Instruction Manual
PIPER CUB _ .
CODE SEA 87

INSTALLING THE AILERON SERVOS.

String.
Small weight.
Servos.
Small weight.
Aileron
Servo electric wire.
Servo.
Thread.
Wing rib.
Wing.
Small Weight.
Small Weight.
String.
String.
Attach the string to the servo lead and carefully thread it though the wing.
INSTALLATION THE PUSHROD.
Wing.
Aileron.
75mm.
M2 clevis.
M2 lock nut.
110mm.
Aileron.
Aileron.
14
