Appendix E – How to Use the Wake-Up Function
POS-478E provides two kinds of Wake-Up functions: Modem Wake-up and LAN
Wake-up. The Wake-Up function will be activated when ATX power supply is in use.

Wake-Up On Modem (Ring)

Wake-Up On Modem is set in CMOS SETUP. Activating this function allows the
ATX power supply to be switched on when there is a ring signal detected on pin "RI"
of the serial port.

Wake-Up On LAN

When your computer is in power-down status, the LAN Link/Active LED will flash,
indicating that the LAN chip has entered standby mode. The LAN chip is waiting for
a Wake-Up signal to become active. You can use other computers to wake up your
computer by sending an ID to it. An ID is the address of your system LAN; every
LAN chip has a factory-set ID. The LAN ID can be found in the network information
section in Microsoft Windows. The ID format is xxxxxxxxxxxx. (Example ID:
009027388320)
