HARMON ROCKET III.
3) Slide the cowl back over the engine
and secure it in place using four 3mm x 12mm
wood screws. See picture below.
4) Install the muffler and muffler extension
onto the engine and make the cutout in the
cowl for muffler clearance. Connect the fuel
and pressure lines to the carburetor, muffler
and fuel filler valve.
Machine screw
3mm X 12mm.
14
1.5mm wire
(needle valve).
Instruction Manual.

INSTALLING THE SPINNER.

1) Install the spinner backplate, propeller and
spinner cone. The spinner cone is held in
place using two 3mm x 12mm wood screws.
The propeller should not touch any part
of the spinner cone. If it does, use a
sharp modeling knife and carefully trim away
the spinner cone where the propeller comes
in contact with it.
