Connections; Device Level - Altusen KVM OVER THE NET KN2116A User Manual

Connections

The Connections page displays port status information at the device level, and
port connection configuration options at the port level.

Device Level

When a KVM Over the NET
Connections page displays a list of ports for the device that the user is
authorized to access or view.
The following attributes are listed for each device:
Port Number – the port's number on the switch.
Port Name – if a name has been assigned to a port it displays here.
Device Name – if a name has been assigned to a switch it displays here.
Status – the current status of the switch – online, or offline.
Operation – Connect means you can access the port by double clicking
anywhere on its line entry.
Note: In the Web Browser version, the sort order of the information displayed
can be changed by clicking the column headings.
TM switch is selected in the Sidebar tree, the
Chapter 6. Port Access
91
