Folder (option) bypass tray LCT top door Power switch Left side cover (not shown) Front door Left door Tray 1 Tray 2 Tray 3 LCT left side Right side door (not shown) door Tray 4 : Large capacity...
  • Page 26 Machine Information External Machine (continued) Punch unit Finisher-Folder (option) (option) Trimmer stacker cover LCT top door Trimmer unit (option) LCT left side door Tray 4: Large capacity tray (11 x 17) (option) 2 LCT top door opens to allow loading paper. 3 Tray 4: Large capacity tray (11 x 17) option holds 4,000 sheets.

  • Page 27: Internal Machine

    Machine Information Internal Machine qToner bottle iConveyance part wToner unit eDrum unit uFixing part rLever A yKnob tConveyance/Fixing unit 1 Toner bottle holds toner and must be replaced when refilling toner. 2 Toner unit holds the toner supply. 3 Drum unit forms the print image. 4 Lever A can be moved to withdraw the conveyance fixing unit for removal of mishandled paper.

  • Page 28: Standard Equipment

    Machine Information Standard Equipment Main Body with 3 Paper Trays (500/500/1,000 sheets) Automatic Duplex Unit (ADU) Multi-Sheet Bypass Tray (150 Sheets) Optional Equipment Finisher (with 2 exit trays) Secondary (sub) tray with 4 output types specified on Finisher Mode Selection Screen (1) Face down non-sort exit (2) Face up non-sort exit (3) Face down group exit...
  • Page 29 Machine Information Optional Equipment (continued) Punching Unit Cover Sheet Feeder (Post Inserter) Trimmer Unit Large Capacity Tray (8.5 x 11) (4,000 sheets) Large Capacity Tray (11 x 17) (4,000 sheets) Expanded Memory Unit-64MB /128MB Network Print Controller 75 PostScript 3 Enabler 75 Ethernet Card 75 Machine Information 3-9...

  • Page 30: Finisher/Large Capacity Tray

    Machine Information Optional Equipment (continued) Finisher/Large Capacity Tray Finisher / Finisher-Folder details Secondary (sub) tray: Cover sheet feeder (option): Holds sets ejected in Holds cover sheets for use in Cover q Non-sort Face Down exit mode Sheet output mode or a printed set in w Non-sort Face Up exit mode manual stapling mode.

  • Page 31: Trimmer Unit

    Machine Information Optional Equipment (continued) Trimmer Unit Trimmer unit details Finisher-Folder Trimmer stacker cover: opens to allow you to take out the finished sets. Trimmer unit tray: slides to the left side each time a trimmed booklet is delivered. Front-right cover: opens to allow removal of mishandled paper.

  • Page 32: Punching Unit

    Machine Information Optional Equipment (continued) Punching Unit Punch Unit details Upper lever: opens upward to allow removal of mishandled paper. Punching unit knob: Right lever: can be turned to ease opens upward to allow removal of mishandled removal of mishandled paper.

  • Page 33: Site Requirements

    (1845) 141.7 (3599) Océ 750 + Finisher-Folder + Punch Unit + Trimmer Unit + Large Capacity Tray (11 x 17) NOTES: 1 Dimensions are in inches with millimeters included in parentheses. 2 The Finisher main tray of the Finisher / Finisher-Folder gradually goes down while printed material is output.

  • Page 34: Specifications

    Machine Information Specifications Product Name Océ 750 Printer Engine Type Dual Beam Laser, Electrostatic Engine Speed 75 pages per minute (400dpi) 55 pages per minute (600dpi) Recommended Operating Environment 50°~86°F (10°~30°C); 10~80% Relative Humidity Warm Up Approx. 6 min. @68°(20°C); 50% Relative Humidity Voltage 208 ~ 240V AC ±...
  • Page 35 Machine Information Specifications (continued) Paper Weight 20 lb~24 lb bond recommended (Max. range: 16 lb~45 lb in 2-2 mode 16 lb~110 lb (200g/m thick paper) in 1-1mode OHP sheet, Transparency, Labels, Tab, 3-hole Options Finisher / Finisher-Folder Cover Sheet Feeder (Post Inserter) Trimmer Unit Large Capacity Tray (LCT) (8.5 x 11) Large Capacity Tray (LCT) (11 x 17)
  • Page 36 Machine Information Specifications (continued) Automatic Duplex Unit (ADU) Paper size: 11"x17", 8.5"x14", 8.5"x11", 5.5"x8.5" Paper weight: 16~45 lb Paper curl limit: 20 mm or less Non-stack type Stapling (Finisher/Finisher-Folder) Power source: Main body Non-sort/Sort/Group mode: 500 sheets 5.5"x8.5"R 3000 sheets 8.5"x11"/R 1500 sheets 11"x17", 8.5"x14"...
  • Page 37 Machine Information Specifications (continued) Trimmer Unit Paper size : 11"x17", 8.5"x14", 8.5"x11"R, A4R (8.27"x11.69", 210mmx297mm) Paper weight : 16 ~ 45 lb * One 110 lb cover paper (200g/m thick paper) is available. Number of trimmed sheets : 3 sheets max. with Folding mode 16 sheets max.
  • Page 39 Section 4: Media Information Main Body Trays ..Large Capacity Tray (8.5 x 11) (Option) ..Large Capacity Tray (11 x 17) (Option) ..Automatic Duplex Unit ..Multi-Sheet Bypass Tray and Tab Sheets ..Finisher / Finisher-Folder (Option) ..Primary (Main) Tray ..

  • Page 40: Main Body Trays

    Media Information Main Body Trays Standard Paper Size: 11"x17", F4, 8.5"x14", 8.5"x11", 8.5"x11"R, 5.5"x8.5", A3, B4, A4, A4R, B5, B5R, A5 (user-adjustable) NOTES: • F4: 8"x13", 203mm x 330mm A3: 11.69"x16.54", 297mm x 420mm B4: 10.11"x14.33", 257mm x 364mm A4: 8.27"x11.69", 210mm x 297mm B5: 7.17"x10.11", 182mm x 257mm A5: 5.85"x8.27", 148mm x 210mm •...

  • Page 41: Large Capacity Tray (8.5 X 11) (Option)

    Media Information Large Capacity Tray (8.5 x 11) (Option) Standard Paper Size: 8.5"x11" or A4 (service-adjustable) Wide Paper Size: 8.5"x11"W or A4W (service-adjustable) Paper Weight: 16~24 lb LCT in Thick 1: 25~45 lb LCT in Thick 2: 46~110 lb (200 g/m thick paper) in 1-1 mode only NOTE: Paper type setting (Thick1 or Thick 2) for LCT can be made in the Key Operator mode.

  • Page 42: Automatic Duplex Unit

    Media Information Automatic Duplex Unit Standard Paper Size: 11"x17"~5.5"x8.5" Wide Paper Size: 11"x17"W~5.5"x8.5"W NOTE: 5.5"x8.5"/W print paper is available in portrait orientation feeding only. Paper Weight: 16~45 lb Multi-Sheet Bypass Tray Loading Paper Size: Max. 12.36"x17.52" (314mm x 445mm) ~ Min. 3.94"x5.83" (100mm x 148mm) Specified Size Automatically: 11"x17", 8.5"x14", 8.5"x11", 8.5"x11"R, 5.5"x8.5", 5.5"x8.5"R, A3, B4, A4, B5, B5R Specified Size Manually / STD Size (Special) : F4, A4R, A5, A5R...

  • Page 43: Finisher / Finisher-Folder (Option)

    Media Information Finisher / Finisher-Folder (Option) In-Bin Stapler Finisher / Finisher-Binder accepts LEDGER (11"x17"), LEGAL (8.5"x14") and LETTER/R (8.5"x11"/R) standard/wide paper sizes (5.5"x8.5"R/W in Non-sort, Sort or Group mode). Primary (Main) Tray In-Bin Stapler Finisher / Finisher-Folder (capacities at 20lb, unless otherwise indicated) Non-sort/Sort/Group mode: 500 sheets 5.5"x8.5"/5.5"x8.5"W, 5.5"x8.5"R/5.5"x8.5"WR (A5/A5W, A5R/A5WR)
  • Page 44 Media Information Finisher / Finisher-Folder (Option) (continued) Finisher / Finisher-Folder Booklet Tray Folding mode: Standard Paper Size : 11"x17", 8.5"x14", 8.5"x11"R, A3, B4, A4R Wide Paper Size : 11"x17"W, 8.5"x11"WR, A3W, B4W, A4WR Paper Weight : 16 ~ 24 lb Number of Folded Sheet : 3 sheets max.

  • Page 45: Cover Sheet Feeder (Post Inserter) (Option)

    Media Information Cover Sheet Feeder (Post Inserter) (Option) Standard Paper Size : 11"x17", 8.5"x14", 8.5"x11", 8.5"x11"R, 5.5"x8.5", A3, B4, A4, A4R, B5, A5 Wide Paper Size : 11"x17"W, 8.5"x11"W, 8.5"x11"WR, 5.5"x8.5"W, A3W, B4W, A4W, A4WR, B5W, A5W Paper Weight in Cover Sheet Mode : 13 ~ 110 lb (200g/m thick paper) Paper Weight in Manual Staple : 16 ~ 24 lb Paper in Punching Unit (Option)

  • Page 46: Paper Supply Message

    Media Information Paper Supply Message When the paper size specified by the driver is not set in the tray or when paper runs out, the following message is displayed on the screen. In addition, the tray size indicator and the paper supply indicator will blink in the Tray size area of the screen. The paper types specified for the main body trays and LCT (trays 1/2/3/4) are set in the Key Operator mode.

  • Page 47: Paper Weight Compatibility Chart

    Media Information Paper Weight Compatibility Chart Main Body Trays All Trays: 16 ~ 24 lb Tray specified in Thick 1: 25 ~ 45 lb Tray specified in Thick 2: 46 ~ 110 lb (200g/m thick paper) in 1-1 or 2-1 only 16 ~ 24 lb Large Capacity Tray LCT specified in Thick 1: 25 ~ 45 lb...

  • Page 49: Section 5: Printing Operations

    Section 5: Printing Operations Introduction ..Wake Up Screen ..5-2 Warm Up Screen ..5-2 Control Panel ..The Basic Screen ..Check Mode Message ..Check Mode Screen ..5-4 Reservation List ..Screen Display ..5-5 Help Mode ..Change Job Order ..

  • Page 50: Wake Up Screen

    Printing Operations Introduction The Océ 750 printer control panel screen described in this section includes the LCD display screen, basic control panel operations and a sampling of screen messages you will encounter when using this printer. Technical details of the LCD as well as a complete Message List can be found in the Service Manual.

  • Page 51: Control Panel

    Printing Operations Control Panel TIMER POWER SAVER ON / OFF CHECK HELP STOP / PAUSE COUNTER CLEAR QTY. START The control panel is user-friendly and easy to operate. On the right are the Weekly Timer indicator and buttons to select [ ], [ ] and [ ] keys.

  • Page 52: Check Mode Message

    Printing Operations Check Mode Message When the temporary stop function is specified by the driver, the following message displays on the Basic Screen. When the [ ] key is pressed the Printer Check Screen will be displayed. CHECK When the [ ] key is pressed, printing will begin.

  • Page 53: Reservation List

    Printing Operations Reservation List Screen Display The reservation list screen displays after the main power switch is turned on and warm up is completed. When no Job is reserved, the screen looks like the screen shown below. Notice that the key and the key are shaded, which JOB PRIORITY...

  • Page 54: Change Of Job Order

    Printing Operations Change Job Order When a reserved Job is listed on the screen, you may select the Status display key to highlight the Job and then press the Job Priority key to change the order of priority. (See screens below.) Screen without Job Priority change Screen with Job Priority change Note that it is not possible to change the priority of a Job in the process of printing.

  • Page 55: Job Deletion

    Printing Operations Job Deletion Touch the Status key to highlight a Job, then touch the key to delete the JOB DELETE Job. Before the Job is deleted, a pop up screen allows you to confirm the deletion. Touch to delete the Job. Touch to keep the Job.

  • Page 56: Previous Job List

    Printing Operations Previous Job List The previous Job list can be displayed by pressing the Previous Job List key at the bottom of the screen. The sample below shows that four previous Jobs per screen can be displayed. If more Jobs are able to be displayed, up and down arrow keys will become available at the bottom of the screen.

  • Page 57: Change Setting

    Printing Operations Change Setting While printing in the Staple Sort mode, printing will stop and the machine will go into the wait mode in the event the machine detects mixed originals with different widths that cannot be stapled. The key enables you to change the setting and CHANGE SETTING restart the Job.

  • Page 58: Print Size

    Printing Operations Print Size Selecting Paper Type/Size for Multi-Sheet Bypass Tray 1 Open the Multi-sheet bypass tray, and load the print paper on the tray. See p. 7-4, p. 7-7 for further details. 2 Touch Bypass key, then touch . The Paper Type/Size Selection PAPER TYPE/SIZE Screen will be displayed.

  • Page 59: Controller Screen

    Printing Operations Controller Screen The Controller screen displays separate sections for Messages, Icons, the Main Menu, and a Main window. • The Message section displays the characters sent from the controller and include a max. of 40 digits x 2 lines. •...

  • Page 60: Auto Low Power Mode

    Printing Operations Auto Low Power Mode Auto Low Power mode enables you to conserve energy by maintaining a lower fixing temperature during periods of printer inactivity. Auto Low Power mode automatically lowers the power after a specified period of printer inactivity as specified in the Key Operator mode.

  • Page 61: The Counter List

    Printing Operations The Counter List This function allows you to view the current status of items shown on the touch panel, such as Total Counter and Counter Start Date. View the Counter List 1 To display the Counter List, press [ P (COUNTER) 2 After viewing the Counter List, touch to return to the Basic Screen.

  • Page 62: Weekly Timer Function

    Printing Operations Weekly Timer Function When the printer is using the weekly timer function, the TIMER indicator on the right side of the control panel is lit. Important: When the TIMER indicator is lit, the printer will automatically be turned off. Do not turn it off by pressing power switch.

  • Page 63: Printing Operations

    Printing Operations Weekly Timer Function (continued) Timer Interrupt (continued) 1 Enter a 4-digit number Timer Interrupt password using the keypad on the control panel. If an invalid password is entered, enter a valid 4-digit password. Timer interrupt mode Enter password 2 Press [START].
  • Page 65 Section 6: Output Modes Finisher / Finisher-Folder Specifications ..Finisher Type ..6-2 Primary (Main) Tray ..6-2 Secondary (Sub) Tray ..6-3 Booklet Tray (Finisher-Folder only) ..6-3 Cover Sheet Feeder (Post Inserter) ..6-3 Punching Unit ..6-4 Trimmer Unit Tray (Finisher-Folder only) ..

  • Page 66: Section 6: Output Modes

    Output Modes Finisher / Finisher-Folder Specifications Use only paper that is recommended by Konica and stored under specified conditions. Special stock is not guaranteed for reliability or print quality. Multi-sheet bypass tray, and Transparency interleaving are incompatible with finisher use. This Finisher also accommodates wide paper sizes in addition to the standard sizes described below.

  • Page 67: Secondary (Sub) Tray

    Output Modes Finisher / Finisher-Folder Specifications (continued) Secondary (Sub) Tray Non-sort and face down exit Non-sort and face up exit Group and face down exit Group and face up exit Paper size: 11"x17"~5.5"x8.5" Paper weight: 16~24 lb Paper capacity for 20 lb: 200 sheets Booklet Tray (Finisher-Folder only) Folding Mode Paper size: 11"x17", 8.5"x14", 8.5"x11"R, A4R (8.27"x11.69", 210mmx297mm)

  • Page 68: Trimmer Unit Tray (Finisher-Folder Only)

    Output Modes Finisher / Finisher-Folder Specifications (continued) Punching Unit Punching Mode Punching mode is available in combination with Primary (Main) Tray output modes Paper size: 11"x17", 8.5"x11" Paper weight: 16~45 lb Number of holes: 3 holes Hole diameter: 0.315" ± 0.020" (8.0 mm ± 0.5 mm) Hole pitch: 4.252"...

  • Page 69: Non-Sort Mode Using Primary (Main) Tray

    Output Modes Non-Sort Mode Using Primary (Main) Tray Non-Sort mode simply means that the offset-stacker finisher modes are not selected. Prints will be stacked upon exit without being offset by sorted sets. With the Primary (main) tray initially selected on the Finisher Mode Selection Screen, Finisher / Finisher-Binder outputs the printed sheets FACE DOWN in the proper order.

  • Page 70: Sort Mode Using Primary (Main) Tray

    Output Modes Sort Mode Using Primary (Main) Tray Use this mode when you want to output multiple prints of the original set, and have each sorted set offset upon exit. The staple mode can be selected with the sort mode. With the Primary (main) tray initially selected on the Finisher Mode Selection Screen, Finisher / Finisher-Folder outputs the printed sheets FACE DOWN in the proper order.

  • Page 71: Staple-Sort Mode Using Primary (Main) Tray

    Output Modes Staple-Sort Mode Using Primary (Main) Tray Use this mode when you want to offset and staple each printed set. Stapling position and number of staples (1 or 2) can be designated on the screen. Each finished set will be offset from the next printed set. With the Primary (main) tray initially selected on the Finisher Mode Selection Screen, Finisher / Finisher-Binder outputs the printed sheets FACE DOWN in the proper order.

  • Page 72: Folding, Stapling & Folding And Trimming Modes

    Output Modes Folding, Stapling & Folding and Trimming Modes The Folding and Stapling & Folding modes are available only when the Finisher-Binder option is installed. The Trimming modes (Folding and Trimming, Stapling & Folding and Trimming) are available only when the Trimmer unit option is installed on the Finisher- Binder.
  • Page 73 Output Modes Folding, Stapling & Folding and Trimming Modes (continued) Trimmer Unit tray capacity: When the Trimmer Unit tray capacity is exceeded, the finisher and Trimmer Unit will stop operating. Select an appropriate print quantity referring to the following capacity. Approx.

  • Page 74: Punching Mode

    Output Modes Punching Mode The Punching mode is available only when the Punch Unit option is installed on the Finisher-Folder. When the Punching mode is selected in combination with any of the Primary (Main) tray output modes, each copied sheet is punched and output to the Primary tray according to the selected output mode.

  • Page 75: Cover Sheet Feeder (Post Inserter)

    Output Modes Cover Sheet Feeder (Post Inserter) The Cover Sheet Feeder is available as an option on the Finisher / Finisher-Folder. Load cover sheet paper into this device and use the sheets as front covers for printed sets output to the Main tray; or use the sheets as booklet type covers for printed sets output to the Booklet tray in the Folding or Stapling &...

  • Page 76: Manual Stapling

    Output Modes Manual Stapling The Manual Stapling function is available only with the Cover Sheet Feeder (Post Inserter) option installed on the Finisher / Finisher-Folder. To use this function, simply place a set of paper to be stapled into the cover sheet feeder of the finisher, select the desired staple mode from the manual stapling operation panel located on the top of the finisher, then press the [ ] key.
  • Page 77 Output Modes Manual Stapling (continued) MANUAL OPERATION Staple Mode Staple Start/Stop button Selection button 1 Place a set of paper to be stapled into the cover sheet feeder, then align the guide plate. The indicator light of [ ] key will turn green. Staple Start/Stop NOTE: Refer to the specifications on previous page for available paper size in each mode.

  • Page 78: Output Mode For Machine Without Finisher

    Output Modes Output Mode for Machine without Finisher This section describes eight output modes for a printer without the finisher. Face down non-sort exit (default) Face up non-sort exit Face down rotation sort exit Face up rotation sort exit Face down group exit Face up group exit Face down rotation group exit Face up rotation group exit...
  • Page 79 Section 7: Maintenance & Supplies Loading Paper ..Paper Indicator ..7-2 Paper Empty Indicator ..7-2 Using the HELP Key ..7-2 Loading Paper in Tray 1, 2, and 3 ..7-3 Loading Paper in Multi-Sheet Bypass Tray ..7-4 Loading Paper in Tray 4 (Large Capacity Tray) ..

  • Page 80: Loading Paper

    Maintenance & Supplies Loading Paper Paper Indicator ( The Paper Indicator always lights on the tray key of the Basic Screen to indicate the paper level. Paper Empty Indicator ( The Paper empty indicator flashes on the tray key of the Basic Screen when a tray is empty.

  • Page 81: Loading Paper In Tray 1, 2, And 3

    Maintenance & Supplies Loading Paper (continued) Loading Paper in Tray 1, 2, and 3 When displaying Thick 1 or Thick 2 on the tray key of the Basic Screen, be sure to load the specified paper; otherwise mishandled paper may occur. When displaying TAB on the tray key of the Basic Screen, see p.

  • Page 82: Loading Paper In Multi-Sheet Bypass Tray

    Maintenance & Supplies Loading Paper (continued) Loading Paper in Multi-Sheet Bypass Tray The Multi-sheet bypass tray can be used to stack regular 16 lb~45 lb Bond paper. Bypass tray paper size: 11"x17"~5.5"x8.5" Bypass tray paper weight range: 16 lb~45 lb Bypass tray paper capacity: up to 150 sheets 20 lb Bypass tray Transparency film capacity: 1 sheet 1 Open the Multi-sheet bypass tray located on the right side of the printer.

  • Page 83: Loading Paper In Tray 4 (Large Capacity Tray)

    Maintenance & Supplies Loading Paper (continued) Loading Paper in Tray 4 (Large Capacity Tray) When displaying Thick 1 or Thick 2 on the tray key of the Basic Screen, be sure to load the specified paper; otherwise mishandled paper may occur. When displaying TAB on the tray key of the Basic Screen, see p.

  • Page 84: Loading Tabbed Sheets In Tray 1, 2, Or 3

    Maintenance & Supplies Loading Paper (continued) Loading Tabbed Sheets in Tray 1, 2, or 3 Load offset tabbed sheets so that the tab extensions are on the left at the rear (not front) of the tray. When loading tabbed sheets in the tray, be sure to specify the paper type as TAB in the Key operator mode;...

  • Page 85: Loading Tabbed Sheets In Multi-Sheet Bypass Tray

    Maintenance & Supplies Loading Paper (continued) Loading Tabbed Sheets in Multi-Sheet Bypass Tray Load offset tabbed sheets so that the tab extensions are on the right at the rear (not front) of the tray. The top sheet is designated face up as the first tab of the finished set. Subsequent offset tab sheets follow in sequence.

  • Page 86: Loading Tabbed Sheets In Tray 4 (Large Capacity Tray)

    Maintenance & Supplies Loading Paper (continued) Loading Tabbed Sheets in Tray 4 (Large Capacity Tray) Load offset tabbed sheets so that the tab extensions are on the right at the rear (not front) of the tray. When loading tabbed sheets in the tray, be sure to specify the paper type as TAB in the Key operator mode;...

  • Page 87: Adding Toner

    Maintenance & Supplies Adding Toner CAUTION Keep toner cartridge away from children. Although the toner is non-toxic, do not inhale it or allow it to enter your eyes. In case the toner comes in contact with eyes, please consult your physician. When toner supply is low, “Please add toner”...

  • Page 88: Inserting A New Staple Cartridge Into Finisher / Finisher-Folder

    Maintenance & Supplies Inserting a New Staple Cartridge into Finisher or Finisher-Folder Use only the staples supplied by Océ. Contact your service representative to reorder. 1 Open the Finisher door. 2 Pull out the stacker unit by holding the stacker unit handle. 3 Pull up the cartridge housing, then remove it while sliding it along the stapler rail.

  • Page 89: Empty Trash Basket Of Trimmer Unit

    Maintenance & Supplies Empty Trash Basket of Trimmer Unit When the waste basket becomes full, “Trash basket of Trimmer is full / Please empty trash basket” message displays on the touch screen. 1 Open the trimmer front door. Withdraw the trash basket. 2 Empty the trash basket.

  • Page 90: Empty Trash Basket Of Punching Unit

    Maintenance & Supplies Empty Trash Basket of Punching Unit When the trash basket becomes full, “Trash basket of Punching Unit is full / Please empty trash basket” message displays on the touch screen. 1 Open the Finisher/Punching Unit front door. Withdraw the trash basket. 2 Empty the trash basket.

  • Page 91: Preventive Maintenance

    Maintenance & Supplies Preventive Maintenance After a set number of prints have been made on your printer, Preventive Maintenance (PM) will be required for maintaining optimal performance. When preventive maintenance is due, a message will prompt you to contact your service representative for maintenance.

  • Page 92: Service, Repairs, Supplies

    Maintenance & Supplies Service, Repairs, Supplies Service Enter the name and telephone number of your service representative, plus the machine serial number in the space provided below: (Service Representative) (Tel. No.) (Machine Serial No.) Repairs When calling for repairs, be sure to have all necessary information at hand, such as the machine serial number and your own telephone number.

  • Page 93: Clearing Mishandled Paper

    Maintenance & Supplies Clearing Mishandled Paper Jam Location Screen When mishandled paper occurs, the Jam location shown below in Screen 1 indicates which Job has the Jam. To see the location of the mishandled paper and to view the Jam removal procedure, touch the Illustration explanation key in the upper right portion of the screen.

  • Page 94: Troubleshooting Tips

    Maintenance & Supplies Troubleshooting Tips PRINTER DOES NOT OPERATE WHEN POWER SWITCH IS ON Fully insert paper trays. Check to be sure power plug is firmly inserted in electrical socket. PRINT IMAGE IS TOO LIGHT Check toner indicator and add toner, if required. Check paper for dampness.
  • Page 95 Maintenance & Supplies Troubleshooting Tips (continued) FINISHER DOES NOT OPERATE Check for a paper misfeed and remove it as required. Properly close Finisher door. ADD TONER MESSAGE IS DISPLAYED New toner supply is needed. Follow instructions for adding toner. CALL FOR PM IS DISPLAYED IN MESSAGE AREA Contact your service representative for Preventive Maintenance.
  • Page 97 Section 8 : Key Operator Mode To the Key Operator ..How to Access the Key Operator Mode ..8-3 Function Menu Map ..System Initial Setting [1] ..Date & Time Setting [1] ..8-6 Language Select Setting [2] ..8-7 ECM (Electronic Copy Monitor) Function Setting [4] ..

  • Page 98: To The Key Operator

    Key Operator Mode To the Key Operator The Key Operator is trained to handle all special Key Operator functions that are not accessible to the general user, such as monitoring overall printer activity, machine performance, and service information, modifying machine settings; and controlling user activity, for billing purposes.

  • Page 99: How To Access The Key Operator Mode

    Key Operator Mode To the Key Operator (continued) How to Access the Key Operator Mode 1 Press the [ ] button on the Control panel to display the Help Screen. HELP 2 Then touch the on the Help Screen. Key Operator Mode The Key Operator Password Entry Screen displays when the 4-digit Key Operator password is set by your service representative.

  • Page 100: Function Menu Map

    Key Operator Mode Function Menu Map FUNCTION MENU SUB FUNCTION MENU AND SETTING OPTIONS [1] System initial setting [1] Date&Time setting: [Present time; Setting time; Summer time On/Off] [2] Language select setting: [Japanese; English] [4] E.C.M. Function [1] E.C.M. data edit: [Change; Add; Delete] setting [2] E.C.M.
  • Page 101 Key Operator Mode Function Menu Map (continued) FUNCTION MENU SUB FUNCTION MENU AND SETTING OPTIONS [14] Machine management [2] User management list [3] E.C.M. management list [4] Font pattern list [15] Call remote center [1] Call for JAM concerns [2] Call for SC concerns [3] Toner bottle supply call [4] Paper supply call [5] Call for image quality...

  • Page 102: System Initial Setting [1]

    Key Operator Mode System Initial Setting [1] Set the following initial conditions of the printer. • Date & Time setting: Current date and time, Summer time On/Off • Language select setting: Language used in LCD (English) Date & Time Setting [1] Set the current date and time, and also the summer time.

  • Page 103: Language Select Setting [2]

    Key Operator Mode System Initial Setting [1] (continued) Language Select Setting [2] Select the language used in the LCD (English). Default setting: English System Initial Setting Menu Screen Language Selection Screen 1 Press [ ] to display the Help Screen, then touch HELP Key Operator Mode Enter a 4-digit Key Operator password, then touch...

  • Page 106: Ecm (Electronic Copy Monitor) Function Setting [4]

    Key Operator Mode ECM (Electronic Copy Monitor) Function Setting [4] This function can only be accessed by the Key Operator after a 8-digit ECM master key code is entered. The Electronic Copy Monitor allows you to monitor all printing activity by controlling ECM password accounts.

  • Page 107: How To Access The Ecm Setting Mode

    Key Operator Mode ECM (Electronic Copy Monitor) Function Setting [4] (continued) How to Access the ECM Setting Mode Key Operator Mode Screen ECM Master Key Code Screen ECM Setting Menu Screen 1 Press [ ] to display the Help Screen, then touch HELP Key Operator Mode Enter a 4-digit Key Operator password, then touch...

  • Page 108: Data Edit [1]

    Key Operator Mode ECM (Electronic Copy Monitor) Function Setting [4] (continued) E.C.M. Data Edit [1] Use this setting to display the list of Print count and Print limit for each account, to change, add, or delete the ECM data, and to reset the Print count of the individual account.
  • Page 109 Key Operator Mode ECM (Electronic Copy Monitor) Function Setting [4] (continued) E.C.M. Data Edit [1] (continued) 1 Press [ ] to display the Help Screen, then touch HELP Key Operator Mode Enter a 4-digit Key Operator password, then touch to display the Key Operator Mode Screen.
  • Page 110 Key Operator Mode ECM (Electronic Copy Monitor) Function Setting [4] (continued) E.C.M. Data Edit [1] (continued) To Add ECM Data: (1) Touch on the ECM Data Edit Screen. The ECM Data Add Screen will be displayed. (2) Touch the desired item key to highlight it, then enter the data by using the touch screen keypad.
  • Page 111 Key Operator Mode ECM (Electronic Copy Monitor) Function Setting [4] (continued) E.C.M. Data Edit [1] (continued) 5 If other ECM setting changes are required, touch on the ECM PREVIOUS SCREEN Data Edit Screen to return to the ECM Setting Menu Screen. Touch desired key, from [1]~[3].

  • Page 112: All Count Reset [2]

    Key Operator Mode ECM (Electronic Copy Monitor) Function Setting [4] (continued) E.C.M. All Count Reset [2] Reset the count for all ECM accounts. ECM Setting Menu Screen ECM All Count Reset Screen 1 Press [ ] to display the Help Screen, then touch HELP Key Operator Mode Enter a 4-digit Key Operator password, then touch...

  • Page 113: Function Setting [3]

    Key Operator Mode ECM (Electronic Copy Monitor) Function Setting [4] (continued) E.C.M. Function Setting [3] Use this function to turn ECM On or Off; or to select whether the printer will stop at the time the count limit is reached, or after the current Print Job is completed. ECM Setting Menu Screen ECM Function Setting Screen 1 Press [...

  • Page 114: Paper Type / Special Size Set [6]

    Key Operator Mode Paper Type / Special Size Set [6] Use this function to indicate a specific paper type or to specify a special paper size for each tray key on the Basic Screen. This is especially useful when special paper is used on a regular basis and is always placed in a specific paper tray.
  • Page 115 Key Operator Mode Paper Type / Special Size Set [6] (continued) 1 Press [ ] to display the Help Screen, then touch HELP Key Operator Mode Enter a 4-digit Key Operator password, then touch to display the Key Operator Mode Screen. (See note.) 2 Touch to display the Paper Type Setting Screen.

  • Page 116: Panel Contrast / Key Sound Adjustment [7]

    Key Operator Mode Panel Contrast / Key Sound Adjustment [7] Use this feature to adjust the level of brightness of the touch screen portion of the control panel, and also the volume of the touch key. Key Operator Mode Screen Panel Contrast/ Key Sound Adjustment Screen 1 Press [ ] to display the Help Screen, then touch...

  • Page 117: Key Operator Data Setting [8]

    Key Operator Mode Key Operator Data Setting [8] Use this screen to enter the name and extension number of the Key Operator indicated on the Help Screen developed from the Basic Screen. Setting options: 5-digit key operator telephone extension; Max. 8-character key operator name Key Operator Mode Screen Key Operator Data Setting Screen 1 Press [...

  • Page 120: Weekly Timer [9]

    Key Operator Mode Weekly Timer [9] This function can be accessed only by the Key Operator after a unique 4-digit Weekly Timer master key code is entered. The Weekly Timer is a printer management function that shuts down power to the machine on a daily or hourly basis, and can be programmed specifically for lunch breaks, weekends and holidays, or any time the printer is not required.

  • Page 121: How To Access The Weekly Timer Setting Mode

    Key Operator Mode Weekly Timer [9] (continued) How to Access the Weekly Timer Setting Mode Key Operator Mode Screen Weekly Timer Master Key Code Screen Weekly Timer Setting Menu Screen 1 Press [ ] to display the Help Screen, then touch HELP Key Operator Mode Enter a 4-digit Key Operator password, then touch...

  • Page 122: Weekly Timer On/Off Setting [1]

    Key Operator Mode Weekly Timer [9] (continued) Weekly Timer On/Off Setting [1] Weekly Timer Setting Menu Screen Weekly Timer On/Off Setting Screen 1 Press [ ] to display the Help Screen, then touch HELP Key Operator Mode Enter a 4-digit Key Operator password, then touch to display the Key Operator Mode Screen.

  • Page 123: Timer Setting [2]

    Key Operator Mode Weekly Timer [9] (continued) Timer Setting [2] Use this function to set the On/Off times in hours and minutes for each day of the week or set the collective time for the entire week, i.e., the same On/Off time for each day. Weekly Timer Setting Menu Screen Weekly Timer On/Off Time Setting Screen Weekly Timer On/Off Time Collective Setting Screen...
  • Page 124 Key Operator Mode Weekly Timer [9] (continued) Timer Setting [2] (continued) 5 To set the ON/OFF time collectively for more than one day of the week, touch to display the Weekly Timer On/Off Time Collective Setting Collectively timer setting Screen. 6 When you open this screen, the ON and OFF times are always set at 00:00~00:00.

  • Page 125: Timer Action On/Off Setting [3]

    Key Operator Mode Weekly Timer [9] (continued) Timer Action On/Off Setting [3] Use this function to set the On/Off condition of the printer for a given month. Set the On- Off condition for specific days; or collectively, for all Mondays through Sundays of the given month.
  • Page 126 Key Operator Mode Weekly Timer [9] (continued) Timer Action On/Off Setting [3] (continued) 5 To collectively set the on/off data for the entire month by the day of the week, touch key for the desired day on the right half of the screen. If you touch an already-highlighted key, no change will occur.

  • Page 127: Lunch Hour Off Setting [4]

    Key Operator Mode Weekly Timer [9] (continued) Lunch Hour Off Setting [4] The Weekly Timer function turns the printer ON and OFF once a day. Use the Lunch hour off function to shut down power during the lunch break and then turn it on again according to the Weekly Timer function setting.

  • Page 128: Timer Interrupt Password Setting [5]

    Key Operator Mode Weekly Timer [9] (continued) Timer Interrupt Password Setting [5] Use this password setting mode to establish a 4-digit password requirement for using Timer Interrupt function. The default password of 0000 allows the timer function to be interrupted without the requirement for password entry. Weekly Timer Setting Menu Screen Timer Interrupt Password Setting Screen 1 Press [...

  • Page 129: Control Panel Adjustment [10]

    Key Operator Mode Control Panel Adjustment [10] Use this feature to check the LCD touch screen and realign the position of the touch sensor that may have shifted. Key Operator Mode Screen Control Panel Adjustment Screen 1 Press [ ] to display the Help Screen, then touch HELP Key Operator Mode Enter a 4-digit Key Operator password, then touch...

  • Page 130: Tray Size Setting [11]

    Key Operator Mode Tray Size Setting [11] Select whether the tray size setting will be detected or not detected when ATS/APS functions. If you select it to be detected, you may also select the priority of the detection for each tray. Key Operator Mode Screen 1 Key Operator Mode Screen 2 Tray Auto Select Setting Screen...

  • Page 131: Power Save Setting [12]

    Key Operator Mode Power Save Setting [12] Select the interval of time that must elapse before Auto Low Power and Auto Shut Off become activated. Auto Shut Off conserves more energy than Auto Low Power. The period of time selected for Auto Low Power cannot exceed the Auto Shut Off setting. Key Operator Mode Screen 1 Key Operator Mode Screen 2 Power Save Setting Screen...

  • Page 132: Memory Switch Setting [13]

    Key Operator Mode Memory Switch Setting [13] This function allows you to change the Memory Settings listed below. See p. 8-33 for details on Memory Settings. SW No. Item Setting (default is underlined) No. 09: Automatic tray switching OFF/ ON No.
  • Page 133 Key Operator Mode Memory Switch Setting [13] (continued) 4 Use the procedure below to select the desired item and change the setting. (1) To select the desired item, touch the arrow keys ( ) and ( ) at the right of the Memory Switch Setting Screen.

  • Page 134: Machine Management List Print [14]

    Key Operator Mode Machine Management List Print [14] Use this function to print out the list selected from the following items. • User management list: Home position settings selected by user • E.C.M. management list: Machine information managed by ECM •...

  • Page 135: Call Remote Center [15]

    Key Operator Mode Call Remote Center [15] When activated, the Remote Diagnostics option is automatically monitored by your service representative. In case of machine trouble, select the Call Remote Center option. Your service representative will contact you to determine the appropriate means for resolving the problem.

  • Page 136: Side 2 Lens Adjustment [16]

    Key Operator Mode Side 2 Lens Adjustment [16] Use this function to set the adjustment data of the magnification ratio for each tray as Side 2. Key Operator Mode Screen 2 Side 2 Lens Adjustment Screen 1 Press [ ] to display the Help Screen, then touch HELP Key Operator Mode Enter a 4-digit Key Operator password, then touch...

  • Page 137: Finisher Adjustment [17]

    Key Operator Mode Finisher Adjustment [17] Use this mode to make fine adjustments to each function of the finisher. Key Operator Mode Screen 2 Finisher Adjustment Menu Screen Stapling&Folding Stopper Position Adjustment Screen Folding Stopper Position Adjustment Screen Trimming Stopper Position Adjustment Screen Punch Adjustment Mode Screen Punch Vertical Position Adjustment Screen Punch Horizontal Position Adjustment Screen...
  • Page 138 Key Operator Mode Finisher Adjustment [17] (continued) 4 Touch the desired menu key to display the adjustment screen for each function. 5 Make fine adjustment on the screen. To go on or back to another adjustment screen, touch NEXT or PREVIOUS. Touching restores the Finisher PREVIOUS SCREEN Adjustment Menu Screen.

  • Page 139: Key Operator Ecm Form

    Key Operator Mode Key Operator ECM Form Password Count/Limit Password Count/Limit Key Operator Mode 8-39...

  • Page 141: Index 1

    Index Index 1...
  • Page 142 Index Adding Toner 7-9 Machine Labels 2-2 ~ 2-4 Auto Low Power 5-12 Manual Shut Off 1-3 Auto Reset 1-3 Manual Stapling 6-12 Auto Shut Off 1-3 Memory indicator 5-3 Multi-sheet bypass tray 4-4 Basic Screen 5-3 Bypass key 5-10 Non-sort mode 6-5 CAUTIONS 2-2 Output icon 5-3...
  • Page 143 MEMO...
  • Page 144 MEMO...
  • Page 145 Machine Handling and Care ..................2-8 Routine Safety ......................2-9 Finisher Capacity Requirements ................2-10 Section 3: Machine Information Océ 750 Overview ......................3-2 Key Operator Functions ..................3-3 Service, Repairs and Supplies ................3-3 Machine Labels ...................... 3-3 Service Settings ..................... 3-4 External Machine ......................
  • Page 146 Contents Section 4: Media Information Main Body Trays ......................4-2 Large Capacity Tray (8.5 x 11) (Option) ............... 4-3 Large Capacity Tray (11 x 17) (Option) ................ 4-3 Automatic Duplex Unit ....................4-4 Multi-Sheet Bypass Tray and Tab Sheets ..............4-4 Finisher / Finisher-Folder (Option) ................
  • Page 147 Contents Section 6: Output Modes Finisher / Finisher-Folder Specifications ..............6-2 Finisher Type ......................6-2 Primary (Main) Tray ....................6-2 Secondary (Sub) Tray ................... 6-3 Booklet Tray (Finisher-Folder only) ............... 6-3 Cover Sheet Feeder (Post Inserter) ..............6-3 Trimmer Unit Tray (Finisher-Folder only) .............. 6-4 Non-Sort Mode Using Primary (Main) Tray ..............
  • Page 148 Contents Section 8: Key Operator Mode To the Key Operator ..................... 8-2 How to Access the Key Operator Mode ..............8-3 Function Menu Map ...................... 8-4 System Initial Setting [1] ....................8-6 Date & Time Setting [1] ..................8-6 Language Select Setting [2] .................. 8-7 ECM (Electronic Copy Monitor) Function Setting [4] ............

Table of Contents
