Xycom 4115T User Manual page 33

4115T Light Duty Industrial PC
CompactFlash TYPE II Storage Card Socket
POS-478 configures CompactFlash TYPE II Storage Card in IDE Mode.
Note: Type I storage cards are supported.
PIN Description
GROUND
1
2 D3
3 D4
4 D5
5 D6
6 D7
7 CS1#
8 N/C
9 GROUND
10 N/C
11 N/C
12 N/C
13 VCC
14 N/C
15 N/C
16 N/C
17 N/C
18 A2
19 A1
20 A0
21 D0
22 D1
23 D2
24 N/C
25 CARD DETECT2
Chapter 3 – POS-478 CPU Control Board and BIOS Setup
CFA1: CompactFlash TYPE II Socket PIN Assignment
PIN
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
29
Description
CARD DETECT1
D11
D12
D13
D14
D15
CS3#
N/C
IOR#
IOW#
OBLIGATORY TO PULL HIGH
IRQ15
VCC
MASTER/SLAVE
N/C
RESET#
IORDY
N/C
OBLIGATORY TO PULL HIGH
ACTIVE#
PDIAG#
D8
D9
D10
GROUND
143926(A)
