KVM Over the NET™ User Manual

PPP Modem Operation

Basic Setup

In addition to the browser and AP methods, the switch can also be accessed
through its RS-232 port using a PPP dial-in connection, as follows:
1. Set up your hardware configuration to match the diagram, below:
Remote
Operator
2. From your client computer, use your modem dial-in program to dial into
the switch modem.
Note: 1. If you don't know the switch modem's serial parameters, get
them from the switch administrator.
2. An example of setting up a modem dial-in program under
Windows XP is provided on the next page.
3. Once the connection is established, open your browser, and specify
192.168.192.1 in the URL box.
Note: The default username and password are blank.
From here, operation is the same as if you had logged in from a browser or with
the AP programs.
212
:
Cat 5e Cable
Serial Modem Cable
Modem
SA0142
(DB9-M, DTE - DCE)
Phone Line
Modem
