Seagull Models SEA 94 Pilatus PC-9 Assembly Manual

Hide thumbs Also See for SEA 94 Pilatus PC-9:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual
PC - 9
"Graphics and Specfications may change without notice".
Specifications
Wingspan--------------------------------- 71 in --------------------- 180.3cm.
Wing area-------------------------------- 789 sq.in ------------- 50.9 sq.dm.
Weight------------------------------------ 10.1-11.9lbs -----------4.6-5.4 kg.
Length------------------------------------- 66.1 in ------------------- 167.9cm.
Recommended engine size---------- 1.20 cu.in ---------------- 2-stroke.
ELECTRIC CONVERSION : OPTIONAL.
Radio System required 6 channel with 8 servos.
Flying skill level Intermediate/advanced.
Kit features.
•
Ready-made—minimal assembly & finishing required.
•
Ready-covered covering.
•
Photo-illustrated step-by-step Assembly Manual.
Made in Vietnam.
ASSEMBLY MANUAL
1.10-1.25 cu.in ---------- 4-stroke.
MS: SEA 94
.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SEA 94 Pilatus PC-9 and is the answer not in the manual?

Questions and answers

Related Manuals for Seagull Models SEA 94 Pilatus PC-9

Summary of Contents for Seagull Models SEA 94 Pilatus PC-9

  • Page 1 PC - 9 MS: SEA 94 ASSEMBLY MANUAL “Graphics and Specfications may change without notice”. Specifications Wingspan--------------------------------- 71 in --------------------- 180.3cm. Wing area-------------------------------- 789 sq.in ------------- 50.9 sq.dm. Weight------------------------------------ 10.1-11.9lbs -----------4.6-5.4 kg. Length------------------------------------- 66.1 in ------------------- 167.9cm. Recommended engine size---------- 1.20 cu.in ---------------- 2-stroke. 1.10-1.25 cu.in ---------- 4-stroke.
  • Page 2 PC-9. INTRODUCTION. Thank you for choosing the PC-9 ARTF by SEAGULL MODELS. The PC-9 was designed with the intermediate/advanced sport flyer in mind. It is a scale airplane which is easy to fly and quick to assemble. The airframe is conventionally built using balsa, plywood to make it stronger than the average ARTF , yet the design allows the aeroplane to be kept light.

  • Page 3: Hinging The Ailerons

    www.seagullmodels.com NOTE: To avoid scratching your new aero- plane we suggest that you cover your workbench with an old towel. Keep a couple of jars or bowls handy to hold the small parts after you open the bags. Please trial fit all parts. Make sure you have the correct parts and that they fit and are aligned properly before gluing! Hinge...

  • Page 4: Hinging The Elevator

    Instruction Manual. PC-9. 7) Repeat this process with the other wing AILERON CONTROL HORN panel, securely hinging the aileron in place. 8) After both ailerons are securely hinged, Aileron control horn installation: See pictures firmly grasp the wing panel and aileron to below make sure the hinges are securely glued and cannot be pulled out.

  • Page 5: Rudder Control Horn

    www.seagullmodels.com ELEVATOR CONTROL HORN. RUDDER CONTROL HORN. Rudder control horn: Install the elevator control horn using the Using the same techniques used aileron same method as with the aileron control control horn. See picture below. horns. 2 sets. 2 sets. M3x45mm.
  • Page 6 Instruction Manual. PC-9. M4x30mm. Mark and drill 4 holes for engine mount. Insert 4 blind nuts to firewall. Thread locker glue. Vent tube. Fuel pick up tube. INSTALLING THE STOPPER ASSEMBLY. Fuel fill tube. 1) Using a modeling knife, carefully cut Carefully use a lighter or heat gun to off the rear portion of one of the 3 nylon tubes permenently set the angle of the vent tube.

  • Page 7: Fuel Tank Installation

    www.seagullmodels.com 5) With the stopper assembly in place, C/A glue. the weighted pick-up should rest away from the rear of the tank and move freely inside the tank. The top of the vent tube should rest just below the top of the tank. It should not touch the top of the tank.

  • Page 8: Cowling Installation

    Instruction Manual. PC-9. Trim and cut. 150mm. 4.2 mm diameter. Trim and cut. 5) Bolt the engine to the engine mount using the four machine screws. Double check that all the screws are tight before proceeding. 6) Attach the Z-Bend in the pushrod wire to the throttle arm on the carburetor.
  • Page 9 www.seagullmodels.com 3) Install the muffler and muffler extension Electric Conversion (Ep Power) onto the engine and make the cut out in the (OPTION). cowl for muffler clearance. Connect the fuel and pressure lines to the carburetor, muffler and fuel filler valve. Secure the cowl to fuse- lage using the M3x10mm screws (4).

  • Page 10: Instruction Manual

    Instruction Manual. PC-9. Aluminum tube. M3 x 15mm. M6 x 120mm. Electric motor. C/A glue. Electric motor. The removable top hatch 155mm. provides easy access. Battery. 4 sets. Aluminum tube. Aluminum spacers. To fuel tank or electric power battery.

  • Page 11: Spinner Installation

    www.seagullmodels.com INSTALLING THE FUSELAGE SERVO. Removable top hatch. Because the size of servos differ, you may need to adjust the size of the precut open- ing in the mount. The notch in the sides of the mount allow the servo lead to pass through. 1) Install the rubber grommets and brass collets onto the throttle servo.

  • Page 12: Installing The Switch

    Instruction Manual. PC-9. Throttle servo arm. Rudder. Cut . Stearing servo. Elevator servo . INSTALLING THE SWITCH. Install the switch into the precut hole in the side of fuselage. Retract servo. SERVO GEAR INSTALLATION. Switch. THROTTLE-RETRACT SERVO ARM INSTALLATION. Install adjustable servo connector in the servo arm .

  • Page 13: Pushrod Installation

    www.seagullmodels.com Remove covering. Wing bottom. Electric wire. M3 x 15mm. PUSHROD INSTALLATION. 135mm. 135mm. 145mm. GEAR INSTALLATION.
  • Page 14 Instruction Manual. PC-9. Open Position servo arm. Close Position. 25mm. 12mm. servo arm.

  • Page 15: Installing The Aileron Servos

    www.seagullmodels.com Installing the aileron servo in place using the INSTALLING THE AILERON SERVOS. same techniques used to flap servo. Servos. Small weight. Small weight. String. Thread. INSTALLING THE AILERON SERVOS. Wing rib. Wing. Small Weight. Small Weight. String. String. Attach the string to the servo lead and carefully thread it though the wing. Wing.

  • Page 16: Wing Tip Installation

    Instruction Manual. PC-9. Masking tape. M3 lock nut. Wing. WING TIP INSTALLATION. Aileron. Repeat the procedure for the other wing. Remove the covering. WING ASSEMBLY. Aluminum tube diameter = 19x806mm. Epoxy. Masking tape. Epoxy. Epoxy.

  • Page 17: Installing The Horizontal Stabilizer

    www.seagullmodels.com Remove the covering. Remove the covering. INSTALLING THE HORIZONTAL STABILIZER. Epoxy. Epoxy. Pen.
  • Page 18 Instruction Manual. PC-9. INSTALLING THE VERITICAL STABILIZER. Epoxy. Rudder control horn. Pen. ELEVATOR - RUDDER PUSHROD HORN INSTALLATION. 1) Elevator and rudder pushrods assembly follow pictures below. 2) Install servos arm to servos. Notice the position of the servo arms on the servos. See picture below.
  • Page 19 www.seagullmodels.com M3 clevis. M3 lock nut. M2 lock nut. 155mm. Rudder pushrod. M2 clevis. M2 Lock nut. Attach to elevator - rudder control horn. Attach to servo arm in fuselage. Elevator . Stearing servo. Throttle. Rudder sevor. Cable pull pul system. MOUNTING THE NOSE WHEEL.
  • Page 20 Instruction Manual. PC-9. M3 x 15mm. Wheel. Landing gear. Wheel. Pull-Pull cable stearing.

  • Page 21: Installing The Battery

    www.seagullmodels.com Battery. Pull-Pull cable stearing. Plastic Screw. OPTIONAL PARTS INSTALLING . Stearing sevor. Rudder. Throttle. INSTALLING THE BATTERY. Tie Wrap. Battery.

  • Page 22: Installing The Receiver

    Instruction Manual. PC-9. 5mm. 5mm. M2 x 6mm. 45mm. INSTALLING THE RECEIVER. 5mm. 1) Plug the servo leads and the switch lead into the receiver. Plug the battery pack lead into the switch also. 2) Wrap the receiver and battery pack in the protective foam rubber to protect them from vibration.

  • Page 23: Control Throws

    www.seagullmodels.com When balanced correctly, the airplane should sit level or slightly nose down when you lift it up with your fingers. 70mm. Wing bolt. CONTROL THROWS. We highly recommend setting up the PC-9 using the control throws listed at right. We have listed control throws for Low Rate (initial test flying/sport flying) (aerobatic fly- ing).

  • Page 24: Preflight Check

    Instruction Manual. PC-9. A) Check the operation and direction of PREFLIGHT CHECK. the elevator, rudder, ailerons and throttle. 1) Completely charge your transmitter B) Plug in your radio system per the and receiver batteries before your first day of manufacturer's instructions and turn every- flying.
