In-­‐Ceiling M ounting
Steps:
1) Drill t he s crew h oles a nd t he c able h ole o n t he c eiling a ccording t o t he s upplied d rill t emplate.
2) Loosen t he s et s crews w ith t he h ex k ey ( supplied) t o r emove t he b ubble; a nd r emove t he b lack l iner.
3) Rotate t he t oggle t o r emove i t f rom t he t oggle b olt.
4) Insert t he b olt i nto t he t oggle b olt h ole o n t he d ome d rive a nd u se t he s crew d river t o r otate t he b olt
slightly b ut n ot t ightly.
5) Reinstall t he t oggle a nd p ush t he d ome d rive t o t he c able h ole o n t he c eiling w ith t oggle b olts a ligned
with t he s crew h oles o n t he c eiling.
10225 Westmoor Drive, Suite 300, Westminster, CO 80021 | w ww.3xlogic.com | (877) 3XLOGIC
Installation Manual
1
Drill T emplate
A
Hole A : f or t he r ecessed p art o f
t he c amera b ody
Screw h ole 1 : f or T oggle b olt
1
Code:190600840
Table 1-­‐ 1 7 Drill Template
Table 1-­‐ 1 8 Disassembling
