Seagull Models Piper Comanche MS:142 Assembly Manual page 15

Needle valve.
Machine screw M3x10mm.
www.seagullmodels.com
1) Locate the items neccessary to install the
electric power conversion included with your
model.
included with your model)
- Model size: .61-75 size models
- Motor: 50mm 310 rev per volt
- Propeller: 13x10 ~ 14x10
- ESC: 60A
- Lipo Batteries: 8 cell 3200mA
3) Install the muffler and muffler extension
onto the engine and make the cutout in the
cowl for muffler clearance. Connect the fuel
and pressure lines to the carburetor, muffler
and fuel filler valve. Secure the cowl to fuse-
lage using the M3x10mm screws.
ELECTRIC POWER CONVERSION.
4x20mm.
3x15mm.
Recommendation EP parts as shown (not
2) Attach the electric motor box to the firewall
suitable with the cross lines drawn on the electric
motor box and firewall. Using epoxy and balsa
stick to secure the motor box to the firewall.
Please see pictures below.
15
