Adapter P late
NOTE: If t he s upplied d rill t emplate i s t ype I I d rill t emplate, y ou c an s kip s tep 3 a nd g o s traight t o s tep 4 .
4) Attach t he d ome d rive w ith t he s upplied P M4x8 s crews.
5) Connect t he p ower c able, n etwork c able, a nd t he a larm/audio c able.
NOTE: Use p liers t o r emove t he r emovable p art a nd r oute t he c ables v ia s ide o utlet ( as s hown i n F igure
5-­‐16) i f n o c able h ole i s d rilled i n s tep 1 , a nd c onnect t he c orresponding c ables.
10225 Westmoor Drive, Suite 300, Westminster, CO 80021 | w ww.3xlogic.com | (877) 3XLOGIC
Installation Manual
Side O utlet
Attach t he A dapter P late
Figure 5-­‐14
Attach t he D ome D rive
Figure 5-­‐15
V ISIX N etwork C amera
|
