4115T Light Duty Industrial PC
Audio Connector
Internal Switches and Indicators
There is one internal switch controlling your CPU board.
Chapter 3 – POS-478 CPU Control Board and BIOS Setup
CN7: Audio CD IN (2.54mm)
PIN Description PIN
1 CD IN_L
3 GND
CN1: Audio AUX IN (2.54mm)
PIN Description PIN
1 AUX IN_L
3 GND
CN2: Audio LINE OUT (2.54mm)
PIN Description PIN
1 LINEOUT_L
3 GND
CN24: Audio Jack
Color
RED
BLUE
GREEN
S2: Reset Switch
PIN Description PIN
1 Reset
28
Description
2 GND
4 CD IN_R
Description
2 GND
4 AUX IN_R
Description
2 GND
4 LINE OUT_R
Description
MIC IN
LINE IN
SPEAK OUT
Description
2 GND
143926(A)
