Special Location; Poll Location; Site Survey Tool - ASCOM d81 Configuration Manual

Configuration Manual
Ascom d81 DECT Handset
Location > Indicate location with LED
• Off - The LED indication is turned off
• Blink on new - The LED flashes when the handset receives a new valid location. A location
is considered as "new" when the location ID is changed for the current location.
• Blink always - The LED flashes when the handset receives a valid location.
• Steady always - The LED lights continuously as long as the handset receives valid
locations with a rate not exceeding 1 second.
Location Information during Call
When the Admin menu is activated and DECT location or LF location is enabled, the
corresponding location information screen can be accessed during a call by pressing the soft
key "More" and selecting "Location info".
For additional information about DECT location concepts, see Planning Guide, DECT Location,
TD 93009.

5.23 Special Location

A special location is a valid location received by the handset from a location device that is
automatically sent to the system. To prevent the system from being overloaded, a special
location that has already been received in the last three seconds will not be sent to the
system again. The special location feature is managed from the Edit template or Edit
parameters dialog window in the PDM/Device Manager in the following way:
1 Select Location > Special location
2 In the Special location drop-down list, select one of the following:
• On- Turns the special location feature on
• Off - Turns the special location feature off.

5.24 Poll Location

A system or application can request the handset location. When a request is issued, the
handset sends its exact location (DECT location enabled or LF location enabled or both) or an
approximate location (Base Station positioning enabled) depending on the set parameters
in the handset.
If DECT location or LF location or both are enabled, the handset sends the four last received
DECT and LF location IDs together with the time since they were received. See also
Location and LF Location
If Base Station positioning is enabled, the handset sends the best-rated Base Station ID
together with the time since it was received. See also
32.

5.25 Site Survey Tool

See the User Guide for Site Survey Tool.
29 April 2015 / Ver. I
5. Handset Configuration
on page 33.
5.21 Base Station Location
TD 92674EN
5.22 DECT
on page
36
