PIPER COMANCHE
3mm.
CONTROL HORN
M3 SCREW.
Epoxy.
.
M3 LOCK NUT
.
18mm
Flap control horn.
8
.
.
ALUMINUM WASHER
.
ALUMINUM WASHER
.
Epoxy
Instruction Manual.
INSTALL ELEVATOR CONTROL HORN.
Install the elevator control horn using the
same method as same as the aileron control
horns.
3x35mm.
3mm.
CONTROL HORN
M3 SCREW.
Aluminum Washer.
Horizontal
Stabilizer
.
Aluminum Washer.
Horizontal
Stabilizer.
16mm.
1 sets.
Epoxy.
Elevator
.
.
M3 LOCK NUT
Epoxy.
Elevator
.
