Inhibiting Cross-Point Button Operations - Sony MVS-3000 System User Manual

Cross-point control block button numbers
(first button numbers)
(second button
numbers)
On each switcher bank, each cross-point button has two
button numbers, and you use the shift button to switch
between these numbers.
In the case of a 24-button layout, the button numbers are as
follows.
Cross-point control block button numbers
Button Number when
the shift button
is not pressed
From the left end to 1 to 23
the 23rd button
Notes
You can use the rightmost (24th) button as a [SIDE FLAG]
button. In this case, the shift button moves one to the left,
to the 23rd, and the button numbers are offset by one.
For details about the [SIDE FLAG] button,
a Cross-Point Button to Enable/Disable Side Flags"
(p. 226).
Switching button numbers
The rightmost (24th) button functions as a shift button.
(The shift button function can be disabled in the Setup
menu.)
When selecting the signals of button numbers 1 to 23,
press the cross-point button for the desired signal.
To select button numbers 24 to 46, hold down the shift
button, and press the cross-point button for the desired
signal.
Inhibiting Cross-Point Button
Operations
For each cross-point button, you can temporarily inhibit
operations.
Notes
This setting is cleared when you reset the control panel.
46
Signal Selection
Buses for which operations can be
inhibited
Shift buttons
This setting applies to the cross-point buttons in each
switcher bank.
If you make the setting for one cross-point button, this
inhibits operation of all cross-point buttons with the same
number in the following buses.
The corresponding name also disappears from the source
name display.
• Background A, background B
• Keys 1 to 4
Shift buttons
• Utility bus
Assigning the function of disabling cross-
point button operation to a button
In the Setup menu, assign "Inhibit Set" to any of the
buttons in the 1st row.
For details,
Buttons" (p.
Number when
the shift button
Inhibiting operation of a cross-point button
is pressed
24 to 46
Hold down the button to which "Inhibit Set" is assigned,
and press the cross-point button whose operation you want
to inhibit.
The button you pressed flashes amber, and its operation is
inhibited.
Notes
1 "Assigning Even when you inhibit operation of a cross-point button,
macro attachment settings are still possible.
For details,
Attachment" (p.
Clearing a cross-point button operation
inhibit setting
Hold down the button to which "Inhibit Set" is assigned,
and press the button whose operation is inhibited (flashing
amber).
This clears the operation inhibit setting for the button you
pressed.
Clearing all operation inhibit settings
Press the button to which "Inhibit Set" is assigned and the
button to which "Inhibit All Clear" is assigned
simultaneously.
1 "Assigning a Bus or Function to 1st Row
235).
1 "Setting and Canceling a Macro
191).
