Pull-Cord Alarm; Man-Down Alarm And No-Movement Alarm - ASCOM d81 Configuration Manual

Configuration Manual
Ascom d81 DECT Handset
This configuration lets the user long press the push-button to dial the number without
sending an alarm. However, the push-button can be configured to send an alarm by pressing
it twice (see Alarm type for multiple press in chapter

5.28 Pull-Cord Alarm

Note: Pull-cord alarm is not available when upgrading the product license from d81
Messenger to d81 Protector. That is, only applicable for d81 Protector with the No-
movement/Man-down hardware. In addition, this function requires a functionality license.
see 4.4 Upgrade Handset by License
The handset can be configured to send an alarm when the pull-cord is pulled off the
handset.
In a template or Number in PDM/Device Manager, the parameters for activation are found
at:
Alarm > Pull-cord alarm
The alarm can also be activated in the handset, see handset's User Manual,.
Parameters in the current version are:
• Pull-cord alarm
• ALS
• Mode for automatic call after alarm
See also 5.26 Common Alarm Settings
Information about the handset's location can also be sent along with an alarm, see
Base Station Location

5.29 Man-Down Alarm and No-Movement Alarm

NOTE: Man-down and No-movement are not available when upgrading the product license
from d81 Messenger to d81 Protector. That is, only applicable for d81 Protector with
the No-movement and Man-down hardware.
Man-down alarm: If the handset is tilted 45 degrees
(default 7 seconds), the Man-down alarm is triggered.
No-movement alarm: If no movement is detected during a preset time (default 30 seconds),
the No-movement alarm is triggered.
The parameters for activation are found at:
Alarm > Man-down and No-movement alarm
The alarms can also be activated in the handset, see the handset's User Manual.
Parameters in the current version are:
• Man-down alarm
Determines if the Man-down alarm is enabled or disabled.
• Man-down detection time
Determines when the warning phase starts after man-down is triggered.
1.The accuracy is +/- 10 degrees.
29 April 2015 / Ver. I
5. Handset Configuration
on page 11.
on page 37 for additional parameter settings.
on page 32 and 5.22 DECT Location and LF Location
5.27 Push Button Alarm
on page 33.
1
(default) or more for a preset time
TD 92674EN
on page 37).
5.21
39
