KVM Over the NET™ User Manual

KA7140 Configuration and Operation

The KA7140 Adapter Cable connects a serial device to the switch.

Configuration

To configure the KA7140 to interact with the connected device, you need to set
its serial parameters to match the parameters of the device, as follows:
1. In the Port Access page Sidebar, select the port that the KA7140 is
connected to.
2. Select Access on the menu bar.
3. In the Properties section, drop down each of the lists to select the port
property values that match the ones used by the connected serial console
device. The port property settings that the KA7140 supports are given in
the following table:
Setting
Bits per second
(Baud Rate)
Data Bits
214
This sets the port's data transfer speed. Choices are from
300—38400 (drop down the list to see them all). Set this to
match the baud rate setting of the serial console device.
Default is 9600 (which is a basic setting for many serial console
devices).
This sets the number of bits used to transmit one character of
data. Choices are: 7 and 8. Set this to match the data bit setting
of the serial console device. Default is 8 (which is the default for
the majority of serial console devices).
Meaning
