KVM Over the NET™ User Manual
4. Plug a cable from the LAN or WAN into the KVM Over the NET
primary network interface socket.
5. (Optional) Plug another cable from the LAN or WAN into the KVM Over
the NET TM switch backup (secondary) network interface socket.
6. (Optional) Use Cat 5e cable to connect the KVM Over the NET
PON port to an SA0142 Adapter. Connect the Adapter to the PON IN port
of a PN0108 Power Over the Net™ unit.
7. (Optional) Use Cat 5e cable to connect the KVM Over the NET
Modem port to an SA0142 Adapter. Connect the Adapter's serial
connector to the modem's DB-9 port.
8. Use the grounding wire supplied with this package to ground the unit by
connecting one end of the wire to the grounding terminal, and the other
end of the wire to a suitable grounded object.
Note: Do not omit this step. Proper grounding helps to prevent damage to
the unit from surges or static electricity.
9. Plug the power cord(s) supplied with this package into the KVM Over the
NET switch power socket, and then into an AC power source.
TM
For the KN2124v, KN2140v, KN4124v and KN4140v, when using a
single power socket, be sure to turn on the correct power switch (see
Power Switch, page 13). When using both power sockets, either of the
power switches can be used to turn on the KVM switch – or, to enable dual
power, turn on both power switches.
Note: If you are connecting the power to a UPS or an ALTUSEN PN9108/
PN0108 use the utility power cords supplied with this package
instead of the standard power cords.
After the KVM Over the NET
After it is powered up, you can turn on the servers.
22
TM switch is cabled up you can turn on the power.
