3xLogic VSX-2MP-FE Installation Manual page 51

6) Insert t he h ex k ey i nto t he h ole m arked i n t he p icture a nd r otate t he h ex k ey t o a djust t he p anning
position a nd t ilting p osition u ntil t he d esired s urveillance a ngle i s a chieved. T ighten t he s et s crews t o
lock t he a ngle.
NOTE: As t he l ens o f c amera h as a lready b een f actory a djusted t o t he b est i mage, y ou j ust n eed t o a djust
the p anning p osition a nd t ilting p osition t o g et t he d esired s urveillance a ngle.
7) Reinstall t he c over b efore v iewing t he i mage s o t hat t he i mage y ou r eceive w ill a ppear t he s ame a s i t
would a fter f inal i nstallation.
8) Install t he c over, a nd t ighten t he s et s crews.
10225 Westmoor Drive, Suite 300, Westminster, CO 80021 | w ww.3xlogic.com | (877) 3XLOGIC
Installation Manual
Adjust P anning P osition
Figure 5-­‐34
Adjust T ilting P osition
Figure 5-­‐35
V ISIX N etwork C amera
|
50
