In-­‐Ceiling M ounting
Steps:
4) Secure t he m ounting b ase t o t he i n-­‐ceiling m ounting b ase w ith s crews.
5) Push t he d ome c amera i nto t he i n-­‐ceiling m ounting b ase, r otate t he d ome c amera 1 0 d egrees
counterclockwise a nd t hen f asten t he l ock s crews t o s ecure t he c amera i n p lace.
①
6) Cut a 1 76~180 m m d iameter h ole i n t he c eiling a nd p ush t he d ome c amera w ith i n-­‐ceiling m ounting
base i nto t he h ole.
NOTE:
The t hickness o f t he c eiling s hould b e l ess t han 3 0mm.
10225 Westmoor Drive, Suite 300, Westminster, CO 80021 | w ww.3xlogic.com | (877) 3XLOGIC
Installation Manual
Mounting B ase
Figure 4-­‐9
②
Camera a nd M ounting B ase
Figure 4-­‐10
V ISIX N etwork C amera
|
In-­‐ceiling
Mounting
ase
Mounting
Base
③
Lock S crew
