Port Level

When a port is selected in the Sidebar tree, the Connections page changes to
display the port connection and configuration options:
The screen is divided into three major panels, as described in the table below:
Panel
Status
Associated Link
Exit Macro
92
The Status Panel displays the port's current status
information, including whether the port is online or offline, and
if the port is mountable.
Click the Connect button to view the port display via the
switch's built-in Win Viewer (when using Windows Internet
Explorer), or Java Viewer (when using other web browsers).
The Associated Link Panel provides a method of associating
other ports on the same switch to the selected port. This
function is primarily intended to be used when connecting
both KVM and serial ports (KA7140, KA9140) from a single
server to the switch. Click Add to add a desired associated
port. To remove an unwanted associated port, select it and
click Remove. To connect to a port, select it, and click
Connect.
The Exit Macro Panel contains a dropdown listbox of System
macros. You can select a macro from the list that will execute
when exiting the port. See System Macros, page 61 for details
on creating exit macros.
The macro only executes after the last user accessing the port
exits the port.
Description
