4115T Light Duty Industrial PC
Back Panel
The diagram below shows the back panel of the 4115T. For maintenance, installation
or upgrade, first remove the back cover by unfastening seven screws as shown in the
diagram below.
Before any installation or un-installation, please take precautions to prevent damage
to the components due to static electricity.
Figure 1-2. System Back Panel
Caution
3
Chapter 1 – Introduction
143926(A)
