KVM Over the NET™ User Manual

KN2132 / KN4132

Function
Computer Direct
Connections
Max
Port Selection
Connectors Console
Port
KVM Port
Power
LAN
PON
Modem
USB
Switches Reset
Power
Port Selection
LEDs On Line
Selected
Power
Link
10 / 100 / 1000 Mbps
Emulation Keyboard/Mouse
Video
Scan Interval
I/P Rating
Power Consumption
Environment Operating Temp.
Storage Temp.
Humidity
Physical Housing
Properties
Weight
Dimensions L x W x H
196
KN2132
Keyboard 1 x 6-pin Mini-DIN Female (Purple)
Video
Mouse 1 x 6-pin Mini-DIN Female (Green)
PS/2 / USB (PC, Mac, Sun) / Serial
110V / 33.40W
230V / 34.20W
5.59 kg
32
512
Pushbutton / GUI / Hotkey
1 x USB Type A Female (White)
1 x HDB-15 Female (Blue)
1 x USB Type A Female (White)
32 x RJ-45 Female (Black)
1 x 3-prong AC socket
2 x RJ-45 Female (Black)
1 x RJ-45 Female (Black)
1 x RJ-45 Female (Black)
3 x USB Type A Female (White)
1 x Semi-recessed Pushbutton
1 x Slide
2 x Pushbutton
32 (Green)
32 (Red)
1 (Blue)
2 (Red / Red + Green / Green)
1600x1200 @ 60Hz
1–255 secs
100–240VAC; 50–60Hz; 1.0A
110V / 45.80W
230V / 46.30W
0–50° C
-20–60° C
0–80% RH
Metal
43.36 x 41.35 x 4.40 cm (19" 1U)
KN4132
5.63 kg
