HARMON ROCKET III.
4.2- 4.5mm.
5) Bolt the engine to the engine mount
using the four machine screws and lock
washer. Double cheek that all the screws are
tight before proceeding.
6) Attach the Z-Bend in the pushrod wire
to the throttle arm on the carburetor. You will
need to remove the throttle arm from the car-
buretor to be able to attach the Z-bend. When
complete, reattach the throttle arm to the car-
buretor.
Pushrod wire.
4mm X 30mm.
gine and line up the back edge of the cowl with
the marks you made on the fuselage then trim
and cut.
flush with the marks, align the front of the cowl
with the crankshaft of the engine. The front of
the cowl should be positioned so the crank-
shaft is in nearly the middle of the cowl open-
ing. Use the spinner backplate as a guide. Hold
the cowl firmly in place using pieces of mask-
ing tape.
may be necessary to use a needle valve ex-
tension for the high speed needle valve. Make
this out of sufficient length 1.5mm wire and
install it into the end of the needle valve. Se-
cure the wire in place by tightening the set
screw in the side of the needle valve.
Instruction Manual.
COWLING.
1) Slide the fiberglass cowl over the en-
2) While keeping the back edge of the cowl
Because of the diameter of the cowl, it
Trim and cut.
Trim and cut.
Trim and cut.
