4115T Light Duty Industrial PC

Touch Screen

Table 1-2 identifies important specifications of the 4115T touch screen.
Touch Screen Model
Screen Type
Resolution
Light Transmission
Surface Hardness
Support Driver
The figures on the next several pages show the internal and external components on
the front and back panels of the unit to help you locate features relevant to
installation.

I/O Panel

The figure below shows the I/O panel of the 4115T.
Table 1-2. 4115T Touch Screen Specifications
Description
Eight wire analog resistive touch screen
Continuous
Typical value 75%
4H (Test condition: ASTM D3363-92A)
Supports Windows 2000/XP
Figure 1-1. I/O Panel
Note: There is only one Ethernet port available
