Using Setup

In general, you use the arrow keys to highlight items, press Enter to select, use the
PgUp and PgDn keys to change entries, press F1 for help and press Esc to quit. The
following table provides more detail about how to navigate in the Setup program
using the keyboard.
Keys
Up arrow
Down arrow
Left arrow
Right arrow
Esc key
PgDn key
PgUp key
+ key
- key
F1 key
F2 /F3 key
F4 key
F5 key
F6 key
F7 key
F8 key
F9 key
F10 key

Getting Help

Press F1 to pop up a small help window that describes the appropriate keys to use and
the possible selections for the highlighted item. To exit the Help Window press Esc
or the F1 key again. Note: For this BIOS, Help has been disabled.
If, after making and saving system changes with Setup, you discover that your
computer no longer is able to boot, the AMI BIOS supports an override to the CMOS
settings, which resets your system to its defaults.
The best advice is to only alter settings that you thoroughly understand. To this end,
we strongly recommend that you avoid making any changes to the chipset defaults.
Chapter 3 – POS-478 CPU Control Board and BIOS Setup
Table 3-2. Using Setup
Description
Move to previous item
Move to next item
Move to the item in the left hand
Move to the item in the right hand
Main Menu -- Quit and not save changes into CMOS
Status Page Setup Menu and Option Page Setup Menu --
Exit current page and return to Main Menu
Increase the numeric value or make changes
Decrease the numeric value or make changes
Increase the numeric value or make changes
Decrease the numeric value or make changes
General help, only for Status Page Setup Menu and Option
Page Setup Menu
Change color from total 16 colors. F2 to select color
forward, (Shift) F2 to select color backward
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Save all the CMOS changes, only for Main Menu
32 143926(A)
