Configuration Manual
Ascom d81 DECT Handset
Custom sounds according to beep code
The handset can play customized message alerts that are mapped to beep codes. The
message alerts must first be customized and then mapped to the beep codes.
Customized sounds may also be mapped to enhanced beep codes, as described in
A. Programming Custom Sound
Tip: It is recommended to use this feature to create a message alert that sounds like an item
of equipment, such as a respirator, that generates an alarm.
Beep code sent from a system/application
Beep code 0
Beep codes 1- 7
Create Customized Sound
1 Select Settings > Custom Sounds > Custom Sound X (where X represent 1 - 10).
2 Set the following parameters:
• Label - The name of the custom sound (required). The name is visible when
mapping the custom sound to a beep code later on.
• Melody - The text string represents a non-polyphonic sound. By default, example
of melodies are set for Custom Sound 1 - 7. See also
Custom Sound
A.1.
• Beat - The tempo in beats per minute to be used when playing the sound.
• Style - The ratio of note to rest period to be used when playing the sound.
• Instrument - The instrument to be used when playing the sound.
Map Beep Codes to Customized Sounds
1 Select Sound and Alerts > Custom Message Alert
2 In the Beep code drop-down lists, select the customized sounds to be used for
respectively beep codes.
Enable Customized Sound
1 Select Settings > Sound and Alert.
2 In the Message alert drop-down list, select "Custom sounds according to beep code"

5.31.2 Examples of TTR/TTP Settings

Example 1
This example describes the message handling with the following message settings:
• TTP= Prioritize forever
• TTR= Close manually
Tip: It is recommended to use these settings if messages with the highest priority are
always displayed until the user closes the current message.
29 April 2015 / Ver. I
5. Handset Configuration
on page 73.
on page 73. For enhanced beep code mappings, also see
The handset plays:
No message alert is played
Corresponding Customized sound
Appendix A. Programming
TD 92674EN
Appendix
Appendix
45
