KVM Over the NET™ User Manual

The Java Control Panel

The Java Applet Viewer and Java Client AP Control Panel is similar to the one
used by the WinClient:
The major differences between them are:
In the Macros dialog box, Toggle Mouse Display is not available.
The Dot mouse pointer type is not available.
The 1:1 Zoom feature is not available.
The Message Board:
There is no Show/Hide button to show or
hide the user list. This function is
achieved by clicking the arrows at the
top of the bar that separates the User List
panel from the Main panel.
If another user sends a message to the
message board and your message board is not open, instead of the
message appearing in the text bar, a window showing the message pops
up on your screen.
In Virtual Media, only ISO and Folder are supported. See Java Applet
Viewer / Java Client AP, page 229 for further details.
The Control Panel Lock LED icons are not in sync with your keyboard.
When you first connect, the LED display may not be accurate. To be sure,
click on the LED icons to set them.
In Control Panel Configuration, the following functions are not available:
the Transparent control panel style; Screen Options; and Keyboard
Passthrough. The BMP Snapshot format has been replaced by PNG.
