HARMON ROCKET III.

INSTALLING THE RECEIVER AND BATTERY.

1) Plug the six servo leads and the switch
lead into the receiver. Plug the battery pack
lead into the switch also.
2 Wrap the receiver and battery pack in
the protective foam rubber to protect them
from vibration.
3) Position the battery pack in the fuel
tank compartment and the receiver just be-
hind the fuel tank . Use extra foam pieces to
hold them in position.
When balancing the airplane you may
need to move the battery or receiver for-
ward or after to achieve proper balance.
4) Using a 1/16" drill bit, drill a hole through
the side of the fuselage, near the receiver, for
the antenna to exit. Route the antenna out of
the fuselage and secure it to the vertical stabi-
lizer using a rubber band and a modified servo
arm. See picture as below.
Antenna
Modified
Servo Arm
ATTACHMENT WING - FUSELAGE.
See picture below:
22
anced correctly. Improper balance will cause
your plane to lose control and crash. The cen-
ter of gravity is located 3 1/4" to 3 1/2" be-
hind the leading edge of the wing.
is nose heavy. To correct this first move the
battery pack further back in the fuselage. If
this is not possible or does not correct it, stick
small amounts of lead weight on the fuselage
sides under the horizontal stabilizer. If the tail
of the plane falls, the plane is tail heavy. To
correct this, move the battery and receiver for-
ward orif this is not possible, stick weight onto
the firewall or use a brass heavy hub spinner
hub, similar to those offered by Harry Higley.
When balanced correctly, the airplane should
sit level or slightly nose down when you lift it
up with your fingers.
Cut
Rubber
Band
Harmon Rocket III using the control throws
listed at right. We have listed control throws
for both Low Rate (initial test flying/sport fly-
ing) and High Rate (aerobatic flying).
trim tabs on the transmitter in neutral, center
the control surfaces by making adjustments
to the clevises or adjustable servo connec-
tors. The servo arms should be centered also.
control surfaces are centered, use a ruler and
check the amount of the control throw in each
surface. The control throws should be
measured at the widest point of each sur-
face!
Instruction Manual.
BALANCING.
1) It is critical that your airplane be bal-
2) If the nose of the plane falls, the plane

CONTROL THROWS.

1) We highly recommend setting up the
2) Turn on the radio system, and with the
3) When the elevator, rudder and aileron
