3xLogic VSX-2MP-FE Installation Manual page 33

To d igitally a djust t he z oom a nd f ocus, v isiting t he d evice's w eb i nterface a nd a djust t hese
settings f rom t he P TZ c ontrol i nterface.
NOTE:
6) Attach t he b lack l iner t o t he d ome d rive.
7) Attach t he b ubble t o t he d ome d rive a nd r otate t o t ighten i t
8) Tighten t he l ock s crew t o c omplete t he i nstallation.
10225 Westmoor Drive, Suite 300, Westminster, CO 80021 | w ww.3xlogic.com | (877) 3XLOGIC
Zoom a nd F ocus A djustment o f E lectronic L ens
Figure 4-­‐26
Dome D rive
Install t he B lack L iner a nd B ubble
Figure 4-­‐27
Complete t he I nstallation
Figure 4-­‐28
|
Installation Manual
Bubble
Black L iner
V ISIX N etwork C amera
