When Pattern is selected
No. Parameter
1 Size
2 Soft
5 Pattern
a) The pattern is the same as the wipe. See
(1 p. 264).
To select the pattern, display the Mask Ptn Select
menu (1113.1) by pressing the [Mask Ptn Select]
button in the Main Mask menu.
After selecting one of the patterns (wipe patterns 1 to
24) displayed in the Mix Pattern Select menu, you can
adjust the following parameters.
No. Parameter
1 Size
2 Soft
5
To invert the black and white of the mask source, press
the [Mask Invert] button, turning it on.
6
When a pattern is selected as the mask source, set the
pattern modifiers as required (see step 5 of
out a color mix for the key edge fill matte" (1 p.

Key Modify Clear

A simple button operation or a menu operation returns the
key settings to the initial status settings.
Press [Default Recall] at the lower left of the menu screen,
turning it on, then press the corresponding VF button (VF1
to VF4) to return the key settings to their initial status.
For details about
initial status
Settings" (p. 214).

Blink Function

With the blink function, you can obtain the following
effects.
Key blink: The key is alternately inserted and deleted at
regular intervals. You can set the period of blinking,
and the proportion of each cycle for which the key is
inserted.
Edge blink: The key fill and key edge fill are interchanged
at regular intervals. You can set the period of blinking,
and the proportion of each cycle for which the original
state holds.
The blink settings are in the Transition menu for each key.
74

Key Adjustments (Flexi Pad)

Adjustment
Pattern size
Edge softness of the pattern
a)
Pattern number
"Wipe Pattern List"
Adjustment
Pattern size
Edge softness of the pattern
"Carrying
1 "Saving User-Defined
,
Using the blink function
For example, to perform settings for key 1 on the M/E-1
bank, use the following procedure.
1
Open the M/E-1 >Key1 >Transition menu (1116).
2
In the <Blink> group, select [Key Blink] or [Edge
Blink] to set it on.
3
Set the blink parameters.
When key blink is selected
No. Parameter
1 Blink Rate
2 Duty
When edge blink is selected
No. Parameter
1 Blink Rate
2 Duty
72)).
Key Adjustments (Flexi
Pad)
EDIT ENBL button
Mode selection buttons
Region selection buttons
Selecting the bank and keyer
Before carrying out key adjustment, first select the key
adjust mode, then select the switcher bank and keyer.
For example, to adjust key 1 on M/E-1, proceed as follows.
Adjustment
Length of blink cycle
Proportion of cycle for which
original state holds
Adjustment
Length of blink cycle
Proportion of cycle for which key
inserted
Alphanumeric display
Adjustment knobs
Adjustment
knob displays
Memory recall section
