Notes
The [BKGD] button is only effective when in the
mode for changing the key priority for after the
transition.
When the next transition selection button [KEY
PRIOR] is on, the selected key appears on top on the
preview monitor. The priority of keys other than the
selected one does not change.
3
To change the priority of more than one key, repeat the
previous operation as required.
Setting the Key Priority by a Menu
Operation
Changing the key priority
1
When operating from the M/E-1 bank, for example,
open the M/E-1 >Misc >Key Priority menu (1173).
2
To target the currently inserted keys, select [Key
Priority].
To target the keys after transition, select [Next Key
Priority].
3
For each of <Priority1>, <Priority2>, <Priority3>, and
<Priority4>, select a key to determine the key priority
sequence.
Notes
It is not possible to select the same key for two or more
priority numbers.
The keys appear in the set order on the program
monitor of the corresponding bank.
Displaying the Key Output Status
and Key Priority
The key status is displayed as follows in the key priority
display of the transition control block. (Example: K1
indicates key 1.)
50
Super Mix Settings / Color Matte Settings
Before transition
CRNT
K4
K3
K2
K1
Key priority display
The current priority (i.e., before transition) is displayed on
the left (CRNT), and the priority after the transition is
displayed on the right (NEXT).
After the transition is complete, the CURRENT and NEXT
displays switch places.

Super Mix Settings

You can set the output levels of the current and new video
signals at the mid-point of the transition, in the range 0 to
100%.
Notes
This transition type is not available for an independent key
transition.
1
When operating from the M/E-1 bank, for example,
open the M/E-1 >Misc >Transition menu (1171).
2
In the <Transition Type> group, select [Super Mix].
3
Adjust the output levels.
No. Parameter Adjustment
2 A Gain Background A output level
3 B Gain Background B output level

Color Matte Settings

You can specify the color matte that is inserted during
preset color mix by luminance, saturation, and hue values.
Also, in place of a color matte you can use an image
selected on the utility bus.
Notes
• This transition type is not available for an independent
key transition.
After transition
NEXT
K1
K2
K3
K4
