CLM HD8

User guide

R9050130
R90501301
R59770057/05
14/01/2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CLM HD8 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Barco CLM HD8

Summary of Contents for Barco CLM HD8

  • Page 1: User Guide

    CLM HD8 User guide R9050130 R90501301 R59770057/05 14/01/2009...
  • Page 2 Barco nv Events Noordlaan 5, B-8520 Kuurne Phone: +32 56.36.89.70 Fax: +32 56.36.88.24 E-mail: sales.events@barco.com Visit us at the web: www.barco.com Printed in Belgium...

  • Page 3: Software License Agreement

    The period of guarantee begins on the date of transfer of risks, in the case of special systems and software on the date of commissioning, at latest 30 days after the transfer of risks. In the event of justified notice of complaint, Barco can repair the fault or provide a replacement at its own discretion within an appropriate period.

  • Page 4: Disposal Information

    GNU-GPL code If you would like a copy of the GPL source code contained in this product shipped to you on CD, please contact Barco. The cost of preparing and mailing a CD will be charged.

  • Page 5: Table Of Contents

    Input configuration ......................60 R59770057 CLM HD8 14/01/2009...
  • Page 6 12.10 White peaking ........................121 R59770057 CLM HD8 14/01/2009...
  • Page 7 17.4 Removal of the top cover......................176 R59770057 CLM HD8 14/01/2009...
  • Page 8 Index........................211 R59770057 CLM HD8 14/01/2009...

  • Page 9: Safety

    About this chapter Read this chapter attentively. It contains important information to prevent personal injury while installing and using an CLM HD8 projector. Furthermore, it includes several cautions to prevent damage to the CLM HD8. Ensure that you understand and follow all safety guidelines, safety instructions and warnings mentioned in this chapter before installing your CLM projector.
  • Page 10 Caution: High pressure lamp may explode if improperly handled. Refer servicing to qualified service personnel. The customer should never attempt to disassemble the lamp casing or to dispose of the lamp casing other than by returning it to Barco. •...
  • Page 11 flammable or combustible materials are present. The exclusion zone must be not less than 40 cm (16”) for all Barco DLP projectors. The exclusion zone on the lens side must be at least 2 meter (80”).

  • Page 12: Recycling Guidelines

    If the product exhibits a distinct change in performance, indicating a need for service. • Replacement parts: When replacement parts are required, be sure the service technician has used original Barco replacement parts or authorized replacement parts which have the same characteristics as the Barco original part. Unauthorized substitu- tions may result in degraded performance and reliability, fire, electric shock or other hazards.

  • Page 13: Important Warnings Concerning Clm Flight Cases

    In the event of a wheel breaking, flight cases must be rigidly strapped tight to prevent a stack collapsing. • Use an appropriate forklift to raise flight cases and take the necessary precautions to avoid personnel injury. R59770057 CLM HD8 14/01/2009...
  • Page 14 1. Safety R59770057 CLM HD8 14/01/2009...

  • Page 15: General

    Projector weight Do not underestimate the weight of one Barco CLM HD8, which is about ±31 kg (±68 lb.). Be sure that the table or truss installation on which the projector(s) has to be installed is capable of handling five (5) times the complete load of the complete system.

  • Page 16: Unpacking The Projector

    2. Cut open the box but do not insert the cutter too deep, otherwise the projector could be damaged. Image 2-1 3. Take out the cardboard box with the accessories such as manuals, remote control and power cord. 4. Take the projector out of the cardboard box and place it on a stable table. R59770057 CLM HD8 14/01/2009...

  • Page 17: Box Content

    This check should confirm that there are no broken knobs or connectors, that the cabinet and panel surfaces are free of dents and scratches, and that the operating panel are not scratched of cracked. The Barco sales and service office should be notified as soon as possible.

  • Page 18: Projector Configurations

    Rear / Table (R/T) Rear / Ceiling (R/C) For a ceiling mounted configuration, the optional carry handle kit is required. Front projection AUDIENCE FLOOR Image 2-3 Front projection Rear projection AUDIENCE BACKSTAGE FLOOR Image 2-4 Rear projection R59770057 CLM HD8 14/01/2009...

  • Page 19: Positioning The Projector

    field of view (F) as illustrated below. Within these shift ranges the projector and lens perform excellently. Configuring the projector outside these shift ranges will result in a slight decline of image quality. R59770057 CLM HD8 14/01/2009...
  • Page 20 Horizontal and vertical projector tilt ranges The projector is designed to work in a table or ceiling mounted position, but tilting over 360°, vertically an horizontally is allowed. 360° 360° Image 2-7 Tilt area R59770057 CLM HD8 14/01/2009...

  • Page 21: Projector Air Inlets And Outlets

    Air inlets and outlets Image 2-8 The CLM HD8 has 2 inlet channels and one air outlet. The air outlet is located at the rear of the projector. The air inlets are located at the front and top of the projector.
  • Page 22 2. General R59770057 CLM HD8 14/01/2009...

  • Page 23: Physical Installation

    The standard remote control unit (A) can be equipped with the optional rugged case (B) and an XLR adapter (C). The remote control unit can be used wired via mini-jack or via optional rugged XLR. Note that the backlight of the remote control unit illuminate continuously when used with a wire. Image 3-1 R59770057 CLM HD8 14/01/2009...

  • Page 24: Rcu Battery Installation

    To prevent battery explosion • Danger of explosion if battery is incorrectly installed. • Replace only with the same or equivalent type recommended by the manufacturer. • Dispose of used batteries according to the manufacturer’s instruction. R59770057 CLM HD8 14/01/2009...

  • Page 25: Rcu Rugged Case Installation

    How to install the XLR adaptor of the remote control unit ? 1. Push the XLR adaptor (C) upon the rugged case of the remote control unit as illustrated. Note: Ensure that the text of the XLR adaptor is on top. R59770057 CLM HD8 14/01/2009...

  • Page 26: Using The Xlr Adaptor Of The Rcu

    1. Connect a cable with XLR plug into the XLR adaptor. 2. Connect the other end of the cable with your CLM HD8. 3. Push the XLR adaptor completely against the rugged case of the remote control unit, as illustrated in the left image below, for wired communication.

  • Page 27: Lenses

    3. Use the lens formulas to find the best corresponding PD with regard to the measured projector-screen distance for the required screen width SW. Tip: Divide PD by SW to determine the approximate throw ratio. Choose a lens, which captures the calculated throw ratio. Use the lens formula of the chosen lens to recalculate exactly. R59770057 CLM HD8 14/01/2009...

  • Page 28: Lens Formulas

    1. Place the projector in the desired location. Take into account the zoom range of the used lens and the size of the screen. 2. Project one of the internal hatch patterns on the screen. 3. Turn the adjustable feet in or out until the projected hatch pattern is perfectly rectangle shaped and leveled. Image 3-10 Level adjustment R59770057 CLM HD8 14/01/2009...

  • Page 29: Suspension Of The Clm Projector With Rigging Clamps

    Mounting the rigging points into the handle 1. Push the cup square neck bolt through the slot input and slide the bolt into the slot. Note: Take the bolt by its thread so that it does not fall inside the carry handle. R59770057 CLM HD8 14/01/2009...
  • Page 30 Ensure that the rigging points are symmetrically lined up, so that the projector will hang in balance. If necessary move point B from a transversal position to a longitudinal position. Warning: Always secure the rigging points after adjustment. x mm Image 3-15 Set up truss width 5. Turn the rigging clamps on the bolts. R59770057 CLM HD8 14/01/2009...
  • Page 31 6. Place all four rigging clamps in open position as illustrated. Image 3-17 Opening clamps 7. Place the projector (upside down) under the truss installation and lower the truss until the support bars of the truss are nearby the rigging clamps on the projector. R59770057 CLM HD8 14/01/2009...
  • Page 32 10.Install the safety cable. Hook one end into a provided hole. Route the cable around the truss and hook the other end into a second hole in the carry handle. Image 3-19 Security cable AUTION Always mount the safety cable when suspending the projector. R59770057 CLM HD8 14/01/2009...

  • Page 33: Alignment Of A Ceiling Mounted Clm Projector

    3. Adjust the height of the rigging clamps with respect to the projector, until the projected hatch pattern is rectangle shaped and leveled. Separate skew adjustment is still possible. Image 3-20 Ceiling mount alignment 4. Adjust the skew adjustment until the rectangle is perfectly shaped. Skew Image 3-21 Skew adjustment R59770057 CLM HD8 14/01/2009...
  • Page 34 3. Physical installation R59770057 CLM HD8 14/01/2009...

  • Page 35: Stacking Clm Projectors

    In case of stacking projectors for a ceiling mount configuration, first turn the projectors upside down before placing the projectors on top of each other. Image 4-1 Stacking projectors 2. Attach the two projectors together by closing all three interlocking adapters as illustrated. R59770057 CLM HD8 14/01/2009...
  • Page 36 If yes, mount a safety cable from one side of the projector around the truss installation to the other side of the projector. Repeat this for the second projector. Image 4-3 Ceiling mounted stacked projectors How to open an interlocking adapter 1. Open an interlocking adapter as illustrated. R59770057 CLM HD8 14/01/2009...

  • Page 37: Aligning Stacked Clm Projectors

    4. If necessary, adjust the inclination of the stacked projector with respect to the reference projector by turning the height adjustment ring of the interlocking adaptor at the rear of the stacked projector in or out. Adjust until the outline of the hatch pattern is most symmetric with the reference hatch pattern. R59770057 CLM HD8 14/01/2009...
  • Page 38 Note: Note that the “Zoom” function is motorized, which means that you have to access the projector software, via the local keypad or remote control unit, to operate the “Zoom” function. Zoom Image 4-9 Zoom adjustment R59770057 CLM HD8 14/01/2009...

  • Page 39: Connections

    5. Connections 5. CONNECTIONS About this chapter This chapter describes more in detail the power (P), the input source (S) and the communication (C) connections of the CLM HD8. Image 5-1 Overview • Power connection • Input source connections •...
  • Page 40 When the input power is between 100V and 140V, 75% of the light output with 3 lamps can be reached. When the input power is between 90V and 100V the light output is reduced to 62.5% with only 3 lamps. R59770057 CLM HD8 14/01/2009...

  • Page 41: Input Source Connections

    Always install a cover plate on an unused input slot. This to prevent dust intrusion into the pro- jector. Available input modules Image 5-5 Image 5-6 Image 5-7 5 Cable input (Multi purpose) (R9854430). HDSDI - SDI input (R9854450). DVI input (R9854460). R59770057 CLM HD8 14/01/2009...

  • Page 42: Communication Connections

    5. Connections Image 5-8 Cover plate for unused input slot (R848607). HDCP DVI input (R9854465) (image not available) The CLM HD8 is standard equipped with one 5 cable input module and one SDI/HDSDI input module. Communication connections Communication interface DIAGNOSTIC CODE...

  • Page 43: Projector Status

    RS232/422 serial communication The communication interface of the CLM HD8 supports RS232 and RS422 serial communication. You can use the RS232/RS422 input port (J) to connect a local PC to your CLM projector. This way you can configure and control your CLM projector from your local PC.
  • Page 44 The connector used for the Ethernet ports (E) are of rugged Neutrik EtherCon RJ45 type, which is compatible with standard RJ45 cable connector. Straight (most common) as well as cross linked network cables can be used. 10/100 Base-T — RJ45 port Pin Description TXD+ TXD- RXD+ — — R59770057 CLM HD8 14/01/2009...

  • Page 45: Usb Port

    Linux FAT16 compatible. DMX interface The communication interface of the CLM HD8 supports DMX. DMX is used as communication bus between different devices in the light technic. Each device has an input and an output, so that the bus can be looped between the different devices.
  • Page 46 5. Connections R59770057 CLM HD8 14/01/2009...

  • Page 47: Getting Started

    • switching to "pause" (blanked picture, full power for immediate restarting) • direct access to all connected sources. Terminology overview Overview The following table gives an overview of the different functionality of the keys. R59770057 CLM HD8 14/01/2009...
  • Page 48 Use these buttons to obtain the desired picture level. PHASE Used to remove the horizontal instability of the image (usually for RGB source). It adjusts the phase of the pixel sampling clock relative to the incoming signal. R59770057 CLM HD8 14/01/2009...

  • Page 49: Operating The Projector

    The projector starts up in standby. The menus are accessible via the local LCD panel. To display an image, the standby key must be pressed once. Starting image projection via the standby key. 1. Press Stand by key once on the local keypad or on the remote control. R59770057 CLM HD8 14/01/2009...

  • Page 50: Errors, Warnings And Messages During Start Up

    Switching to Standby. When the projector is running and you want to go to standby, press the standby key for 2 seconds. Do not press any longer on the standby key otherwise the projector will restart. R59770057 CLM HD8 14/01/2009...

  • Page 51: Switching Off

    When using the wireless remote control, make sure you are within the effective operating distance (30m, 100ft in a straight line). The remote control unit will not function properly if strong light strikes the sensor window or if there are obstacles between the remote control unit and the projector IR sensor. R59770057 CLM HD8 14/01/2009...

  • Page 52: Quick Setup Adjustments

    1. Press the LENS key on the remote control or local keypad. The zoom/focus menu will be displayed. Image 6-6 2. Push the cursor key ▲ or ▼ to zoom and ◄ or ► to focus the image. R59770057 CLM HD8 14/01/2009...

  • Page 53: Direct Lens Adjustment (Rcu)

    TAL SHIFT and VERTICAL SHIFT. 1. Press LENS ZOOM button [-] or [+] (A) for correct image size on the screen. CONTR LENS LENS ZOOM SHIFT LENS LENS SHIFT FOCUS Image 6-9 Direct lens adjustment keys Zoom Vertical shift Focus R59770057 CLM HD8 14/01/2009...

  • Page 54: Quick Picture In Picture

    The language menu opens. 3. Select with the ▲ or ▼ key the desired language and press ENTER to activate. The current active language is indicated with an asterisk (*). Image 6-13 Image 6-12 Image 6-11 R59770057 CLM HD8 14/01/2009...

  • Page 55: Use Of The Auto Button

    1. Press the Address key (recessed key on the RCU) with a pencil. 2. Enter the address with the digit buttons within 5 seconds after pushing the address key. Note: That address can be any digit between 0 and 9. R59770057 CLM HD8 14/01/2009...

  • Page 56: Controlling The Projector

    Image 6-16 Window selection button The outline of the selected window gets a colored rectangle to indicate the selection. For the main window, the color is blue. For the picture in picture window, the color is orange. R59770057 CLM HD8 14/01/2009...

  • Page 57: Controlling The Projector

    When the Stand-by key is pressed, the image projection is stopped and the projector goes to stand-by. This situation is used when a projection stop is planned for a longer period. All custom settings are saved to an internal backup device. A message ’Save data ...’ is displayed during this backup operation. R59770057 CLM HD8 14/01/2009...
  • Page 58 6. Getting started R59770057 CLM HD8 14/01/2009...

  • Page 59: Start Up Of The Adjustment Mode

    To start up the adjustment mode, use the remote control or the local keypad. How to start up? 1. Press Menu on the remote control (RCU) or on the local keypad to start up the Adjustment mode. R59770057 CLM HD8 14/01/2009...

  • Page 60: Navigation And Adjustments

    These menus can be used in the same way as the on-screen menus. The menus on the LCD panel are still reachable even when the projector lamp is not activated and when Text is in the off mode. R59770057 CLM HD8 14/01/2009...
  • Page 61 7. Start up of the adjustment mode When quitting the menu structure, the backlighting of the LCD panel is switched off after a few seconds. R59770057 CLM HD8 14/01/2009...
  • Page 62 7. Start up of the adjustment mode R59770057 CLM HD8 14/01/2009...

  • Page 63: Input Menu

    The projector has 2 input slots and these slots can be filled up in a random order with the available modules. Identical modules are allowed. For more information about the available input modules and how to install, see "Input source connections", page 37. R59770057 CLM HD8 14/01/2009...

  • Page 64: Input Configuration

    YUV input. Projector searches for the sync signal and projects the correct image. CVS/S-VIDEO AUTO Video or S-Video input. Projector detects automatically which type of video is connected to the inputs. RGB HS/VS - CS RGB input with separate horizontal and vertical sync or separate composite sync. R59770057 CLM HD8 14/01/2009...

  • Page 65: Input Locking

    3. Use the ▲ or ▼ key to select Input locking and press ENTER. The input locking window is displayed. The actual selected locking method is indicated by an arrow. 4. Use the ▲ or ▼ key to select the desired locking and press ENTER. R59770057 CLM HD8 14/01/2009...
  • Page 66 When Automatic or specific input is selected (arrow in front of it) and then the Options are selected, the following menu appears: Image 8-10 Use the ▲ or ▼ key to select Genlock and press ENTER to toggle between On and Off. R59770057 CLM HD8 14/01/2009...

  • Page 67: Minimum Delay

    3. Use the ▲ or ▼ key to select Minimum delay and press ENTER to toggle between [On] and [Off]. Image 8-12 Image 8-11 Native resolution What can be done The aim here is to always show the resolution of the source independently of the resolution of the DMD panels. R59770057 CLM HD8 14/01/2009...
  • Page 68 3. Use the ▲ or ▼ key to select Native resolution and press ENTER to toggle between [On] and [Off]. [On] : images displayed in native resolution [Off] : images scaled to fill the complete screen Image 8-15 Image 8-14 R59770057 CLM HD8 14/01/2009...

  • Page 69: Source Switching

    ▲ or ▼ key to scroll until the desired time is reached. Press ENTER to activate. Image 8-19 Image 8-18 Image 8-17 No signal Overview • Background color • Shutdown setting • Shutdown retarding time R59770057 CLM HD8 14/01/2009...

  • Page 70: Background Color

    Shutdown retarding time Only accessible when Shutdown is set to [On]. How to set the retarding time? 1. Press MENU to activate the menus. 2. Use the ▲ or ▼ key to select Input and press ENTER. R59770057 CLM HD8 14/01/2009...
  • Page 71 4. Use the ▲ or ▼ key to change the value. enter the desired value with the keyboard. When trying to exceed the maximum allowed value, the system will set it back to the maximum value. Image 8-28 Image 8-27 Image 8-26 R59770057 CLM HD8 14/01/2009...
  • Page 72 8. Input menu R59770057 CLM HD8 14/01/2009...

  • Page 73: Image Menu

    Noise reduction Color temperature Projector white Computer 9300K Video 6500K Film 5400K Broadcast 3200K Custom balance Input balance Aspect ratio 16/9 2.35 1.88 1.78 Custom Timings Total pixels Active pixels Horizontal start Period Total lines Active lines R59770057 CLM HD8 14/01/2009...

  • Page 74: How To Select The Image Adjustments

    2. Press ENTER to select. The Image menu opens. Image 9-2 Image 9-1 Image Settings Overview • Contrast • Brightness • Saturation • Tint (hue) • Phase • Sharpness • Noise reduction • Color temperature • Input balance R59770057 CLM HD8 14/01/2009...

  • Page 75: Contrast

    3. Use the ▲ or ▼ key to select Image settings and press ENTER. 4. Use the ▲ or ▼ key to select Brightness and press ENTER. The Brightness progress bar appears. 5. Use ◄ or ► to change the brightness. R59770057 CLM HD8 14/01/2009...

  • Page 76: Saturation

    4. Use the ▲ or ▼ key to select Saturation and press ENTER. The Saturation progress bar appears. 5. Use ◄ or ► to change the color saturation. The higher the value, the higher the color saturation. Image 9-12 Image 9-11 Image 9-13 Image 9-14 R59770057 CLM HD8 14/01/2009...

  • Page 77: Tint (Hue)

    When displaying computer patterns or graphics (RGB or YUV signals) which are very detailed (tilting, vertical stripes, etc. ), jitter in picture (mis-sampling) may occur, causing horizontal stripes in portions of the screen. When this jitter occurs, adjust ’Phase’ for optimum image. Image 9-19 Jittering on image R59770057 CLM HD8 14/01/2009...

  • Page 78: Sharpness

    3. Use the ▲ or ▼ key to select Image settings and press ENTER. 4. Use the ▲ or ▼ key to select Sharpness and press ENTER. The Sharpness progress bar appears. 5. Use ◄ or ► to change the sharpness. The higher the value, the higher the sharpness. R59770057 CLM HD8 14/01/2009...

  • Page 79: Noise Reduction

    4. Use the ▲ or ▼ key to select Noise reduction and press ENTER. The Noise reduction progress bar appears. 5. Use ◄ or ► to change the noise reduction. The higher the value, the higher the noise reduction. Image 9-29 Image 9-28 Image 9-30 Image 9-31 R59770057 CLM HD8 14/01/2009...

  • Page 80: Color Temperature

    5. Use the ▲ or ▼ key to select a predefined color temperature value, e.g. Video, and press ENTER. The colors of the image is switched to the selected value. Image 9-33 Image 9-32 Image 9-34 R59770057 CLM HD8 14/01/2009...

  • Page 81: Set A Custom Color Temperature

    6. Adjust gain red with ◄ or ► key. Use the ▲ or ▼ key to toggle to gain blue and back again. Adjust gain blue in the same way as gain red. 7. When gain adjustment is finished press ENTER. Image 9-37 Image 9-36 Image 9-38 Image 9-40 Image 9-39 R59770057 CLM HD8 14/01/2009...

  • Page 82: Input Balance

    A typical ADC transforms the analog value into an 8 bit coded digital signal. The graphic shows that when converting a signal containing a DC offset component the range of the converter is not optimally used. i2 : video information i1 : superfluous information Δ Black level Image 9-43 R59770057 CLM HD8 14/01/2009...

  • Page 83: Adjusting The Input Balance

    Black balance : In the projector, we will set the brightness for each color until we get a 0% light output picture when projecting a 100% black image (image B). The changeover from min to max is indicated by the apparition of bright spots also called “digital noise” R59770057 CLM HD8 14/01/2009...
  • Page 84 10.Toggle with ▲ or ▼ key to Black balance blue adjust the Blue black level until bright spots appear on the screen. 11. Toggle with ▲ or ▼ key to Black balance red adjust the Red black level until bright spots appear on the screen. The projected image should now be noisy full black R59770057 CLM HD8 14/01/2009...

  • Page 85: Aspect Ratio

    Relation between the horizontal & vertical dimension in which the window will be displayed, e.g. 4 by 3 or 16 by 9. Can also be expressed as a decimal number, such as 1.77. The larger the ratio or decimal, the wider are less square the image. R59770057 CLM HD8 14/01/2009...

  • Page 86: What Can Be Done

    The Custom aspect ratio dialog box opens. 2. Use the ▲ or ▼ key to adjust the vertical size of the image. Use the key to adjust the horizontal size of the image. When the desired aspect ratio is obtained, press EXIT. R59770057 CLM HD8 14/01/2009...

  • Page 87: Timings

    3. Use the ▲ or ▼ key to select Timings and press ENTER. The timings menu will be displayed. Image 9-63 Image 9-62 Image 9-64 4. To change a setting, use the ▲ or ▼ key to select and press ENTER. R59770057 CLM HD8 14/01/2009...

  • Page 88: Advanced Settings

    The Advanced settings menu is displayed. 5. Use the ▲ or ▼ key to select Clamp delay or Clamp width and press ENTER. A progress bar appears. 6. Use the ▲ or ▼ key to change the setting. R59770057 CLM HD8 14/01/2009...
  • Page 89 3. Use the ▲ or ▼ key to select Advanced settings and press ENTER. The Advanced settings menu is displayed. 4. Use the ▲ or ▼ key to select Field polarity and press ENTER to toggle between [neg] or [pos]. Image 9-72 Image 9-71 Image 9-73 R59770057 CLM HD8 14/01/2009...

  • Page 90: Advanced Settings, Film Mode Detection

    3. Use the ▲ or ▼ key to select Advanced settings and press ENTER. The Advanced settings menu is displayed. 4. Use the ▲ or ▼ key to select Film mode and press ENTER to toggle between [auto] or [off]. R59770057 CLM HD8 14/01/2009...

  • Page 91: Advanced Setting, Brilliant Color Look

    3. Use the ▲ or ▼ key to select Advanced settings and press ENTER. The Advanced settings menu is displayed. 4. Use the ▲ or ▼ key to select Brilliant color look and press ENTER to toggle between [Data] or [Vid. 1] or [Vid 2]. R59770057 CLM HD8 14/01/2009...

  • Page 92: Image Files Services

    Options : way of loading a file when a source is selected. A loaded file can be edited via the Timings menu. Once a file is edited, it will be saved with the same name as the original file, followed by a sequence number between rounded brackets. R59770057 CLM HD8 14/01/2009...

  • Page 93: Manual Load File

    2. Use the ▲ or ▼ key to select Image and press ENTER. 3. Use the ▲ or ▼ key to select File services and press ENTER. The File service menu is displayed. 4. Use the ▲ or ▼ key to select Delete and press ENTER. R59770057 CLM HD8 14/01/2009...

  • Page 94: Delete All Custom Files

    4. Use the ▲ or ▼ key to select Delete all and press ENTER. A delete all confirmation window opens. 5. Use the ▲ or ▼ key to select Yes if you are sure to delete all custom files and press ENTER to activate the selection. R59770057 CLM HD8 14/01/2009...

  • Page 95: Rename A File

    Note: Digits can be entered with the digit keys on the remote control or on the local keypad. When a digit is entered in that way, the next character will be selected automatically. 8. Press ENTER to finalize the rename action. Image 9-96 Image 9-97 Image 9-95 R59770057 CLM HD8 14/01/2009...

  • Page 96: Copy A File

    8. Press ENTER to finalize the copy action. Image 9-101 Image 9-102 Image 9-100 Image 9-104 Image 9-103 9.6.7 File options How to set the options? 1. Press MENU to activate the menus. R59770057 CLM HD8 14/01/2009...

  • Page 97: Save Custom Settings

    3. Use the ▲ or ▼ key to select Save custom settings and press ENTER. The custom settings are written to the internal backup device. A message menu “Save data ...” is displayed during the save operation. Image 9-109 R59770057 CLM HD8 14/01/2009...
  • Page 98 9. Image menu R59770057 CLM HD8 14/01/2009...

  • Page 99: Layout Menu

    When the active layout is a read only layout, the projector will ask to create a new layout. Use the ▲ or ▼ key to select Yes or No and press ENTER. If Yes is selected an Enter layout name window opens. Image 10-2 Image 10-1 R59770057 CLM HD8 14/01/2009...

  • Page 100: Size Adjustment

    3. Use the ▲ or ▼ key to select Main Window and press ENTER. The main window opens. 4. Use the ▲ or ▼ key to select Size and press ENTER. The size adjustment window opens. Image 10-6 Image 10-5 Image 10-4 R59770057 CLM HD8 14/01/2009...
  • Page 101 The main window opens. 4. Use the ▲ or ▼ key to select Size and press ENTER. The size adjustment window opens. Image 10-11 Image 10-10 Image 10-9 5. Toggle with ENTER till Lock is set to [ ]. R59770057 CLM HD8 14/01/2009...

  • Page 102: Position Adjustment

    3. Use the ▲ or ▼ key to select Main Window and press ENTER. The main window opens. 4. Use the ▲ or ▼ key to select Position and press ENTER. The position adjustment window opens. 5. Use the ▲ or ▼ key to adjust top start point. R59770057 CLM HD8 14/01/2009...

  • Page 103: Pip Window

    The input section of the projector allows a combinations of different input signals which may be projected in the 2 windows of the PiP screen. The PiP window can be placed anywhere, with any dimensions, on the screen by changing its position and its size. R59770057 CLM HD8 14/01/2009...

  • Page 104: Picture In Picture Activation

    RCU. 10.3.3 Picture in Picture size of the window What can be done? The width and height of the picture in picture window can be changed till the desired dimensions are obtained. R59770057 CLM HD8 14/01/2009...
  • Page 105 The main window opens. 4. Use the ▲ or ▼ key to select Size and press ENTER. The size adjustment window opens. Image 10-28 Image 10-27 Image 10-26 5. Toggle with ENTER till Lock is set to [x]]. R59770057 CLM HD8 14/01/2009...
  • Page 106 The main window opens. Image 10-33 Image 10-32 Image 10-31 4. Use the ▲ or ▼ key to select Size and press ENTER. The size adjustment window opens. 5. Toggle with ENTER till Lock is set to [ ]. R59770057 CLM HD8 14/01/2009...

  • Page 107: Picture In Picture, Position Window

    The size adjustment window opens. 5. Use the ▲ or ▼ key to adjust Top Use the ◄ or ► key to adjust Left When the desired position is reached, press EXIT. A Save window opens. R59770057 CLM HD8 14/01/2009...

  • Page 108: Layout File Services

    2. Use the ▲ or ▼ key to select Window and press ENTER. 3. Use the ▲ or ▼ key to select Layout and press ENTER. The layout services window opens. 4. Use the ▲ or ▼ key to select Load and press ENTER. R59770057 CLM HD8 14/01/2009...

  • Page 109: Rename A Layout

    Note: Digits can be entered with the digit keys on the remote control or on the local keypad. When a digit is entered in that way, the next character is selected automatically. 7. Press ENTER to save the new name. R59770057 CLM HD8 14/01/2009...

  • Page 110: Delete A Layout

    3. Use the ▲ or ▼ key to select Layout services and press ENTER. The layout services window opens. 4. Use the ▲ or ▼ key to select Delete and press ENTER. The Delete window opens. Image 10-51 Image 10-50 Image 10-49 R59770057 CLM HD8 14/01/2009...

  • Page 111: Copy / Save As A Layout

    Note: Digits can be entered with the digit keys on the remote control or on the local keypad. When a digit is entered in that way, the next character is selected automatically. 7. Press ENTER to copy to the new name. The new layout will be added to the list of layouts. Image 10-55 Image 10-54 Image 10-53 R59770057 CLM HD8 14/01/2009...
  • Page 112 10. Layout menu Image 10-56 R59770057 CLM HD8 14/01/2009...

  • Page 113: Lamp Menu

    Eco high altitude : a reduced wattage is fed to the lamp(s). Reduced light output but a longer life time for the lamp(s). A correct cooling is started even when the air density is less (fans are turning faster). Eco and Normal high altitude mode are only available when the projector is supplied with 220 V. R59770057 CLM HD8 14/01/2009...

  • Page 114: Lamp Power

    4. Use the ▲ or ▼ key to select Power and press ENTER. Note: Only possible when lamp mode is [Normal]. 5. Use the ▲ or ▼ key to change the lamp power. Image 11-6 Image 11-5 Image 11-4 R59770057 CLM HD8 14/01/2009...

  • Page 115: Lamp Identification

    11.5 Status and run time overview lamps Overview 1. Press MENU to activate the menus. 2. Use the ▲ or ▼ key to select Lamp and press ENTER. 3. Use the ▲ or ▼ key to select Overview and press ENTER. R59770057 CLM HD8 14/01/2009...

  • Page 116: Lamp Mode

    3. Use the ▲ or ▼ key to select Lamp mode and press ENTER. The Lamp mode selection menu is displayed. 4. Use the ▲ or ▼ key to select the desired lamp mode and press ENTER. Image 11-15 Image 11-16 Image 11-14 R59770057 CLM HD8 14/01/2009...

  • Page 117: Alignment Menu

    Alignment Orientation Front Table Front Ceiling Rear Table Rear Ceiling Lens Zoom/Focus Shift Side keystone Blanking Bottom Left Right Reset Intensity Gamma Internal patterns Checker board Color bars Convergence Focus Full screen black Full screen blue R59770057 CLM HD8 14/01/2009...

  • Page 118: Orientation

    2. Use the ▲ or ▼ key to select Alignment and press ENTER. 3. Use the ▲ or ▼ key to select Orientation and press ENTER. 4. Use the ▲ or ▼ key to select the correct orientation and press ENTER. Image 12-3 Image 12-1 Image 12-2 R59770057 CLM HD8 14/01/2009...

  • Page 119: Lens Adjustment

    3. Press ENTER to go to the shift adjustments. Lens shift 1. Use the ▲ or ▼ key to select Shift and press ENTER or when in the Zoom/Focus menu press ENTER to toggle to the Shift menu. R59770057 CLM HD8 14/01/2009...

  • Page 120: Side Keystone

    When the upper part of the image is smaller than the lower part of the image, push the ► key. The value below the bar scale will be positive. Image 12-14 Image 12-12 Image 12-13 R59770057 CLM HD8 14/01/2009...

  • Page 121: Blanking

    4. Use the ▲ or ▼ key to select the desired blanking adjustment and press ENTER. 5. Use the ▲ or ▼ key to adjust until the desired blanking is reached. 6. Press EXIT to return. R59770057 CLM HD8 14/01/2009...

  • Page 122: Intensity

    Gamma is an image quality enhancement function that offers a richer image by brightening the already darker portions of the image without altering the brightness of the brighter portions (contrast feeling enhanced). How to adjust gamma? 1. Press MENU to activate the menus. 2. Use the ▲ or ▼ key to select Alignment and press ENTER. R59770057 CLM HD8 14/01/2009...

  • Page 123: Internal Pattern

    4. Use the ▲ or ▼ key to scroll through the possible selection and press ENTER to activate the selected pattern. Select ▲ or ▼ in the menu to display the previous or next page with possible internal patterns. Image 12-27 Image 12-25 Image 12-26 R59770057 CLM HD8 14/01/2009...

  • Page 124: Color Space

    6. When custom is selected, use the ► key to view the details. To adjust the custom values, select the desired color point using the ▲ or ▼ key and change the value with ◄ or ► key until the desired value is reached. When finished, press EXIT to return. R59770057 CLM HD8 14/01/2009...

  • Page 125: White Peaking

    With 0, no white peaking, spokes not used to enhance the secondary colors and 10, full white peaking, spokes are fully used to enhance the secondary colors to show a truly life-like image. Image 12-34 Image 12-32 Image 12-33 R59770057 CLM HD8 14/01/2009...

  • Page 126: Scenergix

    Why ScenergiX ? When working in a multichannel setup the CLM HD8 and its Soft Edge possibilities enable an image blending that gives the appear- ance of a single view, thus achieving realistic immersion for the majority of wide screen applications.

  • Page 127: Preparations

    10 50 90 130 170 210 250 290 330 370 40 80 120 160 200 240 280 320 360 400 Image 12-40 10 50 90 130 170 210 250 290 330 370 Image 12-41 ScenergiX pattern R59770057 CLM HD8 14/01/2009...

  • Page 128: Scenergix Overlap Zone (Horizontal Scenergix)

    How to set for the first projector 1. Go to Layout → Main window → Size 2. Enter the value for the Width as follow: Total horizontal screen resolution / 2 - 0.5 x overlap zone. 3. Position remains the same. R59770057 CLM HD8 14/01/2009...
  • Page 129 2. Enter the value for the Width as follow: Total horizontal screen resolution / 2 - 0.5 x overlap zone. 3. Position = original start + horizontal width of projector 1 - overlap zone Image 12-50 Image 12-49 Image 12-48 Image 12-52 Image 12-51 R59770057 CLM HD8 14/01/2009...

  • Page 130: Scenergix Overlap Zone (Vertical Scenergix)

    1. Go to Layout → Main window → Size 2. Enter the value for the Height as follow: Total Vertical screen resolution / 2 - 0.5 x overlap zone. 3. Position remains the same. Image 12-56 Image 12-55 Image 12-54 Image 12-57 R59770057 CLM HD8 14/01/2009...

  • Page 131: Scenergix Size Adjustment

    2. Use the ▲ or ▼ key to select Alignment and press ENTER. 3. Use the ▲ or ▼ key to select ScenergiX and press ENTER. 4. Use the ▲ or ▼ key to select one of the four size adjustments and press ENTER. R59770057 CLM HD8 14/01/2009...
  • Page 132 5. Use the cursor keys to move the border of the overlap area to the desired position (value between 0 and 255). Set first the width for the first projector and repeat for the second one. R59770057 CLM HD8 14/01/2009...

  • Page 133: Adjusting The Black Level Of The Images

    2. Use the ▲ or ▼ key to select Alignment and press ENTER. 3. Use the ▲ or ▼ key to select ScenergiX and press ENTER. 4. Use the ▲ or ▼ key to select Black level and press ENTER. R59770057 CLM HD8 14/01/2009...
  • Page 134 5. Adjust the black level of area A until the black level of area A, B and C are equal. Image 2 Image 1 Image 12-72 Black level adjustment Use the Reset function to bring all ScenergiX settings back to zero. R59770057 CLM HD8 14/01/2009...

  • Page 135: Projector Control

    Network DHCP [ON/OFF] IP-address Subnet mask Default gateway IR control IR Front [On/Off] IR Back [On/Off] IR Side [On/Off] DMX address DMX monitor DMX mode Buttons APA [auto image menu] Shortcut keys Menu position Menu [Center] R59770057 CLM HD8 14/01/2009...

  • Page 136: Projector Address

    6. Use the ◄ or ► key to select the next digit and repeat step 5. 7. When the desired address is entered, press ENTER to store that address. Image 13-3 Image 13-2 Image 13-1 Image 13-4 R59770057 CLM HD8 14/01/2009...

  • Page 137: Common Address

    1. Press MENU to activate the menus. 2. Use the ▲ or ▼ key to select Projector control and press ENTER. 3. Use the ▲ or ▼ key to select Serial communication and press ENTER. The serial communication menu opens. R59770057 CLM HD8 14/01/2009...

  • Page 138: Interface Standard

    When the interface standard is set to RS422, the last projector in a line should be RS422 terminated (ON position). All others in the line should be in the OFF position. How to set 1. Press MENU to activate the menus. 2. Use the ▲ or ▼ key to select Projector control and press ENTER. R59770057 CLM HD8 14/01/2009...

  • Page 139: Network

    (WAN) or to the Internet. MAC address Media Access Control address. Unique hardware number, used in combination with the IP-address to connect to the network (LAN or WAN). R59770057 CLM HD8 14/01/2009...

  • Page 140: Dhcp Setup

    5. Use the ▲ or ▼ key to select the desired digit and press ◄ or ► key to select the next digit in the address. enter the value with the digit keys on the remote control or local keypad. The next digit in the address will be selected automati- cally. 6. Press EXIT to return. R59770057 CLM HD8 14/01/2009...

  • Page 141: Subnet-Mask Set Up

    The next digit in the address will be selected automati- cally. 6. Press EXIT to return. Image 13-27 Image 13-26 Image 13-25 Image 13-28 R59770057 CLM HD8 14/01/2009...

  • Page 142: Default Gateway Set Up

    3. Use the ▲ or ▼ key to select IR Control and press ENTER. 4. Use the ▲ or ▼ key to select the desired IR receiver and press ENTER to toggle this receiver [on] or [off]. R59770057 CLM HD8 14/01/2009...

  • Page 143: Dmx

    6. Use the ◄ or ► key to select the next digit and repeat step 5. 7. When the desired address is entered, press ENTER to store that address. R59770057 CLM HD8 14/01/2009...

  • Page 144: Dmx Monitor

    4. Use the ▲ or ▼ key to select DMX monitor and press ENTER. The DMX monitor window opens. Depending on the DMX mode, the Normal view or the Simple view of the DMX monitor window opens. Image 13-44 Image 13-43 Image 13-42 R59770057 CLM HD8 14/01/2009...
  • Page 145 Input 1 32 - 63 Input 2 64 - 255 No image (pause) Channel 5: 0 - 31 32 - 63 Focus 64 - 95 Zoom 96 - 127 Horizontal shift 128 - 255 Vertical shift R59770057 CLM HD8 14/01/2009...

  • Page 146: Dmx Mode

    2. Use the ▲ or ▼ key to select Projector control and press ENTER. 3. Use the ▲ or ▼ key to select Buttons and press ENTER. 4. Use the ▲ or ▼ key to select APA and press ENTER to toggle between [Align only] and [Auto-image menu]. R59770057 CLM HD8 14/01/2009...

  • Page 147: Shortcut Keys

    5. Use the ▲ or ▼ key to select a shortcut with allocation and press ENTER to remove the allocation. The indication becomes No allocation and the key is free again for a new shortcut association. Image 13-55 Image 13-54 Image 13-53 Image 13-56 R59770057 CLM HD8 14/01/2009...

  • Page 148: Menu Position

    2. Use the ▲ or ▼ key to select Projector control and press ENTER. 3. Use the ▲ or ▼ key to select Local LCD contrast and press ENTER. 4. Use the ▲ or ▼ key to adjust the local contrast. Image 13-62 Image 13-61 Image 13-60 R59770057 CLM HD8 14/01/2009...

  • Page 149: Language Selection

    3. Use the ▲ or ▼ key to select Language and press ENTER. 4. Use the ▲ or ▼ key to select the desired language. The change will take effect immediately. Image 13-65 Image 13-64 Image 13-63 R59770057 CLM HD8 14/01/2009...
  • Page 150 13. Projector control R59770057 CLM HD8 14/01/2009...

  • Page 151: Service Menu

    14. Service menu 14. SERVICE MENU About this chapter This chapter refers to the Service menu in which the owner can find valuable information when calling the Barco help desk. Overview • Overview flow • Identification • Diagnosis • Internal service patterns •...
  • Page 152 Use the ◄ or ► key to selected another character. Note: Digits can be entered with the digit keys on the remote control or on the local keypad. When a digit is entered in that way, the next character will be selected automatically. R59770057 CLM HD8 14/01/2009...

  • Page 153: Diagnosis

    3. Use the ▲ or ▼ key to select Diagnosis and press ENTER. The diagnosis screen is displayed. 4. Use the ▲ or ▼ key to select Versions and press ENTER. The Versions overview is displayed. Image 14-10 Image 14-9 Image 14-8 R59770057 CLM HD8 14/01/2009...

  • Page 154: Voltages

    4. Use the ▲ or ▼ key to select Voltages and press ENTER. The Voltage overview menu will be displayed. Image 14-14 Image 14-13 Image 14-12 Image 14-15 Use the ▲ or ▼ item in the menu to select the previous or next page with information. R59770057 CLM HD8 14/01/2009...

  • Page 155: I²C Diagnosis

    3. Use the ▲ or ▼ key to select Diagnosis and press ENTER. The diagnosis screen will be displayed. 4. Use the ▲ or ▼ key to select Temperatures and press ENTER. The Temperature overview menu will be displayed. R59770057 CLM HD8 14/01/2009...

  • Page 156: Fan Speeds Overview

    3. Use the ▲ or ▼ key to select Diagnosis and press ENTER. The diagnosis screen will be displayed. 4. Use the ▲ or ▼ key to select Fan speeds and press ENTER. The Fan speeds overview menu will be displayed. Image 14-26 Image 14-25 Image 14-24 R59770057 CLM HD8 14/01/2009...

  • Page 157: Spi

    Image 14-28 Image 14-31 14.3.8 Error logging overview How to get an overview? 1. Press MENU to activate the menus. 2. Use the ▲ or ▼ key to select Service and press ENTER. The service window opens. R59770057 CLM HD8 14/01/2009...

  • Page 158: Internal Service Patterns

    All settings of the projector will be set to the original factory settings. All user settings are erased with this operation. How to return to the default settings 1. Press MENU to activate the menus. 2. Use the ▲ or ▼ key to select Service and press ENTER. R59770057 CLM HD8 14/01/2009...

  • Page 159: Save Custom Settings

    The custom settings are written to the internal backup device. A message menu “Save data ...” is displayed during the save operation. Image 14-42 Image 14-41 14.7 Refill mode Before selecting Refill mode, take first all preparations necessary to refill the cooling circuit. R59770057 CLM HD8 14/01/2009...

  • Page 160: Usb Memory

    • IR receiver settings • native resolution • min delay • current language of on screen menus • customer id • Network settings (DHCP, IP address, net mask, gateway address) • blanking & keystone • ScenergiX R59770057 CLM HD8 14/01/2009...
  • Page 161 6. Use the ▲ or ▼ key to select the serial number to start from to load the settings. The settings from the selected projector on the USB device are loaded into the current attached projector. The current projector settings are overwritten with these settings. R59770057 CLM HD8 14/01/2009...

  • Page 162: Over Temperature Dmd Safety

    60 and 64 °C the projector continues in normal operation but the warning is set on the LCD display. Once the temperature is higher then 64 °C, then the projector is switched to standby. Image 14-54 Image 14-53 Image 14-52 R59770057 CLM HD8 14/01/2009...

  • Page 163: Maintenance

    The projector is liquid cooled. When running with a low liquid cooling level then the cooling capacity is strongly reduced which results in higher temperatures inside the projector. These higher temperatures can cause an interruption of your show as the lamps can be switched off by the software as a preventive step. R59770057 CLM HD8 14/01/2009...
  • Page 164 "16. Servicing", "Top-up the reservoir with cooling liquid", page 169. When the white indication is in the good area, no corrective action should be taken. Close the top cover and fasten both captive screws. Image 15-1 Check cooling liquid R59770057 CLM HD8 14/01/2009...

  • Page 165: Servicing

    This chapter contains general servicing procedures like lamp replacement, input unit replacement etc. Note that some of these procedures may only be performed by qualified technical service personnel. These procedure are marked with a warning. Extra service information Extra service information for qualified service technicians can be found on Barco’s Partnerzone (URL:www.partner- zone.events.barco.com). Registration is necessary.

  • Page 166: Replacement Of The Dust Filters On The Front Side

    3. Remove the HEPA filter on the front side by pulling the spring clamp (A) on the upper side away from the filter and then pivot the filter a little ( B) and take it out (C). R59770057 CLM HD8 14/01/2009...

  • Page 167: Lens Installation

    1. Remove the front cover of the projector. See "Removal of the front cover", page 173. 2. Remove the foam rubber in the opening of the lens holder if not yet removed. 3. Place the lock handle A is in its right position (table mounted projector). R59770057 CLM HD8 14/01/2009...

  • Page 168: Lens Removal

    2. Support the lens with one hand and push the lens lock handle to the right. Image 16-4 Lens removal 3. Pull out the lens backward until the jack connection is open (A). Slide the lens out of the lens holder. R59770057 CLM HD8 14/01/2009...

  • Page 169: Removal Of A Lamp Unit

    Each lamp position has a number. That number is also used in the software to identify the parameters of the corresponding lamp. Lamp 2 Lamp 1 Lamp 4 Lamp 3 Image 16-6 Lamp position When servicing a projector with exploded lamp Keep the following warning in mind when servicing a projector with exploded lamp. R59770057 CLM HD8 14/01/2009...
  • Page 170 2. Remove the lamp door, see "Removal of the lamp door", page 174. 3. Unplug the cable of the lamp which must be removed. Image 16-7 4. Pull up the fixation handle and rotate it fully upwards. Image 16-8 Lamp removal 5. Clasp the lamp and pull upwards. R59770057 CLM HD8 14/01/2009...

  • Page 171: Mounting A New Lamp Unit

    Never touch the UV filter when a lamp is removed. Necessary tools No tools. How to insert a lamp unit 1. Insert the lamp vertically into the housing, with the front of the lamp facing the middle of the projector. R59770057 CLM HD8 14/01/2009...

  • Page 172: Removal Of An Input Module

    1. Switch off the projector and unplug the power cord at the projector side. 2. Release the two captive screws of the input module. Image 16-11 Input module removal 3. Pull out the input module via the two provided knobs. R59770057 CLM HD8 14/01/2009...

  • Page 173: Inserting An Input Module

    1. Turn the bolt to release the pressure (1) . Turn until the white indication line is in the Open area (membrane is at the bottom of the reservoir) or until you feel to much resistance. 2. If you feel to much resistance, turn off the main lid on top of the reservoir (A). R59770057 CLM HD8 14/01/2009...
  • Page 174 8. Close the third lid again using the back of the main lid. Use a cloth to dab the residue of cooling liquid. Note: Make sure that no cooling liquid is spilled in the projector. 9. Turn in the bleed lid. R59770057 CLM HD8 14/01/2009...
  • Page 175 "Installation of the top cover", page 178. back cover, see "Installation of the back cover", page 178. front cover, see "Installation of the front cover", page 179. lamp door, see "Installation of the lamp door", page 180. R59770057 CLM HD8 14/01/2009...
  • Page 176 16. Servicing R59770057 CLM HD8 14/01/2009...

  • Page 177: Projector Covers, Removal And Installation

    (b) b) In that slightly pivoted position, pull the cover downwards to release it from the top cover (c) R59770057 CLM HD8 14/01/2009...

  • Page 178: Removal Of The Lamp Door

    1. Release the captive screw at the middle upper side of the side cover on the input side. Image 17-3 Release captive screw 2. Take the lamp door with both hands, one on each side, and pull it upward until the cover comes free from its 4 locks. R59770057 CLM HD8 14/01/2009...

  • Page 179: Removal Of The

    17.3 Removal of the back cover Necessary tools Flat screwdriver How to remove the back cover 1. Release the 3 captive screws in the back cover. Image 17-5 Release captive screws 2. Pull off the back cover. R59770057 CLM HD8 14/01/2009...

  • Page 180: Removal Of The Top Cover

    2. Pull the cover out of its locks and take it off. 17.5 Removal of the side cover To remove the side cover, first remove the front, back and top cover. Necessary tools Flat screwdriver How to remove the side cover 1. Loosen both screws. R59770057 CLM HD8 14/01/2009...

  • Page 181: Installation Of The Side Cover

    Allen wrench 3 mm How to install 1. Hook the side cover on the fixation screws and pull the cover downwards until it matches with the bottom cover. Image 17-10 Mount side cover 2. Fixate both screws. R59770057 CLM HD8 14/01/2009...

  • Page 182: Installation Of The Top Cover

    1. Hook the back cover on the top and side covers so that the edges of all three covers are fixed in the back cover. No open space allowed between two covers. Image 17-13 Mount back cover 2. Secure this position by turning the 3 captive screw clockwise. R59770057 CLM HD8 14/01/2009...

  • Page 183: Installation Of The

    1. Insert the top of the front cover behind the front of the top cover (slant the cover a little bit before inserting (A) ). Image 17-15 Install front cover 2. Pull the bottom side of the front cover toward the projector (B). The sides of the front cover overlap the sides of the side covers. R59770057 CLM HD8 14/01/2009...

  • Page 184: Installation Of The Lamp Door

    1. Place the lamp door with its pins (B) on its sockets (A) and push on it until clicks Image 17-17 Lamp door installation 2. Fasten the captive screw at the middle upper side of the side cover on the input side. R59770057 CLM HD8 14/01/2009...
  • Page 185 17. Projector covers, removal and installation Image 17-18 Secure the lamp door R59770057 CLM HD8 14/01/2009...
  • Page 186 17. Projector covers, removal and installation R59770057 CLM HD8 14/01/2009...

  • Page 187: Dimensions

    A. Dimensions A. DIMENSIONS Overview • Dimensions of the CLM HD8 A.1 Dimensions of the CLM HD8 Dimensions without carry handle 691.18 Image A-1 Dimensions R59770057 CLM HD8 14/01/2009...
  • Page 188 A. Dimensions Dimensions with optional carry handle 145.5 97.5 Image A-2 R59770057 CLM HD8 14/01/2009...

  • Page 189: Standard Source Files

    4. Fpix MHz: pixel frequency 5. Ptot : total pixels on one horizontal line. 6. Pact: active pixels on one horizontal line. 7. Ltot: total lines in one field 8. Lact: active lines in one field. R59770057 CLM HD8 14/01/2009...
  • Page 190 1125 1080 hd-1920x1080@60p 60,011 67,513 148,528 2200 1920 1125 1080 VIDEO525 62,437 15,734 13,500 VIDEO525p 59,940 31,468 27,000 VIDEO625 50,080 15,625 13,500 VIDEO625p 50,080 31,250 27,000 no-signal 100,00 20,000 8,000 no-signal-i 100,00 20,000 8,000 Table B-1 R59770057 CLM HD8 14/01/2009...

  • Page 191: Dmx Chart

    128 - Future assignment Same as Stop 160 - Future assignment Same as Stop 192 - Future assignment Same as Stop 224 - Activates Function Channels Held for 5 seconds Command 9. Will be implemented in 2009 R59770057 CLM HD8 14/01/2009...

  • Page 192: Clm Control Channel Mapping (Simple Mode)

    Activate Layout 4 If held for 2 Sec 160 - Power On / Lamp On If held for 2 Sec 192 - Stand By / Lamp Off If held for 2 Sec 224 - Future assignment Future assignment R59770057 CLM HD8 14/01/2009...

  • Page 193: Specifications

    Specifications CLM 5 cable input (multi purpose) • Specifications CLM HDSDI – SDI input • Specifications CLM DVI input • Specifications CLM DVI HDCP input D.1 Specifications CLM HD8 Overview Ambient temperature Max. 40°C (104°F) Brightness uniformity Communication • 1x RS-232C/RS-422 IN (D-9 connector) •...

  • Page 194: Specifications Clm 5 Cable Input (Multi Purpose)

    Sealed DLP™ core Standard Weight 31 kg excl. lens and rigging frame D.2 Specifications CLM 5 cable input (multi purpose) Front view 5 cable input 5-CABLE INPUT SYCN OK G/Y/VIDEO Image D-1 R59770057 CLM HD8 14/01/2009...
  • Page 195 G(s) : 1Vpp ±3dB (0,7Vpp G + 0,3Vpp Sync) 75 Ohm termination. B : 0,7Vpp ±3dB 75 Ohm termination. • Diagnostic LED’s on front panel: Green LED: Lights up in case input module is selected Yellow LED: Lights up in case sync detected R59770057 CLM HD8 14/01/2009...

  • Page 196: Specifications Clm Hdsdi - Sdi Input

    1920x1035/59.94/2:1/ (SMPTE 260M) 1920x1080/60/2:1/ (SMPTE 274M) 1920x1080/59.94/2:1/ (SMPTE 274M) 1920x1080/50/2:1/ (SMPTE 274M) 1920/1080/50/2:1 (1250)/ (SMPTE 295M) 1920x1080/24/Segmented/ (SMPTE 274M) 1920x1080//23.98/Segmented/ (SMPTE 274M) D.4 Specifications CLM DVI input Input front view DVI input Sync OK Image D-3 R59770057 CLM HD8 14/01/2009...

  • Page 197: Specifications Clm Dvi Hdcp Input

    Cable lengths: up to 3 meter at UXGA speed. • Compliance: DDC2B support according to VESA EDID Version 1.2 • Diagnostic LED’s on front panel: Green LED: Lights up in case input module is selected Yellow LED: Lights up in case sync detected R59770057 CLM HD8 14/01/2009...
  • Page 198 D. Specifications R59770057 CLM HD8 14/01/2009...

  • Page 199: Troubleshooting

    Call a qualified service engineer failed 1693 1692 1691 2100 LPS 1 error Replace LPS 2400 LPS 2 error Replace LPS 2700 LPS 3 error Replace LPS 3000 LPS 4 error Replace LPS R59770057 CLM HD8 14/01/2009...
  • Page 200 Fan is running too slow or not at all If problem persists, call a qualified service engineer 7910 Fan LPS B low Fan is running too slow or not at all If problem persists, call a qualified service engineer R59770057 CLM HD8 14/01/2009...
  • Page 201 Call a qualified service engineer exceeded 7863 Lamp 1 run The maximum run time for the lamp Replace the lamp with a new one. time max Call a qualified service engineer is exceeded exceeded R59770057 CLM HD8 14/01/2009...
  • Page 202 9199 Scaler unit Initialization of the scaler failed If problem persists, call a qualified failed service engineer 9198 Scaler pixel BW or refresh rate of input source clock too high too high R59770057 CLM HD8 14/01/2009...
  • Page 203 OSD memory Call a qualified service engineer 27996 OSD out of Call a qualified service engineer range 27995 OSD out of Call a qualified service engineer pos. 27994 OSD fifo full Call a qualified service engineer R59770057 CLM HD8 14/01/2009...
  • Page 204 E. Troubleshooting R59770057 CLM HD8 14/01/2009...

  • Page 205: Mounting Optional Carry Handle

    To turn the projector upside down and place it on the top cover. • To stack two projectors on each other. How to mount the stacking points 1. Break out the circular holes in the top cover. R59770057 CLM HD8 14/01/2009...

  • Page 206: Preparing The New Carry Handle

    fixation bolt of the carry handle is covered by the stacking point construction. How to remove the stacking point construction 1. Turn out the 4 bolts, 2 on each side. Be aware that there is a nut for each bolt on the inside of the carry handle. R59770057 CLM HD8 14/01/2009...

  • Page 207: Preparing The Projector

    2. Remove the 3 feet. First unscrew the foot cap (reference 1) and than loosen the foot adapters (reference 3). Use a 4 mm Allen wrench to unscrew the hexagon socket head cap screws (reference 2). R59770057 CLM HD8 14/01/2009...

  • Page 208: Mounting The Carry Handle

    4. Insert a hexagon socket head cap screw (reference 1) into both fixation holes at the front of the carry handle. Note: If both front holes are not completely free, turn on the skew adjustment (reference 5) at the right side of the carry handle until the holes are free. R59770057 CLM HD8 14/01/2009...
  • Page 209 5. Fasten all screws (reference 1 & 2). Use a 8 mm Allen wrench. 6. Place the removed stacking point construction back on its place and secure with four hexagon socket head cap screws M5 x 10. Use a 2,5 mm Allen wrench. Image F-8 R59770057 CLM HD8 14/01/2009...
  • Page 210 F. Mounting optional Carry handle R59770057 CLM HD8 14/01/2009...

  • Page 211: Order Info

    CLM lamp kit, four lamps R9861000 Optional rigging kit for CLM + rugged remote control R9861010 CLM flight case R764988 CLM remote control unit R9849870 CLD (1.2-1.6:1) zoom lens R9861080 CLD (1.6-2.4:1)[ zoom lens R9849890 CLD (2.4-4.3:1) zoom lens R59770057 CLM HD8 14/01/2009...
  • Page 212 G. Order info R59770057 CLM HD8 14/01/2009...

  • Page 213: Glossary

    DisplayPort, Digital Visual Interface (DVI), High-Definition Multimedia Interface (HDMI), Gigabit Video Interface (GVIF), or Unified Display Interface (UDI) connections. The specification is proprietary, and implementing HDCP requires a license. HEPA High Efficiency Particulate Absorbing R59770057 CLM HD8 14/01/2009...
  • Page 214 2 lines is < - 0.2V that equals with a logical ’0’. When the difference is > +0.2V that equals to a logical ’1’.. Subnet mask A number that is used to identify a subnetwork so that IP addresses can be shared on a local area network. R59770057 CLM HD8 14/01/2009...

  • Page 215: Index

    Carry handle Fan speeds Projector Diagnosis Cleaning File services Exterior Manual load file Lens Film mode detection Color saturation Front cover 173, 179 Color space Installation Color standard Removal Color temperature 76–77 Front projection Custom values R59770057 CLM HD8 14/01/2009...
  • Page 216 Input balance Input balance adjusting Noise reduction Phase Keystone Saturation Sharpness Tint Overview flow Lamp 109–112 Save custom settings Identification Source timings Lamp mode Start up Overview Timings 83–84 Power Advanced settings Power mode Image file services R59770057 CLM HD8 14/01/2009...
  • Page 217 Local LCD contrast Menu position Network 135–138 DHCP Native resolution Gateway Navigation Introduction Adjustment mode IP-address Network 135–138 Subnet-mask DHCP Projector address 132–133 Gateway Address Introduction Common address IP-address Serial communication 133–134 Subnet-mask Baud rate setup R59770057 CLM HD8 14/01/2009...
  • Page 218 Diagnosis Mercury vapor warnings Stacking 31, 33 Personal injury Align projectors Projector damage Projectors Replacement parts Stacking points Servicing Mounting Ultraviolet radiation Start up 46, 55 UV radiation Adjustment mode Saturation Errors and warnings Save as R59770057 CLM HD8 14/01/2009...
  • Page 219 Text on/off Voltages Tilt range Start up Timings Tint Top cover 176, 178 Installation Warnings 6–7 Remove Cooling liquid circuit Troubleshooting Mercury vapor warnings Error codes Ultraviolet radiation UV radiation White peaking Window Ultraviolet radiation PIP window R59770057 CLM HD8 14/01/2009...
  • Page 220 Index R59770057 CLM HD8 14/01/2009...
  • Page 221 Revision Sheet Barco nv Events/Documentation Noordlaan 5, B-8520 Kuurne Phone: +32 56.36.89.70, Fax: +32 56.36.88.24 E-mail: service.mne@barco.com, Web: www.barco.com From: Date: Please correct the following points in this documentation (R59770057/05): page wrong correct R59770057 CLM HD8 14/01/2009...
