4115T Light Duty Industrial PC
Some components on POS-478E are very sensitive to static discharges. To protect
it from unintended damage, be sure to follow these precautions:
1. Ground yourself to remove any static charge before touching your POS-478E.
You can do it by using a grounded wrist strap at all times or by frequently touching
any conducting materials that is connected to the ground.
2. Handle your POS-478E by its edges. Don't touch IC chips, leads or circuitry if not
necessary.
3. Do not plug any connector or jumper while the power is on.
4. Do not put your POS-478E unprotected on a flat surface, as the board has
components on both sides.

Jumper Settings

The following table lists the functions of all the jumpers on the 4115T. The following
sections describe how to set jumpers on the POS-478 board.
Label
JP1
JP2
JP3
JP4
JP5
JP6
JP7
JP8
JP9
JP10
JP11
JP12
JP13
JP14
JP15
JP16
JP18
JP19
Chapter 3 – POS-478 CPU Control Board and BIOS Setup
Caution
Table 3-1. Jumper Functions
CMOS State Setting
LCD Voltage Setting
LCD 24 bit or 18 bit LCD Setting
LCD CLK Signal Setting
LCD Single Pixel or Dual Pixel Setting
Set pin 9 of COM2 Voltage Setting
Set pin 9 of COM1 Voltage Setting
Set pin 9 of COM2 as Signal RI or Voltage Setting
Set pin 9 of COM1 as Signal RI or Voltage Setting
COM2 Mode Setting
COM2 Mode RS-232 or RS-422/RS-485 Setting
Compact Flash Master/Slave Setting
Set pin 9 of COM3 Voltage Setting
Set pin 9 of COM4 Voltage Setting
Set pin 9 of COM3 as Signal RI or Voltage Setting
Set pin 9 of COM4 as Signal RI or Voltage Setting
Keyboard & Mouse Power Source Setting
Enable or Disable Serial ATA (only for POS-478S)
16
Function
143926(A)
